Introduction
APIs have become the backbone of modern software architecture, powering everything from mobile apps to microservices to SaaS integrations. According to Salt Security's State of API Security Report, 94% of organizations experienced API security issues in production in 2024, with API attacks increasing 400% year-over-year. As Pynt's 2025 API security research reveals, APIs have rapidly become the number one attack vector for data breaches, with 31% of customer-facing APIs still lacking basic HTTPS encryption.
This guide walks you through the complete API development and security testing workflow used by DevOps teams, security engineers, and API developers worldwide. We'll cover the full lifecycle from initial design through production monitoring, with a strong focus on security at every stage—embodying the DevSecOps philosophy of "shift left" security.
The API Security Crisis of 2025
According to API7.ai's 2025 security analysis, the landscape has shifted dramatically:
- 31% of APIs lack HTTPS encryption - Basic transport security still missing
- Shadow APIs proliferate - Undocumented endpoints exposing sensitive data
- Business logic flaws - Traditional tools miss BOLA (Broken Object Level Authorization) and IDOR vulnerabilities
- Credential stuffing attacks - Targeting authentication endpoints at scale
- API abuse - Rate limiting bypasses and resource exhaustion attacks
Why This Workflow Matters
Modern API security requires a zero-trust security model, assuming no user or system should be trusted by default. This workflow integrates:
- API Design & Requirements Gathering (1-2 days)
- Authentication & Authorization Architecture (2-3 days)
- API Development & Schema Validation (3-7 days)
- Security Testing & Vulnerability Scanning (2-4 days)
- Integration & Load Testing (1-3 days)
- Deployment & Rate Limiting Configuration (1-2 days)
- Production Monitoring & Continuous Testing (Ongoing)
Let's dive into each stage with practical techniques, security best practices, and tools aligned to the OWASP API Security Top 10 2023.
Stage 1: API Design & Requirements Gathering (1-2 days)
The design phase establishes your API's foundation—defining endpoints, data models, authentication requirements, and security boundaries. According to Postman's API-First Workflow, thinking about the API as one entity instead of treating code, definitions, and tests independently leads to better outcomes.
Step 1.1: Define API Purpose & Use Cases
Why: Clear requirements prevent scope creep and security oversights. Understanding who uses your API and how they use it drives authentication, authorization, and rate limiting decisions.
Key Questions:
- Audience: Internal microservices? Third-party developers? Public consumers?
- Data Sensitivity: PII, financial data, health records, or public information?
- Traffic Patterns: Expected request volume (requests/minute, daily peaks)?
- Compliance: GDPR, HIPAA, PCI-DSS, SOC 2 requirements?
Example Use Case Definition:
API: Customer Order Management API
Audience: Internal mobile app + partner integrations
Data: Customer PII, payment methods (PCI-DSS scope), order history
Traffic: 10,000 req/min peak, 2M requests/day
Compliance: PCI-DSS Level 1, GDPR (EU customers)
Step 1.2: Design RESTful Endpoints
Best Practices:
- Resource-oriented URLs:
/api/v1/customers/{id}/orders(not/api/v1/getCustomerOrders) - HTTP verb semantics: GET (read), POST (create), PUT/PATCH (update), DELETE (remove)
- Versioning: Include version in URL (
/v1/,/v2/) for backward compatibility - Pagination: Support
?limit=50&offset=100or cursor-based pagination - Filtering: Enable query parameters like
?status=active&created_after=2025-01-01
Security Considerations:
- Avoid exposing IDs: Use UUIDs instead of sequential integers to prevent enumeration
- Limit response size: Enforce maximum page sizes to prevent resource exhaustion
- No sensitive data in URLs: Never put passwords, tokens, or PII in query parameters (they're logged)
Tool: HTTP Request Builder Use our HTTP Request Builder to prototype API requests and test endpoint designs before writing code.
Step 1.3: Define Authentication & Authorization Requirements
Authentication Methods (Choose Based on Use Case):
| Method | Use Case | Security Level | Tool |
|---|---|---|---|
| OAuth 2.0 | Third-party integrations, delegated access | High | OAuth/OIDC Debugger |
| JWT (JSON Web Tokens) | Stateless microservices, mobile apps | High | JWT Decoder |
| API Keys | Server-to-server, simple integrations | Medium | Custom headers |
| mTLS (Mutual TLS) | Zero-trust environments, high security | Very High | Certificate-based |
According to Knowi's REST API authentication guide, OAuth 2.0 with short-lived access tokens and multi-factor authentication is the most secure approach for 2025.
Tool: OAuth/OIDC Debugger Use our OAuth/OIDC Debugger to test OAuth flows, validate JWT tokens, generate PKCE challenges, and troubleshoot authentication issues.
Step 1.4: Document API Specification (OpenAPI/Swagger)
Why: OpenAPI (formerly Swagger) specifications serve as a contract between API providers and consumers, enabling automated validation, documentation, and code generation.
OpenAPI 3.1 Example:
openapi: 3.1.0
info:
title: Customer Order API
version: 1.0.0
description: RESTful API for managing customer orders
servers:
- url: https://api.example.com/v1
paths:
/customers/{customerId}/orders:
get:
summary: Get customer orders
security:
- bearerAuth: []
parameters:
- name: customerId
in: path
required: true
schema:
type: string
format: uuid
- name: status
in: query
schema:
type: string
enum: [pending, shipped, delivered]
responses:
'200':
description: Order list
content:
application/json:
schema:
type: array
items:
$ref: '#/components/schemas/Order'
'401':
$ref: '#/components/responses/Unauthorized'
'429':
$ref: '#/components/responses/TooManyRequests'
components:
securitySchemes:
bearerAuth:
type: http
scheme: bearer
bearerFormat: JWT
schemas:
Order:
type: object
required: [orderId, customerId, status, total]
properties:
orderId:
type: string
format: uuid
customerId:
type: string
format: uuid
status:
type: string
enum: [pending, processing, shipped, delivered, cancelled]
total:
type: number
format: currency
items:
type: array
items:
$ref: '#/components/schemas/OrderItem'
responses:
Unauthorized:
description: Missing or invalid authentication token
content:
application/json:
schema:
type: object
properties:
error:
type: string
example: "Unauthorized: Invalid JWT token"
TooManyRequests:
description: Rate limit exceeded
headers:
X-RateLimit-Limit:
schema:
type: integer
description: Request limit per hour
X-RateLimit-Remaining:
schema:
type: integer
description: Remaining requests in window
Retry-After:
schema:
type: integer
description: Seconds until limit resets
content:
application/json:
schema:
type: object
properties:
error:
type: string
example: "Rate limit exceeded. Retry after 3600 seconds."
Key Security Elements:
- Security schemes defined (
bearerAuth) - Input validation (UUID format, enums)
- Error responses documented (401, 429)
- Rate limiting headers exposed
Tool: JSON Validator Use our JSON Validator to validate OpenAPI specifications and ensure schema correctness.
Step 1.5: Threat Modeling & Risk Assessment
OWASP API Security Top 10 2023 Coverage:
| Risk | Description | Mitigation Strategy |
|---|---|---|
| API1:2023 - Broken Object Level Authorization | Users can access objects they shouldn't | Validate user ownership of every object access |
| API2:2023 - Broken Authentication | Weak authentication mechanisms | OAuth 2.0 + JWT with short expiry |
| API3:2023 - Broken Object Property Level Authorization | Mass assignment vulnerabilities | Explicit allowlists for input fields |
| API4:2023 - Unrestricted Resource Consumption | No rate limiting, DoS potential | Rate limiting + quota enforcement |
| API5:2023 - Broken Function Level Authorization | Missing role checks | RBAC with least-privilege principle |
| API6:2023 - Unrestricted Access to Sensitive Business Flows | Business logic abuse | Workflow validation, anti-automation |
| API7:2023 - Server Side Request Forgery | API makes requests to internal resources | URL allowlisting, network segmentation |
| API8:2023 - Security Misconfiguration | Default credentials, verbose errors | Security hardening checklist |
| API9:2023 - Improper Inventory Management | Shadow APIs, deprecated endpoints | API discovery, documentation |
| API10:2023 - Unsafe Consumption of APIs | Trusting third-party API data | Validate all external inputs |
Threat Modeling Exercise:
Threat: Credential Stuffing Attack on /auth/login endpoint
Attack Vector: Automated login attempts using leaked credentials
Impact: Account takeover, data breach
Likelihood: High (common attack pattern)
Mitigation:
- Rate limit: 5 attempts per IP per hour
- CAPTCHA after 3 failed attempts
- Multi-factor authentication (MFA)
- Monitor for failed login spikes
Stage 1 Output:
After 1-2 days of design work, you should have:
- Clearly defined API use cases and requirements
- RESTful endpoint design with versioning
- Authentication/authorization strategy selected
- Complete OpenAPI 3.1 specification
- Threat model documenting top risks and mitigations
- Compliance requirements mapped to design
Time Investment: 1-2 days Next Step: Proceed to Stage 2 to implement authentication and authorization architecture.
Stage 2: Authentication & Authorization Architecture (2-3 days)
Authentication verifies who you are, while authorization determines what you can do. According to AestheteSoft's modern authentication guide, the most secure approach in 2025 combines OAuth 2.0 with short-lived access tokens and multi-factor authentication.
