Certificate Pinning: Implementation Guide for Mobile and Web Apps

┌─────────────────────────────────────────────────────────────────────────┐
│                    STANDARD TLS VALIDATION                               │
├─────────────────────────────────────────────────────────────────────────┤
│                                                                          │
│  ┌────────┐    certificate    ┌────────┐    validate    ┌────────────┐ │
│  │ Server │ ─────────────────►│  App   │ ──────────────►│ Trust Store│ │
│  └────────┘                   └────────┘                │ (100+ CAs) │ │
│                                                          └────────────┘ │
│  Problem: Any of 100+ CAs can issue valid certs for your domain        │
│  Risk: Compromised CA = MITM attack with valid certificate             │
│                                                                          │
├─────────────────────────────────────────────────────────────────────────┤
│                    WITH CERTIFICATE PINNING                              │
├─────────────────────────────────────────────────────────────────────────┤
│                                                                          │
│  ┌────────┐    certificate    ┌────────┐    validate    ┌────────────┐ │
│  │ Server │ ─────────────────►│  App   │ ──────────────►│ Pinned Keys│ │
│  └────────┘                   └────────┘    + match     │ (1-3 keys) │ │
│                                    │                     └────────────┘ │
│                                    │                                     │
│                               ┌────▼────┐                               │
│                               │ Reject  │ ← If cert doesn't match pins │
│                               └─────────┘                               │
│                                                                          │
│  Solution: Only accept specific certificates/keys you control           │
│  Benefit: Rogue CA certificates are rejected                            │
│                                                                          │
└─────────────────────────────────────────────────────────────────────────┘

# From a live server
openssl s_client -connect api.example.com:443 -servername api.example.com </dev/null 2>/dev/null | \
  openssl x509 -pubkey -noout | \
  openssl pkey -pubin -outform DER | \
  openssl dgst -sha256 -binary | \
  base64

# Output: AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA=

# From a certificate file
openssl x509 -in certificate.crt -pubkey -noout | \
  openssl pkey -pubin -outform DER | \
  openssl dgst -sha256 -binary | \
  base64

# View the certificate chain
openssl s_client -connect api.example.com:443 -showcerts </dev/null 2>/dev/null

# Extract intermediate (certificate 1, not 0)
openssl s_client -connect api.example.com:443 -showcerts </dev/null 2>/dev/null | \
  awk '/-----BEGIN CERTIFICATE-----/{i++}i==2' | \
  openssl x509 -pubkey -noout | \
  openssl pkey -pubin -outform DER | \
  openssl dgst -sha256 -binary | \
  base64

import Foundation
import Security
import CryptoKit

class PinnedURLSessionDelegate: NSObject, URLSessionDelegate {

    // SHA-256 hashes of pinned public keys (SPKI)
    private let pinnedPublicKeyHashes: Set<String> = [
        "AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA=",  // Primary
        "BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB="   // Backup
    ]

    func urlSession(_ session: URLSession,
                    didReceive challenge: URLAuthenticationChallenge,
                    completionHandler: @escaping (URLSession.AuthChallengeDisposition, URLCredential?) -> Void) {

        guard challenge.protectionSpace.authenticationMethod == NSURLAuthenticationMethodServerTrust,
              let serverTrust = challenge.protectionSpace.serverTrust else {
            completionHandler(.cancelAuthenticationChallenge, nil)
            return
        }

        // Validate certificate chain
        let policies = [SecPolicyCreateSSL(true, challenge.protectionSpace.host as CFString)]
        SecTrustSetPolicies(serverTrust, policies as CFArray)

        var error: CFError?
        guard SecTrustEvaluateWithError(serverTrust, &error) else {
            completionHandler(.cancelAuthenticationChallenge, nil)
            return
        }

        // Check if any certificate in chain matches our pins
        let certificateCount = SecTrustGetCertificateCount(serverTrust)

        for i in 0..<certificateCount {
            guard let certificate = SecTrustGetCertificateAtIndex(serverTrust, i),
                  let publicKey = SecCertificateCopyKey(certificate),
                  let publicKeyData = SecKeyCopyExternalRepresentation(publicKey, nil) as Data? else {
                continue
            }

            // Hash the public key
            let hash = SHA256.hash(data: publicKeyData)
            let hashBase64 = Data(hash).base64EncodedString()

            if pinnedPublicKeyHashes.contains(hashBase64) {
                completionHandler(.useCredential, URLCredential(trust: serverTrust))
                return
            }
        }

        // No pin matched - reject connection
        print("Certificate pinning failed for \(challenge.protectionSpace.host)")
        completionHandler(.cancelAuthenticationChallenge, nil)
    }
}

