OAuth 2.0 & OpenID Connect Implementation Guide

OAuth 2.0 and OpenID Connect (OIDC) are the industry standards for API authentication and authorization. This guide covers everything you need to implement secure OAuth/OIDC flows, aligned with the latest OAuth 2.1 security best practices.

OAuth 2.0 vs OpenID Connect

┌─────────────────────────────────────────────────────────────────┐
│                    OAUTH 2.0 vs OIDC                            │
├─────────────────────────────────────────────────────────────────┤
│                                                                 │
│  OAuth 2.0 = AUTHORIZATION                                      │
│  "What can this app access?"                                    │
│  └─► Access Tokens → API Access                                 │
│                                                                 │
│  OpenID Connect = AUTHENTICATION + Authorization                │
│  "Who is this user?" + "What can they access?"                  │
│  └─► ID Tokens → User Identity                                  │
│  └─► Access Tokens → API Access                                 │
│                                                                 │
│  OIDC = OAuth 2.0 + Identity Layer                              │
│                                                                 │
└─────────────────────────────────────────────────────────────────┘

Grant Type Selection Guide

What type of client are you building?
│
├─► User-facing app (web, mobile, SPA)
│   │
│   └─► Use: Authorization Code + PKCE
│       • User authenticates at IdP
│       • Code exchanged for tokens
│       • Works for all client types
│
├─► Server-to-server (no user)
│   │
│   └─► Use: Client Credentials
│       • Machine-to-machine auth
│       • Client authenticates directly
│       • No user involvement
│
├─► Device with no keyboard (TV, IoT)
│   │
│   └─► Use: Device Authorization Grant
│       • User authenticates on phone/computer
│       • Device polls for tokens
│       • Good for CLI tools too
│
└─► ❌ DEPRECATED (Don't use)
    • Implicit Grant - tokens exposed in URL
    • ROPC - user credentials shared with app

Authorization Code Flow with PKCE

This is the recommended flow for all user-facing applications.

Flow Diagram

┌─────────┐                                    ┌─────────┐
│  User   │                                    │   IdP   │
└────┬────┘                                    └────┬────┘
     │                                              │
     │  1. Click "Login"                            │
     ▼                                              │
┌─────────┐  2. Redirect with code_challenge  ┌────┴────┐
│  App    │ ─────────────────────────────────►│  Auth   │
│ (Client)│                                   │Endpoint │
└────┬────┘                                   └────┬────┘
     │                                              │
     │         3. User authenticates                │
     │         4. User consents to scopes           │
     │                                              │
     │  5. Redirect with authorization code         │
     │◄─────────────────────────────────────────────│
     │                                              │
     │  6. Exchange code + code_verifier       ┌────┴────┐
     │ ─────────────────────────────────────────►│ Token  │
     │                                         │Endpoint │
     │  7. Receive tokens                      └────┬────┘
     │◄─────────────────────────────────────────────│
     │                                              │
     │  8. Use access_token for API calls           │
     ▼                                              ▼
┌─────────┐                                    ┌─────────┐
│   API   │◄───────────────────────────────────│ Tokens  │
└─────────┘                                    └─────────┘

Step 1: Generate PKCE Challenge

// Generate cryptographically random code verifier
function generateCodeVerifier() {
  const array = new Uint8Array(32);
  crypto.getRandomValues(array);
  return base64URLEncode(array);
}

// Create code challenge (SHA-256 hash of verifier)
async function generateCodeChallenge(verifier) {
  const encoder = new TextEncoder();
  const data = encoder.encode(verifier);
  const hash = await crypto.subtle.digest('SHA-256', data);
  return base64URLEncode(new Uint8Array(hash));
}

// Base64URL encoding (no padding, URL-safe)
function base64URLEncode(buffer) {
  return btoa(String.fromCharCode(...buffer))
    .replace(/\+/g, '-')
    .replace(/\//g, '_')
    .replace(/=+$/, '');
}

// Generate both values
const codeVerifier = generateCodeVerifier();
const codeChallenge = await generateCodeChallenge(codeVerifier);

// Store codeVerifier securely (session storage for SPAs, server session for web apps)
sessionStorage.setItem('pkce_verifier', codeVerifier);

Step 2: Build Authorization Request

function buildAuthorizationURL() {
  const params = new URLSearchParams({
    response_type: 'code',
    client_id: 'your_client_id',
    redirect_uri: 'https://yourapp.com/callback',
    scope: 'openid profile email read:data',
    state: generateRandomString(32),  // CSRF protection
    nonce: generateRandomString(32),  // ID token replay protection
    code_challenge: codeChallenge,
    code_challenge_method: 'S256'
  });

  // Store state for validation
  sessionStorage.setItem('oauth_state', params.get('state'));
  sessionStorage.setItem('oauth_nonce', params.get('nonce'));

  return `https://auth.example.com/authorize?${params}`;
}

// Redirect user to authorization endpoint
window.location.href = buildAuthorizationURL();