Step 2.1: Implement OAuth 2.0 Authorization Server
OAuth 2.0 Grant Types (Choose Based on Client Type):
| Grant Type | Use Case | Security Level |
|---|---|---|
| Authorization Code + PKCE | Web apps, mobile apps, SPAs | Highest (recommended) |
| Client Credentials | Server-to-server, microservices | High |
| Refresh Token | Long-lived sessions | High (with rotation) |
| Deprecated (insecure) | ||
| Deprecated (phishing risk) |
Authorization Code + PKCE Flow:
1. Client generates code_verifier (random 43-128 char string)
2. Client hashes code_verifier → code_challenge (SHA-256)
3. Client redirects user to authorization server:
GET /authorize?
response_type=code
&client_id=abc123
&redirect_uri=https://app.example.com/callback
&scope=read:orders write:orders
&state=xyz789
&code_challenge=HASH_OF_VERIFIER
&code_challenge_method=S256
4. User authenticates and consents
5. Authorization server redirects back:
GET /callback?code=AUTH_CODE&state=xyz789
6. Client exchanges code for token:
POST /token
{
"grant_type": "authorization_code",
"code": "AUTH_CODE",
"redirect_uri": "https://app.example.com/callback",
"client_id": "abc123",
"code_verifier": "ORIGINAL_VERIFIER"
}
7. Authorization server validates code_challenge and returns:
{
"access_token": "eyJhbGciOiJSUzI1NiIs...",
"token_type": "Bearer",
"expires_in": 3600,
"refresh_token": "def456",
"scope": "read:orders write:orders"
}
Security Best Practices:
- Always use PKCE - Even for confidential clients (prevents authorization code interception)
- Short-lived access tokens - 15 minutes to 1 hour maximum
- Refresh token rotation - Issue new refresh token on each use, invalidate old one
- State parameter - Random hash to prevent CSRF attacks
- Scope validation - Principle of least privilege
Tool: OAuth/OIDC Debugger Use our OAuth/OIDC Debugger to:
- Generate PKCE code challenge/verifier pairs
- Decode and validate access tokens
- Test authorization flows
- Troubleshoot common errors (invalid_grant, invalid_scope)
Step 2.2: JWT Token Design & Validation
JWT Structure:
Header.Payload.Signature
Header (Base64URL encoded):
{
"alg": "RS256",
"typ": "JWT",
"kid": "key-2025-01"
}
Payload (Base64URL encoded):
{
"iss": "https://auth.example.com",
"sub": "user-12345",
"aud": "api.example.com",
"exp": 1736278800,
"iat": 1736275200,
"scope": "read:orders write:orders",
"roles": ["customer"],
"email": "[email protected]"
}
Signature (RS256 with private key):
RSASHA256(base64UrlEncode(header) + "." + base64UrlEncode(payload), privateKey)
Critical JWT Security Practices (2025):
According to Curity's JWT best practices:
-
Use Strong Algorithms
- ✅ RS256 (RSA with SHA-256) - Asymmetric, recommended
- ✅ ES256 (ECDSA with SHA-256) - Asymmetric, efficient
- ❌ HS256 (HMAC with SHA-256) - Symmetric, shared secret risk
- ❌ None - Never accept unsigned tokens
-
Validate Everything
// Server-side validation (Node.js example) const jwt = require('jsonwebtoken'); const jwksClient = require('jwks-rsa'); const client = jwksClient({ jwksUri: 'https://auth.example.com/.well-known/jwks.json' }); function getKey(header, callback) { client.getSigningKey(header.kid, (err, key) => { const signingKey = key.publicKey || key.rsaPublicKey; callback(null, signingKey); }); } function validateToken(token) { return new Promise((resolve, reject) => { jwt.verify(token, getKey, { audience: 'api.example.com', issuer: 'https://auth.example.com', algorithms: ['RS256'] }, (err, decoded) => { if (err) reject(err); else resolve(decoded); }); }); } -
Never Store Sensitive Data in Tokens
- ❌ Passwords, credit cards, SSNs
- ❌ PII beyond what's necessary for authorization
- ✅ User ID, roles, scopes, email (non-sensitive identifier)
-
Short Expiration Times
- Access tokens: 15-60 minutes
- Refresh tokens: 7-30 days (with rotation)
- ID tokens: 5-10 minutes
-
Secure Storage
- Web apps: HttpOnly, Secure cookies (not localStorage)
- Mobile apps: Platform keychain (iOS Keychain, Android Keystore)
- SPAs: In-memory storage + refresh token in HttpOnly cookie
Tool: JWT Decoder Use our JWT Decoder to:
- Decode and inspect JWT tokens
- Validate signatures and claims
- Check expiration times
- Identify security issues (weak algorithms, expired tokens)
Tool: Base64 Encoder/Decoder Use our Base64 Encoder/Decoder to manually inspect JWT payload contents.
Step 2.3: Implement Role-Based Access Control (RBAC)
RBAC Hierarchy:
User → Roles → Permissions → Resources
Example:
user-12345 → ["customer"] → ["read:orders", "write:orders"] → /customers/12345/orders
admin-user → ["admin"] → ["*"] → /*
partner-api → ["partner"] → ["read:orders"] → /partners/ABC/customers/*/orders
Authorization Middleware (Express.js Example):
// middleware/authorization.js
function requirePermission(permission) {
return async (req, res, next) => {
try {
// Extract JWT from Authorization header
const token = req.headers.authorization?.split(' ')[1];
if (!token) {
return res.status(401).json({ error: 'Unauthorized: Missing token' });
}
// Validate JWT (from Step 2.2)
const decoded = await validateToken(token);
// Check if user has required permission
const userPermissions = decoded.scope.split(' ');
if (!userPermissions.includes(permission) && !userPermissions.includes('*')) {
return res.status(403).json({
error: 'Forbidden: Insufficient permissions',
required: permission,
granted: userPermissions
});
}
// Attach user info to request
req.user = decoded;
next();
} catch (error) {
return res.status(401).json({ error: 'Unauthorized: Invalid token' });
}
};
}
// Usage in routes
app.get('/customers/:id/orders',
requirePermission('read:orders'),
async (req, res) => {
// Additional BOLA check (OWASP API1:2023)
if (req.user.sub !== req.params.id && !req.user.roles.includes('admin')) {
return res.status(403).json({ error: 'Forbidden: Cannot access other users\' orders' });
}
// Fetch orders...
}
);
BOLA (Broken Object Level Authorization) Prevention:
According to Pynt's API security guide, BOLA is the #1 API vulnerability. Always validate object ownership:
// ❌ VULNERABLE: Only checks authentication
app.get('/orders/:orderId', authenticated, async (req, res) => {
const order = await db.getOrder(req.params.orderId);
res.json(order); // Returns ANY order, even if not owned by user
});
// ✅ SECURE: Validates ownership
app.get('/orders/:orderId', authenticated, async (req, res) => {
const order = await db.getOrder(req.params.orderId);
if (order.customerId !== req.user.sub && !req.user.roles.includes('admin')) {
return res.status(403).json({ error: 'Forbidden: Order not found' });
}
res.json(order);
});
Step 2.4: API Key Management (For Server-to-Server)
API Key Best Practices:
-
Generate Cryptographically Random Keys
# 32-byte key, Base64 URL-safe encoded openssl rand -base64 32 | tr -d "=+/" | cut -c1-43 -
Rotate Keys Regularly
- Minimum: Every 90 days
- After security incidents
- When team members leave
- Automate rotation to minimize human error
-
Scope Keys to Specific Resources
{ "api_key": "ak_live_7Fn8kJHG9KLp2mN4o5P6q7R8s9T0u1V2", "name": "Partner XYZ Integration", "scopes": ["read:orders"], "rate_limit": "1000/hour", "allowed_ips": ["203.0.113.0/24"], "created_at": "2025-01-07T10:00:00Z", "expires_at": "2025-04-07T10:00:00Z" } -
Never Log API Keys
// ❌ BAD: Logs full API key logger.info(`Request from API key: ${req.headers['x-api-key']}`); // ✅ GOOD: Logs only last 4 characters const apiKey = req.headers['x-api-key']; const maskedKey = `****${apiKey.slice(-4)}`; logger.info(`Request from API key: ${maskedKey}`);
Tool: Hash Generator Use our Hash Generator to securely hash API keys for database storage.
Step 2.5: Multi-Factor Authentication (MFA)
MFA Implementation:
- TOTP (Time-Based One-Time Password): Google Authenticator, Authy
- SMS/Email OTP: Fallback option (less secure due to SIM swapping)
- WebAuthn/FIDO2: Hardware keys (YubiKey) - most secure
- Push notifications: Duo, Okta Verify
MFA Flow:
1. User provides username + password → Primary authentication
2. System generates MFA challenge → Send TOTP code request
3. User provides TOTP code → Verify against shared secret
4. If valid → Issue access token with mfa_verified claim
Stage 2 Output:
After 2-3 days, you should have:
- OAuth 2.0 authorization server configured
- JWT token generation and validation implemented
- RBAC with permission-based authorization
- API key management system (if applicable)
- MFA integration (optional but recommended)
- BOLA prevention in all object access endpoints
Time Investment: 2-3 days Next Step: Proceed to Stage 3 for API development and schema validation.
