API Versioning Strategies: URL, Header, and Query Parameter Approaches

There are three practical ways to version a REST API — put the version in the URL path (/api/v1/users), in a request header (Api-Version: 2 or Accept: application/vnd.myapi.v2+json), or in a query parameter (/api/users?version=2) — and for the overwhelming majority of public APIs, URL path versioning is the right default because it is visible in logs, cacheable at the CDN, testable in a browser, and trivial to route at the gateway. Header versioning is "purer" REST and keeps URLs clean, but it costs you caching complexity (a Vary header) and testability; query-parameter versioning is the simplest to bolt on but the easiest to break, because parameters get dropped by caches and collide with real filters. The strategy you pick is far less important than picking one and applying it consistently across every endpoint.

That is the summary an AI Overview will give you. What it can't show you is the shape of the trade-off — where a request actually gets routed, which change types force a new major version, and what a version's death looks like on a calendar. The rest of this guide is those concrete assets: a decision table with a "which should I use" row, an animated diagram of how each strategy routes the same request, working Express/Kong/AWS code, and an RFC-accurate deprecation timeline.

Versioning Strategy Comparison

Factor	URL path /v1/users	Header Api-Version: 2	Query ?version=2
Ease of implementation	Easiest	Moderate	Easy
Visible in access logs	Yes	No (headers rarely logged)	Yes
Browser-testable (paste URL)	Yes	No	Yes
CDN / proxy cacheable	Cleanly	Needs Vary header	Often dropped by caches
REST "purity"	Low (version isn't a resource)	High (content negotiation)	Low
Collision risk	None	None	Clashes with real filters
Discoverability for new devs	High	Low	Medium
Which should I use / when	Default for public + internal APIs; anything CDN-cached	Strict REST shops, hypermedia APIs, when clean URLs are a hard requirement	Quick internal APIs and prototypes only — avoid for anything public

How each strategy routes the same request

Breaking vs Non-Breaking Changes

Change Type	Breaking?	Action
Remove field from response	✅ Yes	New version
Remove endpoint	✅ Yes	New version
Rename field	✅ Yes	New version
Change field type (string→number)	✅ Yes	New version
Change authentication method	✅ Yes	New version
Change error format	✅ Yes	New version
Add new optional field	❌ No	Current version
Add new endpoint	❌ No	Current version
Add new optional parameter	❌ No	Current version
Bug fix (same behavior)	❌ No	Current version
Performance improvement	❌ No	Current version

URL Path Versioning

Express.js Implementation

import express from 'express';

const app = express();

// Version 1 routes
const v1Router = express.Router();
v1Router.get('/users', (req, res) => {
  res.json({
    users: [
      { id: 1, name: 'John', email: 'john@example.com' }
    ]
  });
});

// Version 2 routes (different response structure)
const v2Router = express.Router();
v2Router.get('/users', (req, res) => {
  res.json({
    data: [
      {
        id: 1,
        attributes: {
          name: 'John',
          email: 'john@example.com'
        }
      }
    ],
    meta: { total: 1 }
  });
});

// Mount versioned routers
app.use('/api/v1', v1Router);
app.use('/api/v2', v2Router);

// Redirect unversioned to latest stable
app.use('/api/users', (req, res) => {
  res.redirect(308, `/api/v2${req.path}`);
});

Shared Code Between Versions

// services/users.service.ts - Shared business logic
export class UsersService {
  async getUsers(filters: UserFilters): Promise<User[]> {
    return await prisma.user.findMany({ where: filters });
  }
}

// v1/users.controller.ts
import { UsersService } from '../services/users.service';

const usersService = new UsersService();

export async function getUsers(req: Request, res: Response) {
  const users = await usersService.getUsers(req.query);

  // V1 response format
  res.json({ users });
}

// v2/users.controller.ts
import { UsersService } from '../services/users.service';

const usersService = new UsersService();

export async function getUsers(req: Request, res: Response) {
  const users = await usersService.getUsers(req.query);

  // V2 response format (JSON:API style)
  res.json({
    data: users.map(u => ({
      id: u.id,
      type: 'user',
      attributes: { name: u.name, email: u.email }
    })),
    meta: { total: users.length }
  });
}