// Usage
let delegate = PinnedURLSessionDelegate()
let session = URLSession(configuration: .default, delegate: delegate, delegateQueue: nil)

let task = session.dataTask(with: URL(string: "https://api.example.com/data")!) { data, response, error in
    if let error = error {
        print("Request failed: \(error)")
        return
    }
    // Handle response
}
task.resume()

// In AppDelegate or early initialization
import TrustKit

func configureTrustKit() {
    let trustKitConfig: [String: Any] = [
        kTSKSwizzleNetworkDelegates: true,
        kTSKPinnedDomains: [
            "api.example.com": [
                kTSKEnforcePinning: true,
                kTSKPublicKeyHashes: [
                    "AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA=",
                    "BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB="
                ],
                kTSKIncludeSubdomains: true,
                kTSKReportUris: ["https://report.example.com/pinning"]
            ]
        ]
    ]

    TrustKit.initSharedInstance(withConfiguration: trustKitConfig)
}

<!-- res/xml/network_security_config.xml -->
<?xml version="1.0" encoding="utf-8"?>
<network-security-config>
    <domain-config cleartextTrafficPermitted="false">
        <domain includeSubdomains="true">api.example.com</domain>
        <pin-set expiration="2025-12-31">
            <!-- Primary pin -->
            <pin digest="SHA-256">AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA=</pin>
            <!-- Backup pin (REQUIRED) -->
            <pin digest="SHA-256">BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB=</pin>
        </pin-set>
        <trust-anchors>
            <certificates src="system"/>
        </trust-anchors>
    </domain-config>
</network-security-config>

<!-- AndroidManifest.xml -->
<application
    android:networkSecurityConfig="@xml/network_security_config"
    ...>

import okhttp3.CertificatePinner
import okhttp3.OkHttpClient

val certificatePinner = CertificatePinner.Builder()
    .add(
        "api.example.com",
        "sha256/AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA=",
        "sha256/BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB="
    )
    .add(
        "*.example.com",  // Wildcard support
        "sha256/CCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCC="
    )
    .build()

val client = OkHttpClient.Builder()
    .certificatePinner(certificatePinner)
    .build()

// Usage with Retrofit
val retrofit = Retrofit.Builder()
    .baseUrl("https://api.example.com/")
    .client(client)
    .addConverterFactory(GsonConverterFactory.create())
    .build()

// Using react-native-ssl-pinning
import { fetch } from 'react-native-ssl-pinning';

const response = await fetch('https://api.example.com/data', {
  method: 'GET',
  timeoutInterval: 10000,
  sslPinning: {
    certs: ['cert1', 'cert2']  // Certificate files in assets
  }
});

// Or with public key hashes
const response = await fetch('https://api.example.com/data', {
  method: 'GET',
  pkPinning: true,
  sslPinning: {
    certs: [
      'AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA=',
      'BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB='
    ]
  }
});

┌─────────────────────────────────────────────────────────────────┐
│                  HPKP (Deprecated 2018)                         │
├─────────────────────────────────────────────────────────────────┤
│  Public-Key-Pins: pin-sha256="..."; max-age=5184000            │
│                                                                 │
│  Risks:                                                         │
│  • "HPKP Suicide" - lose keys = site becomes inaccessible      │
│  • "RansomPKP" - attacker pins their keys via XSS              │
│  • Complex rotation requiring careful planning                  │
│                                                                 │
├─────────────────────────────────────────────────────────────────┤
│              MODERN ALTERNATIVES                                │
├─────────────────────────────────────────────────────────────────┤
│                                                                 │
│  1. Certificate Transparency (CT) Monitoring                    │
│     - Monitor crt.sh or CT logs for unauthorized certs         │
│     - Alert on certificates you didn't request                 │
│                                                                 │
│  2. Expect-CT Header (Report-Only)                              │
│     Expect-CT: max-age=86400, report-uri="https://..."         │
│     - Requires CT compliance, reports violations               │
│                                                                 │
│  3. CAA DNS Records                                             │
│     example.com. CAA 0 issue "letsencrypt.org"                 │
│     - Restricts which CAs can issue for your domain            │
│                                                                 │
└─────────────────────────────────────────────────────────────────┘

; Only Let's Encrypt can issue certificates
example.com.    CAA 0 issue "letsencrypt.org"
example.com.    CAA 0 issuewild "letsencrypt.org"

; Report violations
example.com.    CAA 0 iodef "mailto:[email protected]"

# Query CT logs for your domain
curl "https://crt.sh/?q=%.example.com&output=json" | jq '.[].id'

# Set up monitoring with certspotter
pip install certspotter
certspotter --domain example.com --webhook https://alerts.example.com/ct