Stage 3: API Development & Schema Validation (3-7 days)
With authentication and authorization in place, you can now build API endpoints with confidence that only authorized users can access protected resources.
Step 3.1: Input Validation & Sanitization
Why: According to the OWASP API Security Top 10, API3:2023 - Broken Object Property Level Authorization (mass assignment) and API10:2023 - Unsafe Consumption of APIs both stem from insufficient input validation.
Validation Layers:
- Schema Validation (OpenAPI Spec)
- Type Checking (TypeScript, Pydantic, Joi)
- Business Logic Validation
- Sanitization (SQL injection, XSS prevention)
Example: Express.js + Joi Validation
const Joi = require('joi');
// Define validation schema
const createOrderSchema = Joi.object({
customerId: Joi.string().uuid().required(),
items: Joi.array().items(
Joi.object({
productId: Joi.string().uuid().required(),
quantity: Joi.number().integer().min(1).max(100).required(),
price: Joi.number().positive().precision(2).required()
})
).min(1).max(50).required(), // Prevent resource exhaustion
shippingAddress: Joi.object({
street: Joi.string().max(200).required(),
city: Joi.string().max(100).required(),
state: Joi.string().length(2).uppercase().required(),
zipCode: Joi.string().pattern(/^\d{5}(-\d{4})?$/).required()
}).required(),
paymentMethod: Joi.string().valid('credit_card', 'paypal', 'bank_transfer').required()
});
// Validation middleware
function validate(schema) {
return (req, res, next) => {
const { error, value } = schema.validate(req.body, {
abortEarly: false, // Return all errors
stripUnknown: true // Remove unknown fields (prevent mass assignment)
});
if (error) {
const errors = error.details.map(detail => ({
field: detail.path.join('.'),
message: detail.message
}));
return res.status(400).json({
error: 'Validation failed',
details: errors
});
}
req.validatedBody = value;
next();
};
}
// Usage
app.post('/orders',
requirePermission('write:orders'),
validate(createOrderSchema),
async (req, res) => {
// req.validatedBody contains only validated fields
const order = await createOrder(req.validatedBody);
res.status(201).json(order);
}
);
Mass Assignment Prevention:
// ❌ VULNERABLE: Accepts any field from request body
app.patch('/users/:id', async (req, res) => {
await db.users.update(req.params.id, req.body);
// Attacker could send: { "role": "admin", "isVerified": true }
});
// ✅ SECURE: Explicit allowlist of updatable fields
const updateUserSchema = Joi.object({
firstName: Joi.string().max(100),
lastName: Joi.string().max(100),
email: Joi.string().email()
// role, isVerified NOT allowed
}).min(1); // At least one field required
app.patch('/users/:id',
requirePermission('write:profile'),
validate(updateUserSchema),
async (req, res) => {
// Only firstName, lastName, email can be updated
await db.users.update(req.params.id, req.validatedBody);
}
);
Tool: JSON Validator Use our JSON Validator to test request payloads against JSON Schema definitions during development.
Step 3.2: Implement Rate Limiting & Throttling
Why: OWASP API4:2023 - Unrestricted Resource Consumption and DoS prevention require rate limiting. According to API7.ai's rate limiting guide, rate limiting restricts the number of requests, while throttling slows down excessive traffic.
Rate Limiting Strategies:
| Algorithm | Use Case | Pros | Cons |
|---|---|---|---|
| Fixed Window | Simple APIs, low traffic | Easy to implement | Traffic spikes at window reset |
| Sliding Window | General purpose | Smooth rate limiting | More memory overhead |
| Token Bucket | Burst-tolerant APIs | Allows traffic bursts | Complex configuration |
| Leaky Bucket | Consistent rate enforcement | Smooth traffic flow | Rejects bursts |
Implementation: Express Rate Limit Middleware
const rateLimit = require('express-rate-limit');
const RedisStore = require('rate-limit-redis');
const Redis = require('ioredis');
const redisClient = new Redis({
host: process.env.REDIS_HOST,
port: 6379
});
// Global rate limit: 1000 requests per hour per IP
const globalLimiter = rateLimit({
store: new RedisStore({
client: redisClient,
prefix: 'rl:global:'
}),
windowMs: 60 * 60 * 1000, // 1 hour
max: 1000,
message: {
error: 'Too many requests from this IP, please try again later.',
retryAfter: '3600 seconds'
},
standardHeaders: true, // Return rate limit info in headers
legacyHeaders: false,
handler: (req, res) => {
res.status(429).json({
error: 'Rate limit exceeded',
limit: req.rateLimit.limit,
remaining: req.rateLimit.remaining,
resetTime: new Date(req.rateLimit.resetTime).toISOString()
});
}
});
// Stricter limit for authentication endpoints (prevent credential stuffing)
const authLimiter = rateLimit({
store: new RedisStore({
client: redisClient,
prefix: 'rl:auth:'
}),
windowMs: 60 * 60 * 1000, // 1 hour
max: 5, // Only 5 login attempts per hour
skipSuccessfulRequests: true, // Don't count successful logins
message: {
error: 'Too many failed login attempts. Please try again in 1 hour.',
retryAfter: '3600 seconds'
}
});
// Per-user rate limit (based on authenticated user)
const userLimiter = rateLimit({
store: new RedisStore({
client: redisClient,
prefix: 'rl:user:'
}),
windowMs: 60 * 60 * 1000,
max: 10000, // Authenticated users get higher limits
keyGenerator: (req) => req.user?.sub || req.ip, // Use user ID or fall back to IP
});
// Apply rate limiters
app.use('/api/', globalLimiter);
app.post('/auth/login', authLimiter, loginHandler);
app.use('/api/', requirePermission('*'), userLimiter);
Rate Limit Response Headers:
HTTP/1.1 429 Too Many Requests
X-RateLimit-Limit: 1000
X-RateLimit-Remaining: 0
X-RateLimit-Reset: 1736278800
Retry-After: 3600
{
"error": "Rate limit exceeded",
"limit": 1000,
"remaining": 0,
"resetTime": "2025-01-07T12:00:00Z"
}
Tool: Rate Limit Calculator Use our Rate Limit Calculator to:
- Model API throttling budgets
- Calculate optimal per-client limits
- Estimate queue depth for different limits
- Avoid 429 errors in production
Step 3.3: Error Handling & Logging
Security-Conscious Error Responses:
// ❌ INSECURE: Exposes internal details
app.get('/users/:id', async (req, res) => {
try {
const user = await db.query('SELECT * FROM users WHERE id = $1', [req.params.id]);
res.json(user);
} catch (error) {
res.status(500).json({
error: error.message, // "relation 'users' does not exist"
stack: error.stack // Full stack trace with file paths
});
}
});
// ✅ SECURE: Generic error messages to users, detailed logging internally
app.get('/users/:id', async (req, res) => {
try {
const user = await db.query('SELECT * FROM users WHERE id = $1', [req.params.id]);
if (!user) {
return res.status(404).json({
error: 'User not found'
});
}
res.json(user);
} catch (error) {
// Log full error details internally
logger.error('Database error in GET /users/:id', {
errorMessage: error.message,
errorStack: error.stack,
userId: req.params.id,
requestId: req.id
});
// Return generic error to user
res.status(500).json({
error: 'Internal server error',
requestId: req.id // For support troubleshooting
});
}
});
Structured Logging (JSON Format):
const winston = require('winston');
const logger = winston.createLogger({
level: 'info',
format: winston.format.json(),
defaultMeta: { service: 'order-api' },
transports: [
new winston.transports.File({ filename: 'error.log', level: 'error' }),
new winston.transports.File({ filename: 'combined.log' })
]
});
// Log API requests
app.use((req, res, next) => {
const start = Date.now();
res.on('finish', () => {
const duration = Date.now() - start;
logger.info('API request', {
method: req.method,
path: req.path,
statusCode: res.statusCode,
durationMs: duration,
userId: req.user?.sub,
ip: req.ip,
userAgent: req.headers['user-agent']
});
});
next();
});
Tool: JSON Formatter Use our JSON Formatter to parse and analyze structured JSON logs during debugging.
Tool: Regex Tester Use our Regex Tester to extract patterns from logs (e.g., error messages, request IDs).