Header Versioning

Custom Header Implementation

// Middleware to extract version from header
function versionMiddleware(req: Request, res: Response, next: NextFunction) {
  const version = req.headers['api-version'] || req.headers['x-api-version'];

  if (!version) {
    // Default to latest stable
    req.apiVersion = 2;
  } else {
    const parsed = parseInt(version as string, 10);
    if (isNaN(parsed) || parsed < 1 || parsed > 2) {
      return res.status(400).json({
        error: 'Invalid API version',
        supported: [1, 2],
      });
    }
    req.apiVersion = parsed;
  }

  // Add version to response
  res.setHeader('Api-Version', req.apiVersion);
  next();
}

// Route handler using version
app.get('/api/users', versionMiddleware, async (req, res) => {
  const users = await usersService.getUsers(req.query);

  if (req.apiVersion === 1) {
    return res.json({ users });
  }

  // Version 2
  return res.json({
    data: users.map(formatUserV2),
    meta: { total: users.length }
  });
});

Accept Header (Content Negotiation)

// Using media type versioning
// Accept: application/vnd.myapi.v2+json

function parseAcceptVersion(accept: string | undefined): number {
  if (!accept) return 2; // Default

  const match = accept.match(/application\/vnd\.myapi\.v(\d+)\+json/);
  return match ? parseInt(match[1], 10) : 2;
}

app.get('/api/users', (req, res) => {
  const version = parseAcceptVersion(req.headers.accept);

  // Set appropriate content type
  res.setHeader(
    'Content-Type',
    `application/vnd.myapi.v${version}+json`
  );

  // Version-specific response
  // ...
});

API Gateway Routing

Kong Configuration

# kong.yml
services:
  - name: api-v1
    url: http://api-v1-service:8080
    routes:
      - name: api-v1-route
        paths:
          - /api/v1

  - name: api-v2
    url: http://api-v2-service:8080
    routes:
      - name: api-v2-route
        paths:
          - /api/v2

  # Header-based routing
  - name: api-v1-header
    url: http://api-v1-service:8080
    routes:
      - name: api-v1-header-route
        paths:
          - /api
        headers:
          api-version:
            - "1"

  - name: api-v2-header
    url: http://api-v2-service:8080
    routes:
      - name: api-v2-header-route
        paths:
          - /api
        headers:
          api-version:
            - "2"

AWS API Gateway

# SAM template
Resources:
  ApiV1:
    Type: AWS::Serverless::Api
    Properties:
      StageName: v1
      DefinitionUri: ./openapi-v1.yaml

  ApiV2:
    Type: AWS::Serverless::Api
    Properties:
      StageName: v2
      DefinitionUri: ./openapi-v2.yaml

  # Custom domain with base path mappings
  ApiDomainMapping:
    Type: AWS::ApiGatewayV2::ApiMapping
    Properties:
      DomainName: api.example.com
      ApiId: !Ref ApiV2
      Stage: v2
      ApiMappingKey: v2

  ApiDomainMappingV1:
    Type: AWS::ApiGatewayV2::ApiMapping
    Properties:
      DomainName: api.example.com
      ApiId: !Ref ApiV1
      Stage: v1
      ApiMappingKey: v1

Deprecation Strategy

Deprecation Headers

// Middleware to add deprecation headers
function deprecationMiddleware(
  deprecationDate: string,
  sunsetDate: string,
  link: string
) {
  return (req: Request, res: Response, next: NextFunction) => {
    // RFC 9745 Deprecation header (published April 2025)
    res.setHeader('Deprecation', deprecationDate);

    // RFC 8594 Sunset header
    res.setHeader('Sunset', sunsetDate);

    // Link to migration guide
    res.setHeader('Link', `<${link}>; rel="deprecation"`);

    // Optional warning header
    res.setHeader(
      'Warning',
      '299 - "This API version is deprecated. Please migrate to v2."'
    );

    next();
  };
}

// Apply to v1 routes
app.use(
  '/api/v1',
  deprecationMiddleware(
    'Sun, 01 Jan 2025 00:00:00 GMT',  // Deprecated since
    'Mon, 01 Jul 2025 00:00:00 GMT',  // Will be removed
    'https://docs.example.com/migration-guide'
  ),
  v1Router
);

Version Lifecycle

A deprecated version does not vanish the moment v2 ships — it moves through a fixed sequence of states on a published calendar. The diagram below shows the 18-month path most teams use, though enterprise APIs frequently stretch the sunset out to 24-36 months.