┌─────────────────────────────────────────────────────────────────┐
│                    PIN ROTATION TIMELINE                         │
├─────────────────────────────────────────────────────────────────┤
│                                                                  │
│  Month 1          Month 2          Month 3          Month 4     │
│  ────────────────────────────────────────────────────────────── │
│                                                                  │
│  [Pin A: Active]   [Pin A: Active]  [Pin A: Removed]            │
│  [Pin B: Backup]   [Pin B: Active]  [Pin B: Active]             │
│                    [Pin C: Added]   [Pin C: Backup]             │
│                                                                  │
│  Steps:                                                          │
│  1. Always have 2+ pins (active + backup)                       │
│  2. Add new backup pin BEFORE removing old pin                  │
│  3. Wait for app update propagation (2-4 weeks)                 │
│  4. Rotate active pin to use new certificate                    │
│  5. Remove old pin only after full propagation                  │
│                                                                  │
└─────────────────────────────────────────────────────────────────┘

#!/usr/bin/env python3
"""Check if pinned certificates are expiring soon."""

import ssl
import socket
from datetime import datetime, timedelta
import hashlib
import base64

def get_cert_pins(hostname, port=443):
    """Extract public key pins from server certificate chain."""
    context = ssl.create_default_context()
    pins = []

    with socket.create_connection((hostname, port)) as sock:
        with context.wrap_socket(sock, server_hostname=hostname) as ssock:
            cert_chain = ssock.getpeercert(binary_form=True)
            # Note: This gets leaf cert only; for full chain, use different approach

            cert = ssl.DER_cert_to_PEM_cert(cert_chain)
            # Extract and hash public key
            # (Simplified - use cryptography library for production)

    return pins

def check_pin_expiration(pins, warning_days=30):
    """Check if any pinned certificates are expiring soon."""
    alerts = []
    today = datetime.now()

    for pin in pins:
        days_until_expiry = (pin['expiration'] - today).days
        if days_until_expiry < warning_days:
            alerts.append({
                'pin': pin['hash'],
                'expires': pin['expiration'],
                'days_remaining': days_until_expiry
            })

    return alerts

# Check and alert
alerts = check_pin_expiration([
    {'hash': 'AAAA...', 'expiration': datetime(2025, 6, 1)},
    {'hash': 'BBBB...', 'expiration': datetime(2025, 12, 1)}
])

for alert in alerts:
    print(f"WARNING: Pin {alert['pin'][:20]}... expires in {alert['days_remaining']} days")

// iOS - Remote config based bypass
class PinningConfiguration {
    static let shared = PinningConfiguration()

    var isPinningEnabled: Bool {
        // Check remote config
        return RemoteConfig.shared.getBool("pinning_enabled", default: true)
    }

    var pinnedHashes: [String] {
        // Allow remote pin updates for emergencies
        if let remotePins = RemoteConfig.shared.getStringArray("pinned_keys") {
            return remotePins
        }
        return defaultPins
    }

    private let defaultPins = [
        "AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA=",
        "BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB="
    ]
}

// Android - Remote config based bypass
object PinningConfig {
    private val remoteConfig = FirebaseRemoteConfig.getInstance()

    val isPinningEnabled: Boolean
        get() = remoteConfig.getBoolean("pinning_enabled")

    val pins: List<String>
        get() {
            val remotePins = remoteConfig.getString("pinned_keys")
            return if (remotePins.isNotEmpty()) {
                remotePins.split(",")
            } else {
                defaultPins
            }
        }

    private val defaultPins = listOf(
        "sha256/AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA=",
        "sha256/BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB="
    )
}

# Use mitmproxy or Charles Proxy to intercept traffic
# If pinning is working, the app should refuse to connect

# Android: Install proxy CA as user cert (won't be trusted for pinned domains)
# iOS: Trust proxy CA in Settings > General > About > Certificate Trust Settings

// iOS - Detailed logging
func urlSession(_ session: URLSession,
                didReceive challenge: URLAuthenticationChallenge,
                completionHandler: @escaping (URLSession.AuthChallengeDisposition, URLCredential?) -> Void) {

    guard let serverTrust = challenge.protectionSpace.serverTrust else {
        print("No server trust available")
        completionHandler(.cancelAuthenticationChallenge, nil)
        return
    }

    let count = SecTrustGetCertificateCount(serverTrust)
    print("Certificate chain contains \(count) certificates")

    for i in 0..<count {
        if let cert = SecTrustGetCertificateAtIndex(serverTrust, i) {
            let summary = SecCertificateCopySubjectSummary(cert) as String? ?? "Unknown"
            print("Certificate \(i): \(summary)")

            if let publicKey = SecCertificateCopyKey(cert),
               let data = SecKeyCopyExternalRepresentation(publicKey, nil) as Data? {
                let hash = SHA256.hash(data: data)
                print("  Public key hash: \(Data(hash).base64EncodedString())")
            }
        }
    }

    // Continue with validation...
}