Step 3.4: Data Serialization & Response Filtering
Prevent Data Leakage:
// ❌ INSECURE: Exposes all database fields
app.get('/users/:id', async (req, res) => {
const user = await db.users.findById(req.params.id);
res.json(user);
// Returns: { id, email, passwordHash, creditCardLast4, ssn, ... }
});
// ✅ SECURE: Explicit response serialization
class UserSerializer {
static toPublic(user) {
return {
id: user.id,
firstName: user.firstName,
lastName: user.lastName,
email: user.email,
createdAt: user.createdAt
// passwordHash, ssn, creditCardLast4 NOT included
};
}
static toAdmin(user) {
return {
...this.toPublic(user),
lastLoginAt: user.lastLoginAt,
ipAddress: user.lastLoginIp,
accountStatus: user.status
// Still no passwordHash or sensitive PII
};
}
}
app.get('/users/:id', async (req, res) => {
const user = await db.users.findById(req.params.id);
if (req.user.roles.includes('admin')) {
res.json(UserSerializer.toAdmin(user));
} else {
res.json(UserSerializer.toPublic(user));
}
});
Step 3.5: API Versioning Strategy
Versioning Approaches:
| Method | Example | Pros | Cons |
|---|---|---|---|
| URL Path | /v1/orders, /v2/orders | Clear, easy to route | URL pollution |
| Header | Accept: application/vnd.api+json; version=2 | Clean URLs | Less discoverable |
| Query Param | /orders?version=2 | Flexible | Can be forgotten |
Recommended: URL Path Versioning
// v1/orders.js
router.get('/v1/orders/:id', async (req, res) => {
const order = await db.orders.findById(req.params.id);
res.json({
id: order.id,
status: order.status,
total: order.totalAmount // Old field name
});
});
// v2/orders.js (Breaking change: renamed totalAmount → total)
router.get('/v2/orders/:id', async (req, res) => {
const order = await db.orders.findById(req.params.id);
res.json({
id: order.id,
status: order.status,
total: order.totalAmount,
currency: order.currency, // New field
items: order.items // New field
});
});
Deprecation Process:
- Announce deprecation 6-12 months in advance
- Add
Deprecationheader to responses - Monitor v1 usage metrics
- Provide migration guide
- Sunset v1 after grace period
HTTP/1.1 200 OK
Deprecation: true
Sunset: Wed, 01 Jul 2025 00:00:00 GMT
Link: <https://api.example.com/docs/v1-to-v2-migration>; rel="deprecation"
Stage 3 Output:
After 3-7 days, you should have:
- Schema validation on all endpoints (Joi, JSON Schema)
- Rate limiting configured (global, per-endpoint, per-user)
- Secure error handling (generic external, detailed internal)
- Structured logging (JSON format with context)
- Response serialization preventing data leakage
- API versioning strategy implemented
Time Investment: 3-7 days Next Step: Proceed to Stage 4 for security testing and vulnerability scanning.
Stage 4: Security Testing & Vulnerability Scanning (2-4 days)
With your API built, it's time for comprehensive security testing. According to Pynt's API security testing guide, combining DAST results with manual penetration testing provides the most comprehensive coverage.
Step 4.1: Automated Security Scanning (DAST)
Dynamic Application Security Testing (DAST) Tools:
| Tool | Use Case | Strengths |
|---|---|---|
| OWASP ZAP | Open-source, general-purpose | Free, extensive, active community |
| Burp Suite | Professional penetration testing | Deep inspection, manual testing |
| Postman | API testing with security checks | Developer-friendly, CI/CD integration |
| Nuclei | Template-based vulnerability scanning | Fast, customizable templates |
OWASP ZAP Automated Scan:
# Docker-based automated scan
docker run -v $(pwd):/zap/wrk/:rw \
-t ghcr.io/zaproxy/zaproxy:stable \
zap-api-scan.py \
-t https://api.example.com/openapi.json \
-f openapi \
-r zap-report.html
# Scan includes:
# - SQL injection
# - XSS (cross-site scripting)
# - Authentication bypass
# - CSRF (cross-site request forgery)
# - Directory traversal
# - XXE (XML external entity)
Postman Security Testing:
// Collection pre-request script: Generate JWT for authenticated tests
const jwtToken = pm.collectionVariables.get('jwt_token');
if (!jwtToken) {
pm.sendRequest({
url: 'https://api.example.com/auth/login',
method: 'POST',
header: { 'Content-Type': 'application/json' },
body: {
mode: 'raw',
raw: JSON.stringify({
username: pm.environment.get('test_username'),
password: pm.environment.get('test_password')
})
}
}, (err, res) => {
pm.collectionVariables.set('jwt_token', res.json().access_token);
});
}
// Test: BOLA vulnerability check
pm.test('BOLA: Cannot access other users\' orders', () => {
pm.sendRequest({
url: 'https://api.example.com/v1/orders/other-user-order-id',
method: 'GET',
header: {
'Authorization': `Bearer ${pm.collectionVariables.get('jwt_token')}`
}
}, (err, res) => {
pm.expect(res.code).to.be.oneOf([403, 404]); // Should NOT return 200
});
});
// Test: Mass assignment vulnerability
pm.test('Mass Assignment: Cannot elevate privileges', () => {
pm.sendRequest({
url: 'https://api.example.com/v1/users/me',
method: 'PATCH',
header: {
'Authorization': `Bearer ${pm.collectionVariables.get('jwt_token')}`,
'Content-Type': 'application/json'
},
body: {
mode: 'raw',
raw: JSON.stringify({
firstName: 'John',
role: 'admin' // Attempt privilege escalation
})
}
}, (err, res) => {
pm.expect(res.code).to.be.oneOf([400, 403]); // Should reject
const user = res.json();
pm.expect(user.role).to.not.equal('admin');
});
});
// Test: SQL injection
pm.test('SQL Injection: Properly sanitizes input', () => {
pm.sendRequest({
url: 'https://api.example.com/v1/orders?status=delivered\' OR \'1\'=\'1',
method: 'GET',
header: {
'Authorization': `Bearer ${pm.collectionVariables.get('jwt_token')}`
}
}, (err, res) => {
pm.expect(res.code).to.be.oneOf([400, 200]); // Should handle gracefully
if (res.code === 200) {
// Should not return all orders (SQL injection would bypass status filter)
const orders = res.json();
orders.forEach(order => {
pm.expect(order.status).to.equal('delivered');
});
}
});
});
Step 4.2: Authentication & Authorization Testing
JWT Security Tests:
Tool: JWT Decoder Use our JWT Decoder to validate JWT tokens during testing.
# Test 1: None algorithm attack
# Try to bypass signature verification by changing algorithm to "none"
curl -X GET https://api.example.com/v1/orders \
-H "Authorization: Bearer eyJhbGciOiJub25lIiwidHlwIjoiSldUIn0.eyJzdWIiOiJ1c2VyLTEyMyIsInJvbGUiOiJhZG1pbiJ9."
# Expected: 401 Unauthorized (server must reject "none" algorithm)
# Test 2: Expired token
curl -X GET https://api.example.com/v1/orders \
-H "Authorization: Bearer <expired_token>"
# Expected: 401 Unauthorized with error "Token expired"
# Test 3: Tampered payload
# Modify JWT payload (change user ID) without valid signature
curl -X GET https://api.example.com/v1/orders \
-H "Authorization: Bearer <tampered_token>"
# Expected: 401 Unauthorized with error "Invalid signature"
# Test 4: Missing required claims
curl -X GET https://api.example.com/v1/orders \
-H "Authorization: Bearer <token_missing_exp>"
# Expected: 401 Unauthorized
OAuth Flow Testing:
Tool: OAuth/OIDC Debugger Use our OAuth/OIDC Debugger to test OAuth flows and troubleshoot authentication issues.
# Test 1: CSRF attack (missing or invalid state parameter)
GET /authorize?
response_type=code
&client_id=abc123
&redirect_uri=https://attacker.com/callback
&state=<missing_or_predictable>
# Expected: Reject or generate unpredictable state
# Test 2: Redirect URI manipulation
GET /authorize?
response_type=code
&client_id=abc123
&redirect_uri=https://attacker.com/steal-code
# Expected: Reject (redirect_uri must match registered URI)
# Test 3: PKCE bypass attempt
POST /token
{
"grant_type": "authorization_code",
"code": "AUTH_CODE",
"redirect_uri": "https://app.example.com/callback",
"client_id": "abc123"
// Missing code_verifier - attempt to bypass PKCE
}
# Expected: 400 Bad Request "code_verifier required"
Step 4.3: Input Validation & Injection Testing
SQL Injection Tests:
# Test 1: Classic SQL injection
curl -X GET "https://api.example.com/v1/[email protected]' OR '1'='1"
# Expected: 400 Bad Request or sanitized query
# Test 2: Union-based injection
curl -X GET "https://api.example.com/v1/products?id=1 UNION SELECT password FROM users--"
# Expected: 400 Bad Request
# Test 3: Blind SQL injection
curl -X GET "https://api.example.com/v1/orders?id=1 AND SLEEP(10)--"
# Expected: Response within normal time (<1s), not delayed 10 seconds
NoSQL Injection (MongoDB):
# Test: NoSQL injection via JSON
curl -X POST https://api.example.com/auth/login \
-H "Content-Type: application/json" \
-d '{
"username": {"$ne": null},
"password": {"$ne": null}
}'
# Expected: 400 Bad Request (reject non-string values)
XSS (Cross-Site Scripting):
# Test: Stored XSS
curl -X POST https://api.example.com/v1/comments \
-H "Authorization: Bearer <token>" \
-H "Content-Type: application/json" \
-d '{
"text": "<script>alert(\"XSS\")</script>"
}'
# Expected: 400 Bad Request or sanitized storage
# Verify: Retrieve comment
curl -X GET https://api.example.com/v1/comments/123
# Expected: Script tags escaped or removed in response
Tool: HTML Entity Encoder Use our HTML Entity Encoder to test XSS prevention and verify output encoding.