Step 3: Handle Callback and Exchange Code

async function handleCallback() {
  const params = new URLSearchParams(window.location.search);

  // Validate state to prevent CSRF
  const storedState = sessionStorage.getItem('oauth_state');
  if (params.get('state') !== storedState) {
    throw new Error('State mismatch - possible CSRF attack');
  }

  // Check for errors
  if (params.has('error')) {
    throw new Error(`OAuth error: ${params.get('error_description')}`);
  }

  // Get authorization code
  const code = params.get('code');
  const codeVerifier = sessionStorage.getItem('pkce_verifier');

  // Exchange code for tokens
  const tokens = await exchangeCode(code, codeVerifier);

  // Clean up
  sessionStorage.removeItem('oauth_state');
  sessionStorage.removeItem('oauth_nonce');
  sessionStorage.removeItem('pkce_verifier');

  return tokens;
}

async function exchangeCode(code, codeVerifier) {
  const response = await fetch('https://auth.example.com/token', {
    method: 'POST',
    headers: {
      'Content-Type': 'application/x-www-form-urlencoded'
    },
    body: new URLSearchParams({
      grant_type: 'authorization_code',
      client_id: 'your_client_id',
      code: code,
      redirect_uri: 'https://yourapp.com/callback',
      code_verifier: codeVerifier
    })
  });

  if (!response.ok) {
    const error = await response.json();
    throw new Error(`Token exchange failed: ${error.error_description}`);
  }

  return response.json();
  // Returns: { access_token, refresh_token, id_token, expires_in, token_type }
}

Step 4: Validate ID Token (OIDC)

async function validateIdToken(idToken, nonce) {
  // Decode token (without verification for inspection)
  const parts = idToken.split('.');
  const header = JSON.parse(atob(parts[0]));
  const payload = JSON.parse(atob(parts[1]));

  // Get signing keys from IdP
  const jwksResponse = await fetch('https://auth.example.com/.well-known/jwks.json');
  const jwks = await jwksResponse.json();

  // Find the key matching the token's kid
  const key = jwks.keys.find(k => k.kid === header.kid);
  if (!key) {
    throw new Error('Signing key not found');
  }

  // Verify signature (use a library like jose)
  const isValid = await verifySignature(idToken, key);
  if (!isValid) {
    throw new Error('Invalid signature');
  }

  // Validate claims
  const now = Math.floor(Date.now() / 1000);

  if (payload.iss !== 'https://auth.example.com') {
    throw new Error('Invalid issuer');
  }

  if (payload.aud !== 'your_client_id') {
    throw new Error('Invalid audience');
  }

  if (payload.exp < now) {
    throw new Error('Token expired');
  }

  if (payload.iat > now + 60) {  // Allow 60s clock skew
    throw new Error('Token issued in the future');
  }

  if (payload.nonce !== nonce) {
    throw new Error('Invalid nonce - possible replay attack');
  }

  return payload;  // User identity information
}

Client Credentials Flow

For server-to-server authentication without user involvement.

async function getClientCredentialsToken() {
  const response = await fetch('https://auth.example.com/token', {
    method: 'POST',
    headers: {
      'Content-Type': 'application/x-www-form-urlencoded',
      // Client authentication via Basic auth or in body
      'Authorization': `Basic ${btoa(`${clientId}:${clientSecret}`)}`
    },
    body: new URLSearchParams({
      grant_type: 'client_credentials',
      scope: 'read:data write:data'
    })
  });

  const { access_token, expires_in } = await response.json();

  // Cache token until near expiration
  return access_token;
}

// Example: Service-to-service API call
async function callInternalAPI() {
  const token = await getClientCredentialsToken();

  const response = await fetch('https://api.internal.com/data', {
    headers: {
      'Authorization': `Bearer ${token}`
    }
  });

  return response.json();
}

Token Management Best Practices

Secure Token Storage

Platform	Access Token	Refresh Token
Web (SSR)	HttpOnly cookie	HttpOnly cookie (separate)
SPA	Memory only	HttpOnly cookie via BFF
Mobile	Secure storage	Keychain/Keystore
Server	Encrypted DB/secrets manager	Same, with higher protection

Token Refresh with Rotation

async function refreshAccessToken(refreshToken) {
  const response = await fetch('https://auth.example.com/token', {
    method: 'POST',
    headers: {
      'Content-Type': 'application/x-www-form-urlencoded'
    },
    body: new URLSearchParams({
      grant_type: 'refresh_token',
      client_id: 'your_client_id',
      refresh_token: refreshToken
    })
  });

  if (!response.ok) {
    if (response.status === 400) {
      // Refresh token invalid/expired - require re-authentication
      throw new Error('Session expired - please login again');
    }
    throw new Error('Token refresh failed');
  }

  const tokens = await response.json();