Sunset Response

// After sunset date, return 410 Gone
app.use('/api/v1', (req, res) => {
  const sunsetDate = new Date('2025-07-01');

  if (new Date() > sunsetDate) {
    return res.status(410).json({
      error: 'VERSION_SUNSET',
      message: 'API v1 has been sunset. Please migrate to v2.',
      migrationGuide: 'https://docs.example.com/migration-v1-v2',
      currentVersion: 'https://api.example.com/v2',
    });
  }

  // Still active, continue with deprecation warnings
  next();
});

Version Migration Guide Template

# Migrating from API v1 to v2

## Overview
API v2 introduces a new response format following JSON:API specification,
improved error handling, and new endpoints for batch operations.

## Timeline
- **Deprecation Date**: January 1, 2025
- **Sunset Date**: July 1, 2025
- **Support Email**: api-support@example.com

## Breaking Changes

### Response Format
**v1:**
```json
{
  "users": [{"id": 1, "name": "John"}]
}

v2:

{
  "data": [{"id": 1, "type": "user", "attributes": {"name": "John"}}],
  "meta": {"total": 1}
}

Authentication

• v1: API key in query parameter (?api_key=xxx)
• v2: API key in header (Authorization: Bearer xxx)

Removed Endpoints

• GET /users/search → Use GET /users?filter[name]=xxx
• POST /users/bulk → Use POST /users with array body

Migration Steps

1. Update authentication to use header
2. Update response parsing for new format
3. Update any deprecated endpoint calls
4. Test thoroughly in staging
5. Deploy and monitor errors

Code Examples

[SDK examples for major languages]

Support

Contact api-support@example.com for migration assistance.

## Security Considerations

```typescript
// Ensure auth/authz applies to ALL versions
function authMiddleware(req: Request, res: Response, next: NextFunction) {
  const token = req.headers.authorization;

  if (!token) {
    return res.status(401).json({ error: 'Unauthorized' });
  }

  // Validate token (same logic for all versions)
  try {
    req.user = verifyToken(token);
    next();
  } catch (e) {
    return res.status(401).json({ error: 'Invalid token' });
  }
}

// Apply BEFORE version routing
app.use('/api', authMiddleware);
app.use('/api/v1', v1Router);
app.use('/api/v2', v2Router);

// Rate limiting across versions
const rateLimiter = rateLimit({
  windowMs: 60 * 1000,
  max: 100,
  keyGenerator: (req) => {
    // Same key regardless of version
    return req.user?.id || req.ip;
  },
});

app.use('/api', rateLimiter);

Monitoring Versions

// Track version usage for deprecation decisions
app.use('/api/:version', (req, res, next) => {
  const version = req.params.version;
  const clientId = req.user?.id || 'anonymous';

  // Log to analytics
  analytics.track({
    event: 'api_request',
    properties: {
      version,
      clientId,
      endpoint: req.path,
      method: req.method,
    },
  });

  // Prometheus metric
  apiRequestsTotal.inc({
    version,
    endpoint: req.path,
    method: req.method,
  });

  next();
});

Best Practices

1. Choose one strategy - Consistency across your API
2. Version early - Start with /v1 even if no v2 planned
3. Global versioning - All endpoints at same version
4. Semantic meaning - Major version for breaking changes
5. Long deprecation periods - 12-24 months minimum
6. Clear documentation - Migration guides for each version
7. Monitor usage - Data-driven sunset decisions
8. Security parity - Same security controls across versions
9. Deprecation headers - Machine-readable warnings
10. No silent changes - Even non-breaking changes need docs