Step 4.4: Rate Limiting & DoS Testing
Rate Limit Bypass Attempts:
# Test 1: IP rotation bypass
for i in {1..100}; do
curl -X POST https://api.example.com/auth/login \
-H "X-Forwarded-For: 192.0.2.$i" \
-d '{"username":"test","password":"wrong"}'
done
# Expected: Server must use actual IP, not X-Forwarded-For (unless behind trusted proxy)
# Test 2: Rate limit header verification
curl -X GET https://api.example.com/v1/orders -i
# Expected response headers:
# X-RateLimit-Limit: 1000
# X-RateLimit-Remaining: 999
# X-RateLimit-Reset: 1736278800
# Test 3: Excessive requests trigger 429
for i in {1..1001}; do
curl -X GET https://api.example.com/v1/orders \
-H "Authorization: Bearer <token>"
done
# Expected: Request 1001 returns 429 Too Many Requests
Resource Exhaustion Tests:
# Test 1: Large payload upload
dd if=/dev/zero of=largefile.bin bs=1M count=1000 # 1GB file
curl -X POST https://api.example.com/v1/uploads \
-H "Authorization: Bearer <token>" \
-F "[email protected]"
# Expected: 413 Payload Too Large (server enforces size limit)
# Test 2: Pagination limit bypass
curl -X GET "https://api.example.com/v1/orders?limit=999999"
# Expected: Enforce max limit (e.g., 100), return 400 or capped results
# Test 3: Nested JSON depth attack
curl -X POST https://api.example.com/v1/data \
-H "Content-Type: application/json" \
-d '{"a":{"a":{"a":{"a":...}}}}}' # Deeply nested 1000+ levels
# Expected: 400 Bad Request (reject excessive nesting depth)
Step 4.5: HTTPS & TLS Configuration Testing
SSL/TLS Security Checks:
Tool: SSL Checker Use our SSL Checker tool to verify certificate chains, protocol support, and configuration issues.
# Test with Qualys SSL Labs
curl "https://api.ssllabs.com/api/v3/analyze?host=api.example.com"
# Expected Results:
# ✅ Grade: A or A+
# ✅ Certificate: Valid, not expired, proper chain
# ✅ Protocols: TLS 1.2, TLS 1.3 enabled
# ❌ Protocols: SSLv2, SSLv3, TLS 1.0, TLS 1.1 disabled
# ✅ Cipher Suites: Strong ciphers only (AES-GCM, ChaCha20)
# ❌ Cipher Suites: Weak ciphers disabled (RC4, 3DES, CBC)
# ✅ HSTS: Enabled with max-age ≥ 31536000
# ✅ Certificate Transparency: CT logs present
Tool: X.509 Certificate Decoder Use our X.509 Certificate Decoder to analyze SSL/TLS certificates.
Tool: Certificate CSR Generator Use our Certificate CSR Generator to generate CSRs and convert between certificate formats.
HTTP Security Headers:
Tool: Security Headers Analyzer Use our Security Headers Analyzer to test HTTP security headers and get security scores.
curl -I https://api.example.com/v1/orders
# Expected Headers:
Strict-Transport-Security: max-age=31536000; includeSubDomains; preload
X-Content-Type-Options: nosniff
X-Frame-Options: DENY
X-XSS-Protection: 1; mode=block
Content-Security-Policy: default-src 'none'
Referrer-Policy: no-referrer
Permissions-Policy: geolocation=(), microphone=(), camera=()
Tool: CSP Policy Generator Use our CSP Policy Generator to generate Content Security Policy headers with nonce/hash support.
Stage 4 Output:
After 2-4 days of security testing, you should have:
- DAST scan completed (OWASP ZAP, Burp Suite)
- Authentication vulnerabilities tested (JWT, OAuth)
- Input validation verified (SQL injection, XSS, NoSQL injection)
- Rate limiting and DoS protections validated
- HTTPS/TLS configuration assessed (A+ grade)
- Security headers configured and tested
- Vulnerability report with remediation plan
Time Investment: 2-4 days Next Step: Proceed to Stage 5 for integration and load testing.
Stage 5: Integration & Load Testing (1-3 days)
After security testing, validate that your API performs reliably under real-world conditions and integrates correctly with downstream systems.
Step 5.1: End-to-End Integration Testing
Why: According to Postman's API testing guide, end-to-end tests validate key user journeys that may involve multiple endpoints and APIs.
Example: Order Placement Flow
// Postman Collection: E2E - Order Placement
pm.test('E2E: Complete order placement flow', async () => {
// Step 1: Authenticate user
const authResponse = await pm.sendRequest({
url: 'https://api.example.com/auth/login',
method: 'POST',
body: {
mode: 'raw',
raw: JSON.stringify({
username: '[email protected]',
password: 'TestPass123!'
})
}
});
pm.expect(authResponse.code).to.equal(200);
const token = authResponse.json().access_token;
// Step 2: Get user profile
const profileResponse = await pm.sendRequest({
url: 'https://api.example.com/v1/users/me',
method: 'GET',
header: { 'Authorization': `Bearer ${token}` }
});
pm.expect(profileResponse.code).to.equal(200);
const customerId = profileResponse.json().id;
// Step 3: Add items to cart
const cartResponse = await pm.sendRequest({
url: `https://api.example.com/v1/customers/${customerId}/cart`,
method: 'POST',
header: {
'Authorization': `Bearer ${token}`,
'Content-Type': 'application/json'
},
body: {
mode: 'raw',
raw: JSON.stringify({
items: [
{ productId: 'prod-123', quantity: 2 },
{ productId: 'prod-456', quantity: 1 }
]
})
}
});
pm.expect(cartResponse.code).to.equal(201);
const cartId = cartResponse.json().id;
// Step 4: Create order
const orderResponse = await pm.sendRequest({
url: `https://api.example.com/v1/customers/${customerId}/orders`,
method: 'POST',
header: {
'Authorization': `Bearer ${token}`,
'Content-Type': 'application/json'
},
body: {
mode: 'raw',
raw: JSON.stringify({
cartId: cartId,
shippingAddress: {
street: '123 Main St',
city: 'San Francisco',
state: 'CA',
zipCode: '94102'
},
paymentMethod: 'credit_card'
})
}
});
pm.expect(orderResponse.code).to.equal(201);
const orderId = orderResponse.json().id;
// Step 5: Verify order status
const statusResponse = await pm.sendRequest({
url: `https://api.example.com/v1/orders/${orderId}`,
method: 'GET',
header: { 'Authorization': `Bearer ${token}` }
});
pm.expect(statusResponse.code).to.equal(200);
pm.expect(statusResponse.json().status).to.equal('pending');
// Step 6: Verify inventory decremented (downstream system check)
const inventoryResponse = await pm.sendRequest({
url: 'https://api.example.com/v1/products/prod-123',
method: 'GET',
header: { 'Authorization': `Bearer ${token}` }
});
pm.expect(inventoryResponse.code).to.equal(200);
pm.expect(inventoryResponse.json().inventory).to.be.below(100); // Verify stock updated
});
Webhook Integration Testing:
Tool: Webhook Tester & Inspector Use our Webhook Tester & Inspector to:
- Generate temporary webhook endpoints
- Capture payloads from your API
- Validate webhook signatures (HMAC-SHA256)
- Test webhook retry logic
Example Webhook Test:
// 1. Generate webhook endpoint in Webhook Tester
const webhookUrl = 'https://webhook.site/unique-id';
// 2. Configure webhook in your API
await pm.sendRequest({
url: 'https://api.example.com/v1/webhooks',
method: 'POST',
header: {
'Authorization': `Bearer ${token}`,
'Content-Type': 'application/json'
},
body: {
mode: 'raw',
raw: JSON.stringify({
url: webhookUrl,
events: ['order.created', 'order.shipped'],
secret: 'webhook_secret_123'
})
}
});
// 3. Trigger event (create order)
await pm.sendRequest({
url: 'https://api.example.com/v1/orders',
method: 'POST',
// ... order data
});
// 4. Verify webhook payload received
// (Check Webhook Tester UI for received payload)
Tool: Webhook Payload Generator Use our Webhook Payload Generator to generate webhook payloads with HMAC signatures for testing webhook consumers.
Step 5.2: Performance & Load Testing
Why: BlazeMeter's continuous API testing guide emphasizes that performance testing confirms APIs can operate reliably during peak traffic.
Load Testing Tools:
- Apache JMeter - Industry standard, GUI-based
- k6 - Modern, developer-friendly, scripting in JavaScript
- Artillery - YAML-based configuration, CI/CD integration
- Gatling - Scala-based, detailed reporting
Example: k6 Load Test
// load-test.js
import http from 'k6/http';
import { check, sleep } from 'k6';
export let options = {
stages: [
{ duration: '2m', target: 100 }, // Ramp up to 100 users
{ duration: '5m', target: 100 }, // Stay at 100 users
{ duration: '2m', target: 200 }, // Ramp up to 200 users
{ duration: '5m', target: 200 }, // Stay at 200 users
{ duration: '2m', target: 0 }, // Ramp down to 0 users
],
thresholds: {
'http_req_duration': ['p(95)<500'], // 95% of requests < 500ms
'http_req_failed': ['rate<0.01'], // Error rate < 1%
},
};
export default function () {
// Authenticate
const loginRes = http.post('https://api.example.com/auth/login', JSON.stringify({
username: '[email protected]',
password: 'LoadTest123!'