  // IMPORTANT: Save the NEW refresh token (rotation)
  // Old refresh token is now invalid
  await saveTokens(tokens.access_token, tokens.refresh_token);

  return tokens.access_token;
}

Automatic Token Refresh

class TokenManager {
  constructor() {
    this.accessToken = null;
    this.refreshToken = null;
    this.expiresAt = null;
  }

  async getAccessToken() {
    // Check if token is expired or about to expire (60s buffer)
    if (!this.accessToken || Date.now() >= this.expiresAt - 60000) {
      await this.refresh();
    }
    return this.accessToken;
  }

  async refresh() {
    if (!this.refreshToken) {
      throw new Error('No refresh token - authentication required');
    }

    try {
      const tokens = await refreshAccessToken(this.refreshToken);
      this.setTokens(tokens);
    } catch (error) {
      // Clear tokens and redirect to login
      this.clear();
      throw error;
    }
  }

  setTokens({ access_token, refresh_token, expires_in }) {
    this.accessToken = access_token;
    this.refreshToken = refresh_token;
    this.expiresAt = Date.now() + (expires_in * 1000);
  }

  clear() {
    this.accessToken = null;
    this.refreshToken = null;
    this.expiresAt = null;
  }
}

// Usage with fetch wrapper
const tokenManager = new TokenManager();

async function authenticatedFetch(url, options = {}) {
  const token = await tokenManager.getAccessToken();

  return fetch(url, {
    ...options,
    headers: {
      ...options.headers,
      'Authorization': `Bearer ${token}`
    }
  });
}

Security Checklist

Authorization Request

Use PKCE (code_challenge + code_challenge_method=S256)
Include state parameter (random, >= 32 bytes)
Include nonce parameter for OIDC (random, >= 32 bytes)
Use exact redirect_uri matching
Request minimum necessary scopes

Token Exchange

Validate state parameter matches stored value
Use code_verifier with PKCE
Exchange code promptly (codes expire quickly)
Use HTTPS for all token endpoint calls

Token Validation

Verify signature using JWKS
Validate iss (issuer) claim
Validate aud (audience) claim
Check exp (expiration) claim
Validate nonce matches for ID tokens
Use clock skew tolerance (e.g., 60 seconds)

Token Storage

Never store tokens in localStorage (XSS vulnerable)
Use HttpOnly cookies for web apps
Use platform secure storage for mobile
Encrypt tokens at rest on servers

Token Lifecycle

Implement refresh token rotation
Set reasonable expiration times
Support token revocation
Clear tokens on logout

Common Pitfalls

Mistake	Risk	Solution
Skipping PKCE	Code interception	Always use PKCE, even for confidential clients
Tokens in localStorage	XSS theft	Use HttpOnly cookies or memory
Long-lived access tokens	Extended exposure	Short expiry (15 min) + refresh tokens
No state parameter	CSRF attacks	Random state, validate on callback
Trusting token claims	Forged tokens	Always verify signatures
Refresh token reuse	Undetected theft	Implement rotation

Next Steps

JWT Security Best Practices - Deep dive into JWT security
API Authentication Comparison - When to use OAuth vs other methods
API Security Complete Guide - Comprehensive API security overview

OAuth 2.0 & OpenID Connect Implementation Guide

OAuth 2.0 vs OpenID Connect

Grant Type Selection Guide

Authorization Code Flow with PKCE

Flow Diagram

Step 1: Generate PKCE Challenge

Step 2: Build Authorization Request

Step 3: Handle Callback and Exchange Code

Step 4: Validate ID Token (OIDC)

Client Credentials Flow

Token Management Best Practices

Secure Token Storage

Token Refresh with Rotation

Automatic Token Refresh

Security Checklist

Authorization Request

Token Exchange

Token Validation

Token Storage

Token Lifecycle

Common Pitfalls

Next Steps

Need Expert IT & Security Guidance?

How should APIs use status codes for RESTful responses?

Can I compare JSON, XML, or structured data?

How do I create and apply patch files from diffs?

OAuth 2.0 & OpenID Connect Implementation Guide

OAuth 2.0 vs OpenID Connect

Grant Type Selection Guide

Authorization Code Flow with PKCE

Flow Diagram

Step 1: Generate PKCE Challenge

Step 2: Build Authorization Request

Step 3: Handle Callback and Exchange Code

Step 4: Validate ID Token (OIDC)

Client Credentials Flow

Token Management Best Practices

Secure Token Storage

Token Refresh with Rotation

Automatic Token Refresh

Security Checklist

Authorization Request

Token Exchange

Token Validation

Token Storage

Token Lifecycle

Common Pitfalls

Next Steps

Need Expert IT & Security Guidance?

Related Articles

How should APIs use status codes for RESTful responses?

Can I compare JSON, XML, or structured data?

How do I create and apply patch files from diffs?