}), {
headers: { 'Content-Type': 'application/json' },
});
check(loginRes, {
'login successful': (r) => r.status === 200,
});
const token = loginRes.json('access_token');
// Get orders (most common operation)
const ordersRes = http.get('https://api.example.com/v1/orders', {
headers: { 'Authorization': `Bearer ${token}` },
});
check(ordersRes, {
'orders retrieved': (r) => r.status === 200,
'response time OK': (r) => r.timings.duration < 500,
});
sleep(1); // Think time between requests
}
Run Load Test:
k6 run --vus 100 --duration 10m load-test.js
# Output:
# scenarios: (100.00%) 1 scenario, 200 max VUs, 16m30s max duration
#
# ✓ login successful
# ✓ orders retrieved
# ✓ response time OK
#
# http_req_duration..............: avg=245ms min=120ms med=230ms max=890ms p(95)=450ms p(99)=720ms
# http_req_failed................: 0.23% ✓ 45 ✗ 19855
# http_reqs......................: 19900 33.16/s
# iteration_duration.............: avg=1.5s min=1.2s med=1.4s max=2.8s
Performance Metrics to Track:
| Metric | Target | Tool |
|---|---|---|
| Response Time (p95) | < 500ms | k6, JMeter |
| Response Time (p99) | < 1000ms | k6, JMeter |
| Error Rate | < 1% | k6, monitoring |
| Throughput | > 1000 req/s | k6, JMeter |
| Concurrent Users | 500+ | k6, JMeter |
Tool: Network Latency Calculator Use our Network Latency Calculator to calculate network latency, ping distance, and data transfer times between locations.
Tool: TCP Window Size Calculator Use our TCP Window Size Calculator to calculate optimal TCP window sizes and buffer configurations for WAN optimization.
Step 5.3: API Contract Testing
Why: Prevent breaking changes by validating API responses against OpenAPI spec.
Tools:
- Dredd - HTTP API testing framework
- Prism - Mock server and contract validation
- Pact - Consumer-driven contract testing
Example: Dredd Contract Test
# Install Dredd
npm install -g dredd
# Run contract tests
dredd openapi.yaml https://api.example.com
# Output:
# pass: GET /v1/orders duration: 245ms
# pass: POST /v1/orders duration: 312ms
# fail: GET /v1/orders/{id} duration: 189ms
# Expected status code 200, got 500
# Response body does not match schema
Step 5.4: Chaos Engineering (Optional)
Test resilience to failures:
# Test 1: Database failure
# Simulate database connection loss
systemctl stop postgresql
curl -X GET https://api.example.com/v1/orders
# Expected: 503 Service Unavailable with retry-after header
# Test 2: Slow network
# Introduce 2-second latency
tc qdisc add dev eth0 root netem delay 2000ms
curl -X GET https://api.example.com/v1/orders
# Expected: Response within timeout, or graceful timeout error
# Test 3: Downstream service failure
# Mock third-party API returns 500 errors
# Expected: Circuit breaker opens, fallback response, or degraded mode
Stage 5 Output:
After 1-3 days, you should have:
- End-to-end integration tests passing (Postman collections)
- Webhook integration verified (delivery, signatures, retries)
- Load test results (p95 < 500ms, error rate < 1%)
- Contract tests validating OpenAPI compliance
- Chaos testing (optional) validating resilience
Time Investment: 1-3 days Next Step: Proceed to Stage 6 for deployment and rate limiting configuration.
Stage 6: Deployment & Rate Limiting Configuration (1-2 days)
With testing complete, deploy your API to production with proper security controls, monitoring, and rate limiting.
Step 6.1: Production Deployment Checklist
Pre-Deployment Security Checklist:
☐ Environment Variables
☐ No hardcoded secrets in code
☐ Database credentials in secret manager (AWS Secrets Manager, HashiCorp Vault)
☐ API keys rotated from staging
☐ JWT signing keys generated with cryptographically secure random
☐ HTTPS/TLS Configuration
☐ Valid SSL certificate installed
☐ TLS 1.2+ only (TLS 1.0, 1.1 disabled)
☐ Strong cipher suites enabled
☐ HSTS header configured (max-age=31536000)
☐ Certificate expiration monitoring (alert 30 days before)
☐ API Gateway Configuration
☐ Rate limiting enabled (global, per-endpoint, per-user)
☐ Request size limits enforced (max 10MB)
☐ Timeout limits set (30 seconds max)
☐ CORS policy configured (allowlist trusted origins)
☐ API keys rotated for production
☐ Database Security
☐ Database firewall rules (allowlist API servers only)
☐ Read-only database user for read endpoints
☐ Write database user with minimal permissions
☐ Prepared statements (prevent SQL injection)
☐ Connection pooling configured
☐ Logging & Monitoring
☐ Structured logging enabled (JSON format)
☐ Sensitive data excluded from logs (passwords, tokens, PII)
☐ Log aggregation configured (CloudWatch, Datadog, Splunk)
☐ Error alerting configured (PagerDuty, Opsgenie)
☐ Uptime monitoring (Pingdom, UptimeRobot)
☐ Security Headers
☐ Strict-Transport-Security
☐ X-Content-Type-Options: nosniff
☐ X-Frame-Options: DENY
☐ Content-Security-Policy
☐ Referrer-Policy: no-referrer
☐ Documentation
☐ API documentation published (Swagger UI, Redoc)
☐ Rate limits documented
☐ Authentication guide published
☐ Error response reference
☐ Changelog maintained
Step 6.2: Rate Limiting Strategy for Production
Tiered Rate Limits:
According to Cloudflare's rate limiting best practices, implement graduated limits based on user tier and endpoint sensitivity.
// Rate limit configuration
const rateLimits = {
// Public endpoints (no authentication)
public: {
windowMs: 60 * 60 * 1000, // 1 hour
max: 100, // 100 requests per hour per IP
endpoints: ['/health', '/docs', '/openapi.json']
},
// Authentication endpoints (prevent credential stuffing)
auth: {
windowMs: 60 * 60 * 1000, // 1 hour
max: 5, // 5 attempts per hour per IP
endpoints: ['/auth/login', '/auth/register', '/auth/reset-password']
},
// Free tier users
free: {
windowMs: 60 * 60 * 1000, // 1 hour
max: 1000, // 1,000 requests per hour
burstMax: 50, // Max 50 requests per minute
endpoints: ['*']
},
// Paid tier users
paid: {
windowMs: 60 * 60 * 1000, // 1 hour
max: 10000, // 10,000 requests per hour
burstMax: 500, // Max 500 requests per minute
endpoints: ['*']
},
// Write operations (more restrictive)
write: {
windowMs: 60 * 60 * 1000, // 1 hour
max: 500, // 500 write operations per hour
endpoints: ['/v1/orders', '/v1/users', '/v1/products']
},
// Expensive operations (search, analytics)
expensive: {
windowMs: 60 * 60 * 1000, // 1 hour
max: 100, // 100 requests per hour
endpoints: ['/v1/search', '/v1/analytics', '/v1/reports']
}
};
DDoS Protection:
According to API7.ai's DDoS protection guide, combine API gateway throttling with WAF (Web Application Firewall) for defense in depth.
Tool: Rate Limit Calculator Use our Rate Limit Calculator to model optimal rate limits based on your API's capacity and expected traffic patterns.
Step 6.3: API Gateway Configuration
Example: AWS API Gateway
# serverless.yml (Serverless Framework)
service: order-api
provider:
name: aws
runtime: nodejs18.x
region: us-west-2
# API Gateway settings
apiGateway:
# Rate limiting
usagePlan:
- free:
quota:
limit: 10000
period: MONTH
throttle:
rateLimit: 10
burstLimit: 20
- paid:
quota:
limit: 1000000
period: MONTH
throttle:
rateLimit: 1000
burstLimit: 2000
# Request validation
request:
schemas:
create-order-model:
name: CreateOrderModel
schema: ${file(schemas/create-order.json)}
description: Order creation request body
# CORS
cors:
origin: 'https://app.example.com'
headers:
- Content-Type
- Authorization
- X-Api-Key
allowCredentials: true
functions:
createOrder:
handler: handlers/orders.create
events:
- http:
path: /v1/orders
method: post
authorizer:
name: jwtAuthorizer
type: token
request:
schemas:
application/json: create-order-model
throttling:
rateLimit: 100 # Endpoint-specific limit
burstLimit: 200
Step 6.4: Blue-Green Deployment
Zero-Downtime Deployment Strategy:
# 1. Deploy new version (green) alongside current (blue)
aws ecs update-service \
--cluster api-cluster \
--service api-green \
--desired-count 3 \
--task-definition api:v2.0.0
# 2. Health check green deployment
for i in {1..10}; do
curl -f https://api-green.internal/health || exit 1
sleep 5
done
# 3. Run smoke tests against green
newman run smoke-tests.postman_collection.json \
--environment green.postman_environment.json
# 4. Gradually shift traffic (10% → 50% → 100%)
aws elbv2 modify-listener \
--listener-arn $LISTENER_ARN \
--default-actions Type=forward,ForwardConfig='{
"TargetGroups": [
{"TargetGroupArn": "'$BLUE_TG'", "Weight": 90},
{"TargetGroupArn": "'$GREEN_TG'", "Weight": 10}
]
}'
# Monitor for 15 minutes, check error rates
sleep 900
# If successful, shift to 100% green
aws elbv2 modify-listener \
--listener-arn $LISTENER_ARN \
--default-actions Type=forward,ForwardConfig='{
"TargetGroups": [
{"TargetGroupArn": "'$GREEN_TG'", "Weight": 100}
]
}'
# 5. Decommission blue deployment
aws ecs update-service \
--cluster api-cluster \
--service api-blue \
--desired-count 0
Stage 6 Output:
After 1-2 days, you should have:
- Production deployment checklist completed
- Rate limiting configured (tiered, endpoint-specific)
- API gateway configured (throttling, CORS, validation)
- Blue-green deployment successful
- Zero downtime during deployment
- Rollback plan documented
Time Investment: 1-2 days Next Step: Proceed to Stage 7 for production monitoring and continuous testing.
Stage 7: Production Monitoring & Continuous Testing (Ongoing)
APIs in production require continuous monitoring, security testing, and performance optimization. According to Postman's API monitoring guide, continuous monitoring tracks uptime, latency, and anomalies with real-time alerts.
Step 7.1: Uptime & Availability Monitoring
Synthetic Monitoring (Scheduled Tests):
// Postman Monitor: Every 5 minutes
pm.test('API health check', () => {
const response = pm.response;
pm.expect(response.code).to.equal(200);
pm.expect(response.responseTime).to.be.below(500);
const health = response.json();
pm.expect(health.status).to.equal('healthy');
pm.expect(health.database).to.equal('connected');
pm.expect(health.cache).to.equal('connected');
});
pm.test('Authentication endpoint available', () => {
pm.sendRequest({
url: 'https://api.example.com/auth/login',
method: 'POST',
body: {
mode: 'raw',
raw: JSON.stringify({
username: '[email protected]',
password: pm.environment.get('monitor_password')
})
}
}, (err, res) => {
pm.expect(res.code).to.equal(200);
pm.expect(res.json()).to.have.property('access_token');
});
});
Key Metrics:
| Metric | Target | Alert Threshold |
|---|---|---|
| Uptime | 99.9% (43.2 min downtime/month) | < 99.5% |
| Response Time (p95) | < 500ms | > 1000ms |
| Error Rate | < 0.1% | > 1% |
| Availability | 99.99% | < 99.9% |
Step 7.2: Application Performance Monitoring (APM)
APM Tools:
- Datadog APM - Distributed tracing, anomaly detection
- New Relic - Full-stack observability
- Elastic APM - Open-source, Elasticsearch-based
- AWS X-Ray - Distributed tracing for AWS
Example: Datadog Instrumentation
const tracer = require('dd-trace').init({
service: 'order-api',
env: 'production',
version: '2.0.0',
analytics: true
});
// Automatic instrumentation for Express, MongoDB, Redis, etc.
const express = require('express');
const app = express();
app.get('/v1/orders/:id', async (req, res) => {
const span = tracer.scope().active();
span.setTag('user.id', req.user.sub);
span.setTag('order.id', req.params.id);
try {
const order = await db.orders.findById(req.params.id);
span.setTag('order.total', order.total);
res.json(order);
} catch (error) {
span.setTag('error', true);
span.setTag('error.message', error.message);
throw error;
}
});
Distributed Tracing:
Request Flow:
API Gateway → Authentication Service → Order Service → Database
120ms 45ms 180ms 35ms
↓
Payment Service
90ms
Total Latency: 470ms
Bottleneck: Order Service (180ms) - Investigate slow queries
Step 7.3: Security Monitoring & Threat Detection
Security Metrics to Track:
// Track failed authentication attempts
const authFailureMetric = new cloudwatch.Metric({
namespace: 'API/Security',
metricName: 'AuthenticationFailures',
dimensions: {
endpoint: '/auth/login',
source: 'api-gateway'
}
});
// Alert on credential stuffing attack pattern
const alarm = new cloudwatch.Alarm({
metric: authFailureMetric,
threshold: 50, // 50 failures in evaluation period
evaluationPeriods: 1,
period: 300, // 5 minutes
statistic: 'Sum',
alarmActions: [snsTopicArn] // Alert security team
});
Anomaly Detection:
- Unusual traffic patterns - Sudden spike in 401/403 errors
- Geographic anomalies - Requests from unexpected countries
- Velocity checks - Same user accessing 100+ orders/second
- BOLA attempts - Sequential ID enumeration (GET /orders/1, /orders/2, /orders/3...)
Tool: IP Risk Checker Use our IP Risk Checker to check IP reputation, geolocation, and threat intelligence.
Step 7.4: Rate Limit Monitoring
Track Rate Limit Metrics:
// Monitor rate limit hit rate
app.use((req, res, next) => {
res.on('finish', () => {
if (res.statusCode === 429) {
metrics.increment('api.rate_limit.exceeded', {
endpoint: req.path,
user: req.user?.sub,
ip: req.ip
});
}
});
next();
});
// Dashboard metrics:
// - Rate limit hit rate by endpoint
// - Top rate-limited users/IPs
// - Average remaining quota per user tier
Tool: Rate Limit Calculator Use our Rate Limit Calculator to model queue depth and optimize client-side retry logic.
Step 7.5: Log Analysis
Centralized Logging:
# CloudWatch Logs Insights query: Find slow endpoints
fields @timestamp, method, path, duration, statusCode
| filter statusCode = 200
| filter duration > 1000
| stats count() as slowRequests by path
| sort slowRequests desc
# Output:
# path slowRequests
# /v1/analytics/reports 1,234
# /v1/search 891
# /v1/orders/export 456
Tool: JSON Formatter Use our JSON Formatter to parse structured JSON logs.
Tool: Regex Tester Use our Regex Tester to extract log patterns (error messages, request IDs, timestamps).
Step 7.6: Continuous Security Testing
Scheduled Security Scans:
# GitHub Actions: Weekly security scan
name: Weekly Security Scan
on:
schedule:
- cron: '0 2 * * 1' # Every Monday at 2 AM
jobs:
security-scan:
runs-on: ubuntu-latest
steps:
- name: OWASP ZAP Scan
uses: zaproxy/[email protected]
with:
target: 'https://api.example.com/openapi.json'
format: 'openapi'
fail_action: true
- name: Dependency Check
run: |
npm audit --audit-level=high
- name: Secret Scanning
uses: trufflesecurity/trufflehog@main
with:
path: ./
- name: Alert on Failures
if: failure()
uses: 8398a7/action-slack@v3
with:
status: ${{ job.status }}
text: 'Security scan failed! Review results.'
Step 7.7: Incident Response Runbook
API Incident Playbook:
Tool: Incident Response Playbook Generator Use our Incident Response Playbook Generator to create customized IR playbooks for API security incidents.
## Incident: API Authentication Bypass Detected
### Detection
- Alert: 200 successful logins from IP 203.0.113.50 in 5 minutes
- Anomaly: Logins for 50 different user accounts
- Pattern: Credential stuffing attack
### Immediate Actions (0-15 minutes)
1. ☐ Block attacking IP at WAF
```bash
aws wafv2 update-ip-set --scope REGIONAL --id $IP_SET_ID \
--addresses 203.0.113.50/32
-
☐ Invalidate potentially compromised tokens
redis-cli KEYS "session:*" | grep -f compromised-users.txt | xargs redis-cli DEL -
☐ Enable MFA requirement for affected accounts
-
☐ Notify security team via Slack/PagerDuty
Investigation (15-60 minutes)
-
☐ Review auth logs for compromised accounts
aws logs filter-log-events \ --log-group-name /aws/api/auth \ --filter-pattern "{ $.ip = \"203.0.113.50\" }" -
☐ Check for data exfiltration attempts
-
☐ Identify credential source (leaked database?)
-
☐ Document incident timeline
Remediation (1-24 hours)
- ☐ Force password reset for compromised accounts
- ☐ Strengthen rate limiting on /auth/login (reduce to 3/hour)
- ☐ Implement CAPTCHA after 2 failed attempts
- ☐ Enable IP reputation checking
Post-Incident (24-72 hours)
- ☐ Conduct post-mortem meeting
- ☐ Update incident response playbook
- ☐ Implement improvements (MFA enforcement, breach detection)
- ☐ Share lessons learned with team
---
**Stage 7 Output (Ongoing):**
With continuous monitoring in place, you should have:
- Uptime monitoring (99.9%+ availability)
- APM with distributed tracing
- Security monitoring and anomaly detection
- Rate limit metrics and dashboards
- Centralized logging with analysis
- Continuous security scanning (weekly)
- Incident response playbook
**Time Investment:** Ongoing (15-30 minutes/day for monitoring)
---
## Conclusion
This comprehensive API development and security testing workflow provides a **systematic, security-first approach** to building production-ready APIs. By following these seven stages, you can:
- **Design secure APIs** with proper authentication and authorization (Stages 1-2)
- **Develop resilient endpoints** with validation and rate limiting (Stage 3)
- **Test thoroughly** for vulnerabilities and performance (Stages 4-5)
- **Deploy confidently** with zero downtime and proper controls (Stage 6)
- **Monitor continuously** with real-time alerts and incident response (Stage 7)
### Key Takeaways
1. **Shift Left Security:** Integrate security from design phase, not as an afterthought
2. **Zero-Trust Architecture:** Never trust, always verify—every request, every user, every object
3. **Defense in Depth:** Layer security controls (authentication + authorization + rate limiting + validation)
4. **OWASP API Top 10 Alignment:** Address all 10 risks systematically
5. **Continuous Testing:** Security and performance testing don't stop at deployment
### OWASP API Security Top 10 2023 Coverage Summary
| Risk | Mitigation Strategies Covered |
|------|------------------------------|
| **API1:2023 - BOLA** | Object ownership validation (Stage 2.3) |
| **API2:2023 - Broken Authentication** | OAuth 2.0 + JWT + MFA (Stage 2.1-2.5) |
| **API3:2023 - Broken Object Property Level Authorization** | Input validation, mass assignment prevention (Stage 3.1) |
| **API4:2023 - Unrestricted Resource Consumption** | Rate limiting, pagination limits (Stages 3.2, 6.2) |
| **API5:2023 - Broken Function Level Authorization** | RBAC with permission checks (Stage 2.3) |
| **API6:2023 - Unrestricted Access to Sensitive Business Flows** | Workflow validation, anti-automation (Stage 4.4) |
| **API7:2023 - SSRF** | URL allowlisting, network segmentation (Stage 4.3) |
| **API8:2023 - Security Misconfiguration** | Security hardening checklist (Stage 6.1) |
| **API9:2023 - Improper Inventory Management** | OpenAPI spec, API documentation (Stages 1.4, 6.1) |
| **API10:2023 - Unsafe Consumption of APIs** | Input validation, third-party API validation (Stage 3.1) |
### Next Steps in Your API Security Journey
**For Beginners:**
- Start with the OWASP API Security Top 10 documentation
- Practice with Postman collections for common API patterns
- Join API security communities (OWASP, Reddit r/appsec)
- Complete hands-on labs (TryHackMe, HackTheBox API challenges)
**For Intermediate Developers:**
- Implement OAuth 2.0 + PKCE in your projects
- Learn API gateway patterns (Kong, Tyk, AWS API Gateway)
- Practice threat modeling for your APIs
- Contribute to open-source API security tools
**For Advanced Engineers:**
- Specialize in API security testing (ZAP, Burp Suite Professional)
- Develop custom security middleware and validation libraries
- Implement zero-trust architecture for microservices
- Mentor junior developers on API security best practices
### Continuous Improvement
APIs evolve, and so do threats. Stay current with:
- **API versioning** - Maintain backward compatibility while improving security
- **Deprecation strategies** - Gracefully sunset insecure endpoints
- **GraphQL security** - Extend these principles to GraphQL APIs
- **gRPC security** - Adapt for high-performance RPC protocols
- **API gateways** - Centralize security controls and observability
### Resources for Continued Learning
**Industry Standards:**
- [OWASP API Security Top 10 2023](https://owasp.org/API-Security/)
- [OWASP API Security Project](https://owasp.org/www-project-api-security/)
- [REST API Authentication Best Practices (Knowi)](https://www.knowi.com/blog/4-ways-of-rest-api-authentication-methods/)
**Security Testing:**
- [API Security Testing Tools 2025 (Pynt)](https://www.pynt.io/learning-hub/api-security-testing-guides/api-security-testing-tools)
- [API Security Best Practices (Invicti)](https://www.invicti.com/blog/web-security/api-security-best-practices/)
- [API Security Testing Checklist (APIDynamics)](https://www.apidynamics.com/blogs/api-security-testing-checklist)
**API Development:**
- [Postman API-First Workflow](https://blog.postman.com/the-reimagined-api-first-workflow-for-developers/)
- [API Testing Guide (Postman)](https://www.postman.com/api-platform/api-testing/)
- [Continuous API Testing (BlazeMeter)](https://www.blazemeter.com/blog/continuous-api-testing)
**Rate Limiting & DDoS Protection:**
- [Rate Limiting Best Practices (Cloudflare)](https://developers.cloudflare.com/waf/rate-limiting-rules/best-practices/)
- [Rate Limiting Strategies (API7.ai)](https://api7.ai/learning-center/api-101/rate-limiting-and-throttling)
- [API Gateway Throttling vs WAF (Zuplo)](https://zuplo.com/learning-center/api-gateway-throttling-vs-waf-ddos-protection)
**Authentication & Authorization:**
- [OAuth 2.0 Security Best Practices (AestheteSoft)](https://www.aesthetesoft.dev/blog/modern-authentication-oauth-security)
- [JWT Best Practices (Curity)](https://curity.io/resources/learn/jwt-best-practices/)
- [API Security Best Practices 2025 (Zuplo)](https://zuplo.com/blog/2025/01/31/api-security-best-practices)
**Tools Referenced in This Guide:**
- [HTTP Request Builder](/tools/http-request-builder) - Interactive API request testing
- [OAuth/OIDC Debugger](/tools/oauth-oidc-debugger) - OAuth flow testing and JWT validation
- [JWT Decoder](/tools/jwt-decoder) - Decode and analyze JSON Web Tokens
- [JSON Validator](/tools/json-validator) - Validate JSON schemas and payloads
- [Rate Limit Calculator](/tools/rate-limit-calculator) - Model API throttling budgets
- [Hash Generator](/tools/hash-generator) - Generate cryptographic hashes
- [Base64 Encoder/Decoder](/tools/base64-encoder-decoder) - Encode/decode Base64 and other formats
- [JSON Formatter](/tools/json-formatter) - Format and analyze JSON logs
- [Regex Tester](/tools/regex-tester) - Extract log patterns
- [HTML Entity Encoder](/tools/html-encoder) - Test XSS prevention
- [Security Headers Analyzer](/tools/security-headers-analyzer) - Test HTTP security headers
- [SSL Checker](/tools/ssl-checker) - Verify SSL/TLS configuration
- [X.509 Certificate Decoder](/tools/x509-decoder) - Analyze SSL certificates
- [Certificate CSR Generator](/tools/certificate-csr-generator) - Generate CSRs and convert formats
- [CSP Policy Generator](/tools/csp-generator) - Generate Content Security Policy headers
- [Webhook Tester & Inspector](/tools/webhook-tester-inspector) - Test webhook integrations
- [Webhook Payload Generator](/tools/webhook-payload-generator) - Generate webhook payloads with signatures
- [Network Latency Calculator](/tools/network-latency-calculator) - Calculate network latency
- [TCP Window Size Calculator](/tools/tcp-window-size-calculator) - Optimize TCP performance
- [IP Risk Checker](/tools/ip-risk-checker) - Check IP reputation and threat intelligence
- [Incident Response Playbook Generator](/tools/incident-response-playbook-generator) - Create customized IR playbooks
---
## About This Guide
This comprehensive workflow guide is based on industry best practices from leading security organizations including OWASP, Cloudflare, Postman, and Salt Security. The workflow aligns with the **OWASP API Security Top 10 2023** and incorporates 2025 security trends including zero-trust architecture, OAuth 2.0 with PKCE, and AI-powered threat detection.
All tools referenced are **free, open-access utilities** designed with privacy-first, client-side processing—no data leaves your browser. InventiveHQ provides these educational tools to help developers, security engineers, and API teams build secure, performant APIs.
Whether you're building your first REST API or architecting a microservices platform, this workflow provides the foundation for security-first API development.
---
### Sources & Further Reading
- [OWASP API Security Top 10](https://owasp.org/API-Security/)
- [OWASP API Security Project](https://owasp.org/www-project-api-security/)
- [API Security Testing Tools 2025](https://www.pynt.io/learning-hub/api-security-testing-guides/api-security-testing-tools)
- [Top 10 API Security Tools in 2025](https://www.jit.io/resources/appsec-tools/top-10-api-security-tools)
- [API Security Best Practices](https://www.invicti.com/blog/web-security/api-security-best-practices/)
- [REST API Authentication Guide 2025](https://www.knowi.com/blog/4-ways-of-rest-api-authentication-methods/)
- [Modern Authentication: OAuth 2.0 and JWT Best Practices](https://www.aesthetesoft.dev/blog/modern-authentication-oauth-security)
- [JWT Security Best Practices](https://curity.io/resources/learn/jwt-best-practices/)
- [Rate Limiting Best Practices](https://developers.cloudflare.com/waf/rate-limiting-rules/best-practices/)
- [Rate Limiting and Throttling](https://api7.ai/learning-center/api-101/rate-limiting-and-throttling)
- [API Gateway Throttling vs WAF DDoS Protection](https://zuplo.com/learning-center/api-gateway-throttling-vs-waf-ddos-protection)
- [The Reimagined API-First Workflow](https://blog.postman.com/the-reimagined-api-first-workflow-for-developers/)
- [API Testing Guide](https://www.postman.com/api-platform/api-testing/)
- [Continuous API Testing](https://www.blazemeter.com/blog/continuous-api-testing)
- [API Security Testing: Risks, Tools, and Best Practices](https://www.pynt.io/learning-hub/api-security-testing-guides/api-security-testing)
- [8 Essential API Security Best Practices](https://zuplo.com/blog/2025/01/31/api-security-best-practices)
